- Page 1 866.332.2403 (TOLL FREE) (707) 640.29.05 (Option 4) Direct Line for the Design Department; 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE TI AMO BENCHES...
- Page 2 Insert the carriage bolts into the holes and lightly tap with a hammer until the square neck fit in the wood piece and the bolt head must flush with the wood piece. Finally, place the washer and the nut and carefully tighten it using a ratchet with the necessary socket or a wrench. P| 1 TI AMO BENCHES www.ForeverRedwood.com...
- Page 3 Place the washers in their lag bolts. After that, insert the lag bolts into the holes and carefully tighten it using a ratchet with the necessary socket. Use the washers only for the Wood Pieces. To install the deck screws. Insert the deck screws into the holes and carefully tighten it using a drill. P| 2 TI AMO BENCHES www.ForeverRedwood.com...
- Page 4 Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent. HARDWARE LIST Description Drawing 3/8´´ X 4 ½´´ Bolts 3/8´´ X 5 ½´´ Bolts 3/8´´ X 3 ½´´ Bolts Note: Dimensions of your hardware will vary depending on size. P| 3 TI AMO BENCHES www.ForeverRedwood.com...
- Page 5 DESCRIPTION Legs Seat Backrest Front Support Diagonal Supports Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent. P| 4 TI AMO BENCHES www.ForeverRedwood.com...
- Page 6 Step 2: Attach the backrest (3) to the legs with 5/16´´ x 4 ½´´ bolts (BL1). Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 5 TI AMO BENCHES www.ForeverRedwood.com...
- Page 7 Step 4: Use 5/16´´ x 3 ½´´ bolts (BL3) to attach the diagonal supports (5) to the seat. After that, use 5/16´´ x 5 ½´´ bolts (BL2) bolts to attach to the legs. Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 6 TI AMO BENCHES www.ForeverRedwood.com...
- Page 8 This completes the outdoor assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 7 TI AMO BENCHES www.ForeverRedwood.com...
