SK BRU5-1-240-050
Footprint braking resistor for connection
to a NORDAC PRO SK 500P
Pos: 6 /Allgemein/Hinweise (Gefahr, Warnung, Vorsicht und Allgemein)/Hinweis Inbetriebnahme durch Elektrofachkraft @ 13\mod_1472545292234_388.docx @ 344669 @ @ 1
It only is allowed for qualified electricians to install and commission the module. An electrician is a person
who, because of their technical training and experience, has sufficient knowledge relating to
• switching on, switching off, isolating, earthing and marking power circuits and devices,
• proper maintenance and use of protective devices in accordance with defined safety standards.
Pos: 7 /Allgemein/Hinweise (Gefahr, Warnung, Vorsicht und Allgemein)/Gefahr/Gefahr eines elektrischen Schlags @ 13\mod_1472544803791_388.docx @ 344601 @ @ 1
DANGER!
Danger of electric shock
The frequency inverter continues to carry hazardous voltages for up to 5 minutes after it was switched
off.
• Work must not be carried out unless the device has been disconnected from the voltage and at
least 5 minutes have elapsed since the mains was switched off!
Pos: 8 /Allgemein/Hinweise (Gefahr, Warnung, Vorsicht und Allgemein)/Vorsicht/Verbrennungsgefahr @ 13\mod_1472546485907_388.docx @ 344740 @ @ 1
CAUTION
Danger of burns
The module and all other metal components can heat up to temperatures above 70 °C.
• Sufficient cooling time must be allowed for when working on the components in order to avoid injuries
(local burns) to parts of the body coming into contact with the components.
• In order to avoid damage to neighbouring objects, sufficient clearance must be maintained during
installation.
Pos: 9 /Allgemein/Hinweise (Gefahr, Warnung, Vorsicht und Allgemein)/Achtung/Gültigkeit des Dokuments @ 13\mod_1472545201279_388.docx @ 344635 @ @ 1
NOTICE
Validity of this document
This document is only valid in combination with the operating instructions for the relevant frequency
inverter. Safe commissioning of this module and the frequency inverter depends on the availability of
this information.
Pos: 10 /Technische Informationen/Bremswiderstände/Unterbau- Bremswiderstände [SK 5xxP]/BRU5/Basisinformation I-Teil [SK BRU5-1-...] @ 33\mod_1554798372247_388.docx @ 2526572 @ 55 @ 1
Technical Information / Datasheet
Brake resistor
Part number: 275 299 004
SK BRU5-1-240-050
275299004 1.0 0821 en
