Ethernet Port

Ethernet Port
A OFF: No activity
BLINKING: Activity
Pin Description
1 TX OUT +
2 TX OUT -
Operating Instructions
B ON: Valid link hast NOT been detected
OFF: Valid link has been detected
Pin Description
3 RX OUT +
4
16
Pin Description
5
6 RX OUT -
Pin Description
7
CP650, CP660, CP675
