- Page 1 Thon Studio Side Rack 10U Studio Rack...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 21.07.2022, ID: 547450, 547455, 547457, 547460, 547461...
-
Page 3: Table Of Contents
Table of contents Table of contents Safety instructions..........................................5 Scope of delivery........................................... 6 Installation..............................................7 Technical specifications........................................14 Protecting the environment......................................15 Thon Studio Side Rack 10U Studio Rack... - Page 4 Thon Studio Side Rack 10U Studio Rack...
-
Page 5: Safety Instructions
Safety instructions Safety instructions DANGER! Danger for children Ensure that plastic bags, packaging, etc. are properly disposed of and are not in the reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the product. They could swallow the pieces and choke! Never let children play unattended with the product. -
Page 6: Scope Of Delivery
Scope of delivery Scope of delivery Before you assemble your rack, make sure the contents of package is complete according to the following list. 2 × side panel, melamine-coated 19 mm furniture board 1 × floor panel, melamine-coated 19 mm furniture board 1 ×... -
Page 7: Installation
Installation Installation Place all components on a suitable mounting surface for mounting. Use a soft padding to prevent damages to the surfaces. Overview The following figure shows an overview of the individual components. ö & Left side panel Connector bolt Right side panel Connector housing Thon Studio Side Rack 10U... - Page 8 Installation Base panel Wooden dowel Cover panel Woodscrew for rack rail Front panel Raised countersunk screw 4,8×16 Base Rack rail 10 U Furniture caster Thon Studio Side Rack 10U Studio Rack...
- Page 9 Installation Preparing the components Insert the connector housings, the connecting bolts and the wooden pegs into the holes provided in the components, as shown in the figure below. Position all connector housings so that the respective connecting bolts can be completely sunk into the holes and the arrow posi‐ tion of the connector housings points towards the hole.
- Page 10 Installation & Left side panel Base Right side panel Connector bolt Base panel Connector housing Cover panel Wooden dowel Front panel Thon Studio Side Rack 10U Studio Rack...
- Page 11 Installation Assembling the components Place the base panel, the base and the front panel onto the connecting bolts of the left side panel. Tighten the connector housings clockwise to lock the connection with the inserted connecting bolts. & ö Left side panel Front panel Base panel Base...
- Page 12 Installation Place the cover panel onto the connecting bolts of the left side panel. Tighten the connector housings clockwise to lock the connec‐ tion with the inserted connecting bolts. Place the right side panel on the pre-assembled unit consisting of the left side panel, base plate, base, front panel and cover plate. Tighten the connector housings clockwise to lock the connection with the inserted connecting bolts.
- Page 13 Installation Set the fully assembled unit onto the rack rail front. Screw the four casters into the holes provided in the base panel , each with four raised countersunk screw. Set up the rack. Screw the rack rails to the inside of the rack, parallel to the front edge, using six wood screws each. We recommend a distance of approx.
-
Page 14: Technical Specifications
Technical specifications Technical specifications Thon Studio Side Rack 10U WH, white Item number 547450 Thon Studio Side Rack 10U BK, graphite Item number 547455 Thon Studio Side Rack 10U oak Item number 547457 Thon Studio Side Rack 10U beech Item number 547460... -
Page 15: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging material For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 16 Notes Thon Studio Side Rack 10U Studio Rack...
- Page 17 Notes Thon Studio Side Rack 10U Studio Rack...
- Page 18 Notes Thon Studio Side Rack 10U Studio Rack...
