Summary of Contents for DEVIATE highlander
- Page 1 Product Manual Contents • Safety • Assembly • Maintenance • Parts List • Diagrams...
- Page 2 Product Manual Safety WARNING: - As with all mechanical components, the bicycle is subjected to wear and high stresses. Different materials and components might react to wear or stress fatigue in different ways. If the design life of a component has been exceeded, it may suddenly fail, possibly causing injuries or death to the rider. Any form of crack, scratches, or change of colouring in highly stressed areas indicate that the life of the component has been reached and it should be replaced.
- Page 3 Product Manual Assembly Below is a list of the specific “standards” that parts fitted to the Highlander frame must adhere to. You must refer to the specific product instructions provided with any parts you fit to the Highlander. Interface Standard/Information 29”, Boost: 148mm x 12mm...
- Page 4 Product Manual Maintenance Service Intervals: Bolt torque summary: Ever Ever Part Torque (Nm) y 50 hour ride Main Pivot Bolt Action Notes Pull Link to Rocker Bolt ◆ Clean and lube chain We recommend to refrain from wax chain lubricants Pull Link to Rear Triangle Bolt ◆...
- Page 5 Cable Grommet TRP04-F9-026 Deviate Cycles can happy to supply any spares that you may need for your bike, but some items such as bearings and seals can be sourced from you local bearing dealer. For all other frame related spares please contact us or check the online store. The use of non-genuine parts is not recommended and would void the warranty associated with Deviate products.
- Page 6 Product Manual Front Triangle Assembly ITEM PART NUMBER NAME NOTES Loctite 243 TRP04-F9-XXX FRAME - CARBON TRP04-F9-010 CLAMP - CABLE GUTTER Loctite 638 TRP04-F9-011 TOP HAT - PIVOT TRP04-S9-035 SPACER TUBE - MAIN PIVOT Greas TRP04-F9-016 SLEEVE - FRAME BOLT TRP04-F9-017 BOLT - SLEEVE FRAME TORQUE TO 10 Nm...
- Page 7 Product Manual Rear Triangle Loctite 243 ITEM PART NUMBER NAME NOTES Loctite 638 TRP04-S9-014 REAR SWING ARM TRP04-S9-029 AXLE - MAIN PIVOT LOCTITE THREADS WITH 243 Greas TRP04-D9-007 IDLER - SIDE PLATE TRP04-S9-020 INSERT - M15 LOCTITE OUTER FACE WITH 638 TRP04-D9-008 DROP OUT - 12X148 TRP04-D9-009...
- Page 8 Product Manual ITEM PART NUMBER NAME NOTES Rocker 1 TRP04-S9-016 ROCKER - 140MM 2 TRP04-S9-015 LINK - 140MM 3 TRP04-F9-011 TOP HAT - PIVOT 4 TRP04-F9-013 TOP HAT - BB 5 TRP04-S9-019 AXLE BOLT - SWINGARM LINK TIGHTEN TO 20Nm 6 TRP04-S9-030 AXLE - SWING ARM LINK TIGHTEN TO 30Nm...
