GEMS SENSORS & CONTROLS
OPERATING & INSTALLATION INSTRUCTIONS
CE MARKED SERIES 40XXX
PLEASE READ CAREFULLY BEFORE INSTALLING
PART NUMBER:
560550-0110
ISSUE: F
INTRODUCTION
Series 40XXX are fluid pressure measuring transducers in which a four active arm Wheatstone
bridge of thin film gauges, integral with a beam structure connected to a pressure summing
diaphragm, is used to convert fluid pressures into a proportional electrical signal.
These
instruments are suitable for long, continuous arduous service when operated within the published
specifications.
Series 40XXX conform with the essential protection requirements of the EMC Directive
2004/108/EC amended by certified type testing to EN 61326-1 and EN 61326-2-3.
Series 40XXX with the CE0086 mark also complies with the requirements of the Pressure
Equipment Safety Regulations 2016 and can be used as part of a safety-related system on
Category IV pressure equipment.
Conformity with the requirements of the CE mark only applies when the installation
conditions described in these instructions have been met. For units supplied without a
cable assembly connection to the transducer must be accomplished using Gems Sensors
approved cable. see APPROVED CABLE section.
All instruments conform to the appropriate specifications and/or drawings applicable and have
been subjected to relevant strict quality control procedures.
HAZARDOUS PRODUCTS
The Consumer Protection Act of 1987, Section 6 of the Health and Safety at Work Act 1974 and
the Control of Substances Hazardous to Health Regulations 1988 require that we advise
recipients and users of our products of any potential hazards associated with their storage,
handling or use.
The products which our Company supplies may be classified as Electrical, Electro-Mechanical
and Electronic equipment.
These products are tested and supplied in accordance with our published specifications or
individual special requirements that are agreed in writing at time of order. They are constructed
so as not to affect adversely the safety of persons and property when properly installed,
maintained and used by qualified personnel, in the applications for which they were designed and
manufactured
560550-0110
Issue F
Page 1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Gems Sensors & Controls 4000K Series
- Page 1 GEMS SENSORS & CONTROLS OPERATING & INSTALLATION INSTRUCTIONS CE MARKED SERIES 40XXX PLEASE READ CAREFULLY BEFORE INSTALLING PART NUMBER: 560550-0110 ISSUE: F INTRODUCTION Series 40XXX are fluid pressure measuring transducers in which a four active arm Wheatstone bridge of thin film gauges, integral with a beam structure connected to a pressure summing diaphragm, is used to convert fluid pressures into a proportional electrical signal.
-
Page 2: Mechanical Installation
ACTION ON RECEIPT Check details on Calibration Certificate agree with data etched on transducer body. Check accessories supplied include: Calibration Certificate (or QA Certificate) Seal, Dowty Bonded Mating Connector (where applicable) GENERAL Transducer should not be subjected to greater than the maximum allowable pressure (P.S.) / Temperature (T.S) as defined on the transducer label. -
Page 3: Electrical Installation
499207-0006 G1/8 bonded seal up to +200°C operation. Dowty Ref: 300-020-0967-02 Refer to Dowty for external pressure ratings. Mounting: Pressure Transducer is designed to be attached by the coupling thread only. Omni- directional. To fit, use a 22.2 mm (7/8 inch) AF spanner on the hexagon provided and apply maximum torque of 27 Nm (20 lbf-ft). -
Page 4: Approved Cables
Types 40XXX-XX-M2-U: These types are supplied with colour-coded flying leads and are intended for users/suppliers wishing to hold stocks of pressure ranges to which various lengths of cable can be fitted. Connection MUST be made via Gems Sensors cable assembly part number 560509;... -
Page 5: Maintenance
sealed reference; reference side of the instrument is sealed and the output electrically adjusted to zero with 1013 mb applied to pressure port uni-directional differential bi-directional differential CHARACTERISTICS Millivolt Output Transducers: All millivolt (mV) output transducers should be used with a stabilised d.c. -
Page 6: Warranty
The instrument may withstand some excess pressure without failure, but a change in residual output may result. If this is not excessive the instrument may be re-zeroed externally, although other changes in characteristics might occur which can only be determined by total re-calibration. Failure can also occur if the system is driven into resonance by a fast pressure pulse, even though the pulse peak is within the nominal pressure range. -
Page 7: Electrical Requirements
W A R N I N G * IF INSTRUMENT IS SUBJECTED TO +400°C PLUS Some instruments use Viton sealant. Above +400°C this material decomposes producing (amongst others) Hydrofluoric Acid which is extremely corrosive * DO NOT ALLOW CONTACT WITH SKIN If it is suspected that an instrument has been subjected to temperatures in excess of +400°C CONTACT OUR SALES OR SERVICE DEPARTMENT TO... - Page 8 560550-0110 Issue F Page 8 of 8...
