ELECTRICAL PARTSLIST

MAIN BOARD ASSEMBLY
C24 996510029538
C24 996510029551
D4 996510027488
D7 996500042437
F1 ! 994000001222
IC2 996500039806
IC2 996510014303
IC201 996510006827
IC202 996510029534
IC203 996510006828
IC8 996510018861
Q11 996510021976
Q11 996500040320
Q17 994000004145
Q19 996510020216
Q2 994000004145
Q202 996510003996
Q22 994000004145
U2 996500039808
U3 996510018962
X201 994000004551
XT3 996500042441
POWER/ECO BOARD ASSEMBLY
C66 C66 996510029551 996510029551
D1 996510020774
D37 996510020774
F2 ! 994000004599
IC1 996510000882
J002 994000003661
Q13 996510000337
Q4 996510000337
Q6 996510000337
C301 ! 994000001225
F101 ! 994000001222
Q303 996500040320
RL301 ! 996500039818
T102 ! 996510030965
Note: Only these parts mentioned in the list are
normal service parts.
E.CAP 3300UF 25V (-/98/12)
E.CAP 4700UF 25V +-20% (-/05)
CHIP DIODE SOD323 BZX384-C3V9
CH-DIODE SS14 SMA/DO-214AC
FUSE RADIAL LT 2A 250V
IC UE2314 (-/98/12)
IC UE2314 (-/05)
IC (SANYO) LA6541NHL-TE-L-E
IC (SANYO) LC78603E-8628E
IC (SANYO) LA9242M-MPB-E
IC SI4702
IC LM78L05A (-/98/12)
IC LM78L06 (-/05)
TRANSISTORS B772Y (160-320)
TRANSISTORS D882F
TRANSISTORS B772Y (160-320)
TRANSISTORS KTA1273
TRANSISTORS B772Y (160-320)
IC SM LM324D
IC UTC7805
CRYSTAL 16.9344MHZ +-20PPM
X'TAL 32.768KHZ -20PPM
E.CAP 4700UF 25V +-20% E CAP 4700UF 25V + 20%
SMD DIODE BAS316
SMD DIODE BAS316
FUSE RADIAL T3.15A 250V
IC TFA9842BJ
SPK JACK PT-22V11
SMD TRANSISTORS BC847B (-/98)
SMD TRANSISTORS BC847B (-/98)
SMD TRANSISTORS BC847B (-/98)
SAFETY CAP 275V 0.22UF -20% (-/05/12)
FUSE RADIAL LT 2A 250V (-/05/12)
IC LM78L06 (-/05/12)
RELAY ME-7-006-HSL DC6V AC10A (-/05/12)
TRANSFORMER EI28 230V TO8599A (-/05/12)
10 - 1
