WARNING
• Recommendation: Installation and fitting
of this product should be carried out by
an experienced and competent installer.
• We have not supplied ceiling fixings
with this product. All ceilings differ
in strength and thickness. Consult
a qualified installer.
• Check the components list and
images to check there are no missing
or defective parts.
• Never exceed the Maximum
Weight Capacity.
• Read these instructions carefully before
installation. If in any doubt about safely
installing this product, contact
a professional installer for assistance.
• This product was designed to be
installed on wood ceilings and solid con-
crete/brick ceilings. When fixing
to ceilings screws/bolts should be fixed
into bricks/stone not into
mortar courses.
• Make sure the ceiling will support the
combined load of the equipment and
hardware. Also check for hidden
wiring or plumbing.
• Make sure that the heads of the screws/
bolts you buy as wall fastenings are the
correct size to hold the bracket securely
in position.
• For larger/heavier TVs we recommend
that you ask someone to assist you with
lifting and positioning your TV.
• This product is suitable for indoor
use only.
• Improper installation or use of this
product can result in product failure,
damage or personal injury.
• This product contains small items
that could cause choking if swallowed,
so keep these items away from
children and pets.
• Appropriate safety equipment and
proper tools must be used for
installation. Always check manufacturer's
operating and safety instructions before
using tools and other equipment.
• Check that the bracket is secure
and safe to use at regular intervals
(at least every three months).
UK Distributor: Philex Electronic Ltd.,
London Road, Bedford, MK42 0NX, U.K.
EU Distributor: Philex Electronic Ireland Ltd.,
Robwyn House, Corrintra, Castleblayney,
Co. Monaghan, A75 YX76, Ireland.
USER GUIDE - 28090T
32-55"
Large Display Ceiling TV Mount
• TV Size range: 32-55"
• Maximum weight capacity:
50kg
• Mount function:
Full Motion tilt and swivel
• Extends: 560-910mm
• Compatible with VESA sizes:
200 x 200, 400 x 200,
300 x 300, 300 x 200,
400 x 300, 400 x 400
Advertisement
Related Manuals for THOR 28090T
Summary of Contents for THOR 28090T
- Page 1 WARNING USER GUIDE - 28090T 32-55" Large Display Ceiling TV Mount • Recommendation: Installation and fitting • For larger/heavier TVs we recommend • TV Size range: 32-55" of this product should be carried out by that you ask someone to assist you with an experienced and competent installer.
- Page 2 1a. Preparing Ceiling Fixings - Stud Ceiling 1b. Preparing Ceiling Fixings - Concrete/Brick Ceiling Tools required Tools required The process is the same as for attaching to wood see Fig.2. You will however need to use four suit- The ceiling mount is attached to the ceiling using four appropriate screws/bolts as shown in Fig.2. able screws/bolts/wall plugs for the type of ceiling you are mounting onto (if in doubt ask for advice Make sure the screws/bolts are suitable for wood and large enough to support the weight of the at your local DIY/hardware store and remember to make sure that the heads of the screws/bolts are...
