Summary of Contents for Gossen MetraWatt E-Clip 1
- Page 1 User manual E-Clip 1 / E-Clip 2 20 751 208 3-349-447-03 Current Clamps 1/11.20...
- Page 2 Do not use the current clamp if any damage is noticed! Do not leave open nodes of the current clamp with current output (E-Clip 1, E-Clip 2) during measurement to avoid damage and electric shock on secondary side, never enclose conductor in the jaw unless the clamp is connected to measuring instrument! ...
- Page 3 E-Clip 1 / E-Clip 2 Current Clamps Description of current clamps The E-Clip 1and E-Clip 2 are 1000/1 ratio current clamps for measuring alternating currents in the range from 1 mA to 1000 A (depending on the type). They can be connected to any power analyzer, energy analyzer, harmonics analyzer, multimeter, earth resistance meters, electrical installation testers and other measuring instruments with compatible voltage or current inputs.
- Page 4 E-Clip 1 / E-Clip 2 Current Clamps 3.2. Cleaning Use a soft cloth moistened with soapy water or alcohol to clean non-metallic surface of the current clamps and leave them to dry totally before using it. Notes! Do not use liquids based on petrol or hydrocarbons! ...
- Page 5 E-Clip 1 / E-Clip 2 Current Clamps Clamp current transformer must always have a low impedance load on its secondary side. This loading is realized with an A-meter (for current sensors with current output). Current clamp with voltage output already contains the load resistor and its output voltage is proportional to measured current.
- Page 6 E-Clip 1 / E-Clip 2 Current Clamps Specifications 5.1. General purpose current clamp with current output Type: E-Clip 2 Rated current: 1000 A Current ratio : 1000:1 Output:1 mA/A, safety banana sockets 4 mm Electrical characteristics (at R = 1 ): Measuring range: 0.2 A ÷...
- Page 7 E-Clip 1 / E-Clip 2 Current Clamps Influence of conductor position <0.3 % at f < 400 Hz 2 to 10 : 1 % and 1 Influence of loading: Influence of DC current offset: <2.5 % for I < 15 A 5.3.
- Page 8 This address is only valid in Germany. Please contact our representatives or subsidiaries for service in other countries. Product Support When you need support, please contact: Gossen Metrawatt GmbH Product Support Hotline Phone +49 911 8602-931 +49 911 8602-709 E-Mail support@gossenmetrawatt.com ...
