Instruction Manual
ESDP30A Scroll Pump
Description
ESDP30A Scroll Pump, 3-phase, 200/208/230/380-460 V, 50/60 Hz
ESDP30A Scroll Pump, 1-phase, 100/115/200/230 V, 50/60 Hz
Edwards High Vacuum International
Manor Royal, Crawley, West Sussex, RH10 2LW, UK
Telephone: (01293) 528844 Fax: (01293) 533453 Telex: 87123 Edivac G
A710-99-880
Issue A
Item Number
A710-03-908
A710-03-910
Advertisement
Table of Contents
Related Manuals for Edwards ESDP30A
Summary of Contents for Edwards ESDP30A
- Page 1 Issue A Instruction Manual ESDP30A Scroll Pump Description Item Number ESDP30A Scroll Pump, 3-phase, 200/208/230/380-460 V, 50/60 Hz A710-03-908 ESDP30A Scroll Pump, 1-phase, 100/115/200/230 V, 50/60 Hz A710-03-910 Edwards High Vacuum International Manor Royal, Crawley, West Sussex, RH10 2LW, UK...
-
Page 2: Table Of Contents
Connect the pump-inlet to the vacuum system Connect the pump-outlet 3.10 Leak test the pump installation OPERATION Start-up Shut-down MAINTENANCE Introduction Inspect the inlet screen Service STORAGE AND DISPOSAL Storage Disposal SPARES AND ACCESSORIES Introduction Accessories RETURN OF EDWARDS EQUIPMENT ESDP30A Scroll Pump... - Page 3 Illustrations Figure Title Page The ESDP30A Scroll Pump (3-phase pump shown) Dimensions (mm): 3-phase pump shown Pumping speed (m Pumping speed (cfm) Motor terminal-box low-voltage configuration: 3-phase pumps Motor terminal-box high-voltage configuration: 3-phase pumps Motor terminal-box low-voltage configuration: 1-phase pumps...
-
Page 4: Introduction
Description Refer to Figure 1 in the following description. The ESDP30A Scroll Pump is a compact, reliable vacuum pump which is suitable for use on clean processes. The ESDP30A pump is not suitable for use with explosive, flammable, toxic or corrosive substances, or substances which contain particulates, or powders. - Page 5 11. Locating dowels (2 off) Lifting-eye 12. Direction of rotation arrow Motor terminal-box 13. Motor end-cover Hours counter 14. Mounting-holes (4 off) Outlet-port 15. Base-plate Bolts (4 off) 16. Jacking hole Figure 1 - The ESDP30A Scroll Pump (3-phase pump shown) ESDP30A Scroll Pump...
-
Page 6: Technical Data
Noise level (at 1 m from the pump) 3-phase pump < 60 dB(A) 1-phase pump < 62 dB(A) Vibration velocity < 1.5 mm.s Materials exposed to vacuum PTFE (polytetrafluoroethylene) impregnated aluminium , stainless steel, steel bearings, PFPE (perfluoropolyether) grease, fluoroelastomer seals. ESDP30A Scroll Pump... - Page 7 Electrical supply voltage 50 Hz Full load current rating: A 60 Hz 50 Hz 1430 1430 1450 Motor rotational speed: r.min 60 Hz 1720 1740 1720 1740 Table 2 - Full load current ratings and motor speed: 1-phase pumps ESDP30A Scroll Pump...
- Page 8 Inlet-port (NW40) Pump Alternative inlet-port position 1-phase Outlet-port (NW25) Alternative outlet-port position 3-phase 4 x mounting holes for M8 bolts Figure 2 - Dimensions (mm): 3-phase pump shown ESDP30A Scroll Pump...
- Page 9 60 Hz 60 Hz 50 Hz 50 Hz Figure 3 - Pumping speed/pressure graph (m 60 Hz 60 Hz 50 Hz 50 Hz Figure 4 - Pumping speed/pressure graph (cfm) ESDP30A Scroll Pump...
-
Page 10: Installation
• A suitably trained and supervised technician must install your ESDP30A pump. • Ensure that the installation of the pump conforms with all the requirements of your local and national safety standards. -
Page 11: Unpack And Inspect
8. Use the five bolts removed in Step 3 to secure the body of the pump to the motor. 9. Use the four bolts removed in Step 2 to secure the fan cover to the body of the pump. 10. Turn the pump over so that it rests on the base-plate (15). ESDP30A Scroll Pump... -
Page 12: Locate The Pump
Introduction Connect the electrical supply to the motor as described in Section 3.6.2 or 3.6.3. Connect the supply through a contactor which incorporates a circuit breaker suitable for the full load current ratings given in Section 2. ESDP30A Scroll Pump... -
Page 13: Connect To 3-Phase Pumps
Figures 7 or 8, depending on your electrical supply voltage, then connect the earth wire in the cable to the earth stud in the terminal-box. 6. Tighten the cable-gland. 7. Connect the wires at the other end of the cable to your electrical supply. ESDP30A Scroll Pump... -
Page 14: Motor Terminal-Box Low-Voltage Configuration: 3-Phase Pumps
Figure 5 - Motor terminal-box low-voltage configuration: 3-phase pumps Figure 6 - Motor terminal-box high-voltage configuration: 3-phase pumps ESDP30A Scroll Pump... -
Page 15: Motor Terminal-Box Low-Voltage Configuration: 1-Phase Pumps
Figure 7 - Motor terminal-box low-voltage configuration: 1-phase pumps Figure 8 - Motor terminal-box high-voltage configuration: 1-phase pumps ESDP30A Scroll Pump... -
Page 16: Check The Direction Of Motor Rotation
Step 1 to ensure that the direction of rotation is now correct. • On a 1-phase pump, do not use the pump. Contact your supplier or Edwards for advice. Connect the pump-inlet to the vacuum system Ensure that debris does not get into the pump when you install it. If the pump is to replace a pump in an existing system, purge the existing pump with nitrogen for 15 minutes before you disconnect it. -
Page 17: Connect The Pump-Outlet
Leak test the pump installation and seal any leaks found to prevent the leakage of dangerous substances from the system and the leakage of air into the system. When supplied, the leak tightness of the pump is less than 1 x 10 mbar.ls (1 x 10 Pa.ls ESDP30A Scroll Pump... -
Page 18: Operation
Note: When you switch off the pump, the cooling-fan may stop and then rotate in the reverse direction for a few revolutions. Use the procedure below to shut down the pump. 1. Close the vacuum system isolation-valve (to prevent suck-back into the vacuum system). 2. Switch off the electrical supply to the pump. ESDP30A Scroll Pump... -
Page 19: Maintenance
Service We recommend that the ESDP30A pump is serviced by Edwards service engineers at least once a year (if the pump is in continuous use) or every 8500 hours of pump operation; contact your supplier or Edwards to arrange these services. -
Page 20: Storage And Disposal
Kingdom, U.S.A and a worldwide network of distributors. The majority of these centres employ Service Engineers who have undergone comprehensive Edwards training courses. Order spare parts and accessories from your nearest Edwards company or distributor. When you order, state for each part required: •... - Page 21 ESDP30A Scroll Pump...
