Panasonic LUMIX DMC-FS5EB Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Digital Camera
  5. LUMIX DMC-FS5EB
  6. Service manual
Panasonic LUMIX DMC-FS5EB Service Manual

Panasonic LUMIX DMC-FS5EB Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DMC-FS5P
Model No.
DMC-FS5PC
DMC-FS5PL
DMC-FS5PR
DMC-FS5E
DMC-FS5EB
DMC-FS5EE
DMC-FS5EF
DMC-FS5EG
DMC-FS5GC
DMC-FS5GK
DMC-FS5GN
DMC-FS5GT
DMC-FS5GJ
Vol. 1
Colour
(S)...........Silver Type
(K)...........Black Type (except PR)
(A)...........Blue Type (only P)
(R)...........Red Type (except PC/PL/PR/EE/GN/GT)
© 2008 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
ORDER NO. DSC0802005CE
B26
Digital Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIX DMC-FS5EB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic LUMIX DMC-FS5EB

Summary of Contents for Panasonic LUMIX DMC-FS5EB

  • Page 1 ORDER NO. DSC0802005CE Digital Camera DMC-FS5P Model No. DMC-FS5PC DMC-FS5PL DMC-FS5PR DMC-FS5E DMC-FS5EB DMC-FS5EE DMC-FS5EF DMC-FS5EG DMC-FS5GC DMC-FS5GK DMC-FS5GN DMC-FS5GT DMC-FS5GJ Vol. 1 Colour (S)...Silver Type (K)...Black Type (except PR) (A)...Blue Type (only P) (R)...Red Type (except PC/PL/PR/EE/GN/GT) © 2008 Matsushita Electric Industrial Co., Ltd. All rights reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precaution -------------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1.)--------3 1.4. How to Discharge the Capacitor on Flash Top PCB------------------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1.

  • Page 3: Safety Precaution

    1 Safety Precaution 1.1. General Guidelines 1.3. Leakage Current Hot Check (See Figure 1.) 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The Capacitor On Flash Top Pcb

    1.4. How to Discharge the Capacitor on Flash Top PCB CAUTION: 1. Be sure to discharge the capacitor on FLASH TOP PCB. 2. Be careful of the high voltage circuit on FLASH TOP PCB when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and Remove the necessary parts/unit. 2.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 6: Caution For Ac Cord(For Eb

    2.3.2.3. How to Replace the Fuse A replacement fuse cover can be purchased from your local Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 7: How To Replace The Lithium Battery

    2.4. How to Replace the Lithium Battery 2.4.1. Replacement Procedure 1. Remove the MAIN PCB. (Refer to Disassembly Procedures.) 2. Remove the Lithium battery (Ref. No. “B9101” at foil side of MAIN PCB) and then replace it into new one. NOTE: This Lithium battery is a critical component.

  • Page 8: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.

  • Page 9: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.4. How to Define the Model Suffix (NTSC or PAL model) There are five kinds of DMC-FS5, regardless of the colours. • a) DMC-FS5P/PC • b) DMC-FS5E/EB/EF/EG/GN • c) DMC-FS5EE • d) DMC-FS5GT/GK • e) DMC-FS5PL/GC/PR/GJ What is the difference is that the “INITIAL SETTINGS” data which is stored in Flash ROM mounted on Main PCB. 3.4.1.
  • Page 10 3.4.2. INITIAL SETTINGS: When you replace the Main PCB, be sure to perform the initial settings after achieving the adjustment by ordering the following pro- cedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
  • Page 11 • Step 5. Set the INITIAL SETTING: (Refer to “CAUTION 1”) [Caution for befor settings] Once "NONE(JAPAN)" (Area for Japan) or "P" (Area for Noth America) is selected with "INITIAL SETTINGS", other areas will not displayed even if "INITIAL SETTINGS" menu is displayed again, thus, the area can not be changed. Select the area carefully.

  • Page 12: Specifications

    4 Specifications...

  • Page 13: Location Of Controls And Components

    5 Location of Controls and Components...

  • Page 15: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (when the unit is powered on by the battery, the battery is pulled out) because the error code is memorized to FLASH ROM when the unit is powered off.
  • Page 16 • 5. How to read the error code: One error code is displayed for 8 bit, the contents of error codes is indicated the table as shown below. Attribute Main item Sub item Error code Contents (Upper) High 4 bits Low 4 bits Check point (Lower) LENS Lens drive...
  • Page 17 Attribute Main item Sub item Error code Contents (Upper) High 4 bits Low 4 bits Check point (Lower) HARD VENUS A/D Flash 28*0 0000 Flash charging error. IC6001-(AC17) signal line or Flash charging circuit FLASH ROM FLASH ROM 2B*0 0001 EEPROM read error (EEPROM (EEPROM...

  • Page 18: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit.

  • Page 19: When Replacing The Main Pcb

    7.2. When Replacing the Main PCB After replacing the MAIN PCB, be sure to achieve adjustment. The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-PAVC” web-site in “TSN system”, together with Maintenance software. 7.3. Service Position This Service Position is used for checking and replacing parts.

  • Page 20: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart 8.2. PCB Location...

  • Page 21: Disassembly Procedure

    8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit Item Removal Rear Case Unit Fig.D1 Card Battery 1 Screw (A) 3 Screws (B) 1 Lock A 2 Locks B Fig.D2 FP9004(Flex) FP9103(Flex) Rear Case Unit LCD Unit Fig.D3 2 Locking tabs LCD Unit Front Case Unit Fig.D4...
  • Page 22 8.3.3. Removal of the Front Case Unit Fig.D4 8.3.4. Removal of the Top Operation Unit Fig.D2 8.3.2. Removal of the LCD Unit Fig.D3 Fig.D5...
  • Page 23 8.3.5. Removal of the Flash Top P.C.B. Fig.D7 Fig.D6...
  • Page 24 8.3.6. Removal of the Lens Unit 8.3.7. Removal of the Main P.C.B. Fig.D9 8.3.8. Removal of the SD FPC Unit Fig.D8 Fig.D10...
  • Page 25 8.3.9. Removal of the Battery Case Unit 8.3.11. Removal of the Battery Door Unit Fig.D13 NOTE: (When Assembling) Be sure to confirm the following points when assembling. • The Screw is tightened enough. • Assembling conditions are fine. (No distortion, no illegal- space.) •...

  • Page 26: Disassembly Procedure For The Lens

    8.4. Disassembly Procedure for the Lens NOTE: When Disassembling and Assembling for the Lens 1. To minimize the possibility of the CCD being dirt, perform disassemble and/or assemble under the condition of the CCD is being mounted. Disassembling procedures for the CCD unit, refer to item 8.6.
  • Page 27 8.4.2. Removal of the Master Flange Unit 8.4.3. Removal of the 1st Lens Frame/2nd Lens Frame Move Unit 8.4.4. Removal of the 2nd Lens Frame Move Unit...

  • Page 28: Assembly Procedure For The Lens

    8.5. Assembly Procedure for the 8.5.2. Phase alignment of the Drive/Direct Unit and Fixed Frame Unit Lens 8.5.1. Phase alignment of the Direct Frame and Drive Frame Unit...
  • Page 29 8.5.3. Assembly for the 1st Lens Frame 8.5.4. Assembly for the 2nd Lens Frame Unit and Drive/Direct/Fixed Frame Move Unit and Drive/Direct/Fixed Unit Frame/1st Lens Frame Unit...

  • Page 30: Removal Of The Ccd Unit

    8.6. Removal of the CCD Unit 8.5.5. Assembly for the Master Flange Unit and Drive/Direct/Fixed Frame/ To prevent the CCD unit from catching the dust and dirt, do not 1st Lens Frame/2nd Lens Frame remove the CCD unit except for replacing. Move Unit...

  • Page 31: Removal Of The Focus Motor Unit

    8.7. Removal of the Focus Motor 8.8. Applyment Grease Unit Method The grease apply point of lens unit are as follows. Apply grease additionally in the specified position if necessary. When the grease is applied, use a toothpick and apply thinly. •...

  • Page 32: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Matrix Chart for Replaced Part and Necessary Adjustment The relation between Replaced part and Necessary Adjustment is shown in the following table. When concerned part is replaced, be sure to achieve the necessary adjustment(s). As for Adjustment condition/procedure, consult the “Adjustment Manual” which is available in Adjustment software. The Adjustment software is available at “TSN Website”, therefore, access to “TSN Website”...

  • Page 33: Maintenace

    10 Maintenace 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the their surface. Note: The Lens Cleaning KIT ;...
  • Page 34 DSC0802005CE S1. About Indication of The Schematic Diagram Service Manual S1.1. Important Safety Notice COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS Diagrams and Replacement FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS USE ONLY THE SAME TYPE. 1.Although reference number of the parts is indicated on the P.C.B. drawing and/or Parts List schematic diagrams, it is NOT mounted on the P.C.B.

  • Page 35: S2. Voltage Chart

    S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1.

  • Page 36: S3. Block Diagram

    S3. Block Diagram S3.1. Overall Block Diagram (33mm ~ 132mm) IC3001 PRE PROCESS X6001 (24MHz) 1/2.33" 10 MEGA PIX CDS, AGC, A/D, TG, CCD DRIVER ZOOM OIS UNIT IRIS SHUTTER FOCUS CARD IC9101 SYSTEM IC MOTOR DRIVE, OIS DRIVE& IC9101 MICROPHONE PRE PROCESS SYSTEM IC...

  • Page 37: S4. Schematic Diagram

    S4. Schematic Diagram S4.1. Interconnection Diagram ET8001 FLASH TOP P.C.B. M8001 (COMPONENT SIDE) : (FOIL SIDE) MICROPHONE PS8001 ET8002 P8002 SPEAKER BATTERY FP9005 SDCD SDDAT2 SDDAT3 SDCMD SDDAT0 SDDAT1 SDWP SD FPC UNIT D GND D GND D GND SDCLK FRAME GND FRAME GND FRAME GND...

  • Page 38: S4.2. Flash Top Schematic Diagram

    S4.2. Flash Top Schematic Diagram CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 1.25A 32V FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 1.25A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MÉME TYPE 1.25A 32V. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 1.5A 32V FUSE.

  • Page 39: S4.3. Sd Flex Schematic Diagram

    S4.3. SD Flex Schematic Diagram DMC-FS5 SD Flex Schematic Diagram...

  • Page 40: S4.4. Ccd Flex Schematic Diagram

    S4.4. CCD Flex Schematic Diagram DMR-FS5 CCD Flex Schematic Diagram...

  • Page 41: S4.5. Lens Flex Schematic Diagram

    S4.5. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE ENC VCC LED CONT PHOTO CO. BARREL ENCODER SENSOR XVO+ (FULL RETRACT) XVH- HALL SENSOR (X) XVO- XVH+ OIS UNIT XDRV- DRIVE COIL (X) XDRV+ STAP STAP DC SOLENOID STBN (IRIS) STBN STAN STAN SHUTTER UNIT...

  • Page 42: S5. Print Circuit Board

    S5. Print Circuit Board S5.1. Flash Top P.C.B. (Component Side) (Foil Side) DMC-FS5 Flash Top P.C.B.

  • Page 43: S5.2. Sd Flex P.c.b

    S5.2. SD Flex P.C.B. / S5.3. CCD Flex P.C.B. (Component Side) (Foil Side) (Foil Side) DMC-FS5 DMC-FS5 SD Flex P.C.B. CCD Flex P.C.B. S-10...

  • Page 44: S5.4. Lens Flex P.c.b

    S5.4. Lens Flex P.C.B. CO. BARREL ENCODER (FULL RETRACT) A3 A2 SHUTTER UNIT ZOOM MOTOR UNIT OIS UNIT Pin 1 ZOOM ENCODER 2 ZOOM ENCODER 1 Pin 45 FOCUS MOTOR UNIT DMC-FS5 LENS FLEX P.C.B. S-11...
  • Page 45 S-12...

  • Page 46: S6. Replacement Parts List

    S6. Replacement Parts List Note: 1.* Be sure to make your orders of replacement parts according to this list. 2. IMPORTANT SAFETY NOTICE Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. 3.
  • Page 47 DMC-FS5P/PC/PL/PR/EB/EE/EF/EG/E/GC/GK/GN/GT/GJ Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ------ P.C.B. LIST ------ VEP58052A FLASH TOP P.C.B. 1 (RTL) E.S.D.[PAVCSG] VEK0L78 CCD UNIT 1 E.S.D. --- INDIVIDUAL PARTS --- C8003 F2A2F9500002 E.CAPACITOR 1 [PAVCSG] ET8003 VMB4149...
  • Page 48 DMC-FS5P/PC/PL/PR/EB/EE/EF/EG/E/GC/GK/GN/GT/GJ Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks LB8001 J0JCC0000415 FILTER 1 [PAVCSG] M8001 L0CBAA000012 MICROPHONE UNITS 1 [PAVCSG] P8002 K4ZZ03000334 BATTERY CATCHER 1 [PAVCSG] PS8001 K1KB30AA0123 CONNECTOR 1 [PAVCSG] Q8001 B1JBLP000015 TRANSISTOR 1 E.S.D.[PAVCSG] Q8009...
  • Page 49 DMC-FS5P/PC/PL/PR/EB/EE/EF/EG/E/GC/GK/GN/GT/GJ Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VGQ9871 CCD SHEET VXW0918 LENS UNIT(W/O CCD) VEK0L83 SD FPC UNIT VDL2046 OPTICAL FILTER VEP56057A MAIN P.C.B. 1 (RTL)E.S.D. VEK0L78 CCD UNIT 1 E.S.D. ...
  • Page 50 DMC-FS5P/PC/PL/PR/EB/EE/EF/EG/E/GC/GK/GN/GT/GJ Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPF1224 CAMERA BAG 1 P,PC  201 DE-A39BA BATTERY CHARGER 1 P,PC  202 ---- BATTERY 1 P,PC K1HA08CD0007 USB CABLE W/PLUG 1 P,PC K1HA08CD0008 AV CABLE W/PLUG 1 P,PC VFC4297...
  • Page 51 DMC-FS5P/PC/PL/PR/EB/EE/EF/EG/E/GC/GK/GN/GT/GJ Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYQ3914 BATTERY CARRYING CASE U 1 (EXCEPT P/PC/GK) VPF1224 CAMERA BAG 1 (EXCEPT P/PC) VYQ4384 BATTERY CARRYING CASE U 1 GK  301 DE-A39BA BATTERY CHARGER 1 PL...

  • Page 52: S7. Exploded View

    S7. Exploded View S7.1. Frame and Casing Section 33-1 33-2 12-2 12-1 S-19...

  • Page 53: S7.2. Camera Lens Section

    S7.2. Camera Lens Section B100 B109 B101 B102 114-1 B103 114-2 B105 B104 114-3 113-3 B106 B107 B108 113-2 113-1 S-20...

  • Page 54: S7.3. Packing Parts And Accessories Section (1

    S7.3. Packing Parts and Accessories Section (1) S-21...

  • Page 55: S7.4. Packing Parts And Accessories Section (2

    S7.4. Packing Parts and Accessories Section (2) (DMC-FS5E/EE/EF/EG/GC/GJ) (DMC-FS5EB/GC) (DMC-FS5GK/GT) (DMC-FS5GN/PR) S-22...
