Installation Instructions
Model # SC-UN
Universal Source Controller
Risk of Fire, Electrical Shock, Cuts or other Casualty Hazards- Installation and maintenance of this product must be
performed by a qualified electrician. This product must be installed in accordance with the applicable installation code
by a person familiar with the construction and operation of the product and hazards involved. For continued protection
against shock hazard replace all covers and guards after field wiring is completed.
Risk of Fire and Electric Shock- Before installing or performing any service, the power MUST be turned OFF.
All installations should be in compliance with the National Electric Code and all state and local codes.
Risk of Burn- Disconnect power and allow product to cool before handling or servicing.
Risk of Personal Injury- Due to sharp edges, handle with care.
Failure to comply with these instructions may result in death, serious bodily injury and property damage.
DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind that may arise
from the improper, careless, or negligent installation, handling or use of this product.
IMPORTANT: Read carefully before installing product. Retain for future reference.
NOTICE: Product may become damaged and/or unstable if not installed properly.
Note: Specifications and dimensions subject to change without notice.
ATTENTION Receiving Department: Note actual product description of any shortage or noticeable damage on delivery receipt.
File claim for common carrier (LTL) directly with carrier. Claims for concealed damage must be filed within 15 days of delivery.
All damaged material, complete with original packing must be retained.
NOTICE: All new wiring must be fully verified before applying power.
NOTICE: Designed for indoor installation and use only. Dry location rated.
Please Read This First
The Universal Source Controllers are designed, built and tested to strict safety regulations. By following the steps listed below and elsewhere within this
guide, you can ensure safe installation and operation of these controller units.
• The Universal Source Controllers must be installed only by a qualified electrician
• The installation must comply with the appropriate electrical codes and regulations in force in your area
• The Universal Source Controllers are designed for indoor installation and use only. The units can, however, be used to control appropriately certified
exterior lighting fixtures
• Ensure that all wiring used conforms fully to local specifications and is sufficiently rated for the installation
• All new wiring must be fully verified before applying power
• The high voltage supply should be fed to the Universal Source Controller via an external isolation breaker with sufficient capacity for the planned
installation
• All Universal Source Controllers exceed the weight limit for one person lifting - always use at least two people when lifting and mounting the units
• Do not mix load types within a single channel (e.g. 120V tungsten and low voltage ballast control)
• Ensure that the supply is fully isolated at an external breaker before removing the chassis covers. Test that power has been removed before starting
to handle conductors
• Ensure that high voltage and low voltage wiring remains separate
Important Points For Consideration
• The Universal Source Controllers must be mounted flush with the wall, do not recess the controller chassis
• Upper and lower raceways must not be located within 8 inches (200 mm) of the upper and lower panels of the Universal Source Controller. Use
suitable conduits and couplers to link the raceways to the controller chassis
• Allow adequate space for future maintenance of the unit. Do not install in a location that will later be difficult to access
• The Universal Source Controllers are designed to be mounted vertically
• During operation, the Universal Source Controllers will produce audible noise caused by electrical noise suppression circuitry and also the circuit
relays within the unit. The noise is a low level buzz that varies with the level of dimming and also clicks when relays are energised. Take these
matters into consideration when deciding on a suitable mounting position.
• The hinged cover must be unscrewed and removed from the front cover when the Universal Source Controller operates at full load in a high ambient
environment
WARNING
WaveLinx Wired
