ENGLISH
1.
Switch trigger
2.
Outer sleeve
3.
Screw
4.
Inner sleeve
5.
Pin
6.
Tip rod
7.
Tip rod spring
8.
Inner sleeve spring
SPECIFICATIONS
Max. normal torque
No load speed (min
Dimensions (L x W x H)
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2014
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
.... Read instruction manual.
.............. DOUBLE INSULATION
Intended use
The tool is intended for fastening "tor-shear type" high
tensile bolts.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
General power tool safety
warnings
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
4
Explanation of general view
9.
There should be no gap between
the outer sleeve and the tool.
10. Bolt tip
11. Nut
12. Notched portion
13. Tip ejector (Tip lever)
14. Identification mark
15. Bolt
Model
Bolt size
-1
)
Net weight
Safety class
Save all warnings and
END201-7
instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
ENE038-1
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
ENF002-2
to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
GEA012-2
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
16. Chamfered
17. Washer
18. Remaining length
19. Limit mark
20. Screwdriver
21. Brush holder cap
6924N
M22, M24
1,100 N·m
19
330 mm x 104 mm x 257 mm
7.5 kg
/II
