Fusion FS-RX4DF/35 Operating Instructions

Intelligent Receiver
Digitally Filtered Signal & Transmitter Recognition Circuit
FS-RX4DF/35
FS-RX6DF/35
Thank you for purchasing this receiver. We are sure you will be pleased with its
performance and features. In order to ensure that you obtain the maximum benefit
from its operation, please read the instructions carefully.
OpErAting instructions
Frequency
No. of Channels
Dimensions
Weight
Voltage
Approximate Current Drain
• Integrated Digital Rx Filter which suppresses signals which are not within the
permissible servo signal width, and also filters out unwanted interference
peaks.
• Switch the receiver on and the integrated Transmitter Recognition Circuit
remembers the number of channels and the signal repeat rate of the
transmitter and then only passes values to the servo output, if the signal
matches the same stored characteristics, which is an extremely effective way
of suppressing interference from other transmitters.
• The Digital Rx Filter and Transmitter Recognition Circuit can be switched on
and off.
35MHz FM (PPM)
Please keep for Future Reference

SpECIFICATIOnS

FS-RX4DF/35
35 MHz FM (PPM)
43.4 x 21.0 x 12.8mm
11.5g
4.8V ~ 6V
8mA

FEAturEs

Intelligent Receiver 4ch 35FM
Intelligent Receiver 6ch 35FM
4
FS-RX6DF/35
35 MHz FM (PPM)
6
43.4 x 21.0 x 12.8mm
12.5g
4.8V ~ 6V
8mA
