MECHANICAL PARTSLIST

0001 996510029544
0002 996510029553
0003 996510029537
0080 994000005085
110 994000005401
201 996510029545
201 996510030959
202 996510029611
203 996510029548
204 996510029554
205 996510029552
206 996510029547
207 996510029071
208 996500039790
209 996510029536
210 994000004392
211 996510000864
212 996510000865
213 996510029546
214 996510029073
215 996510029021
216 996500039338
217 996510029022
218 996510014364
219 996510029026
233 996510012604
J001 ! 996510029287
J002 J002 994000004629 994000004629
J003 996510019887
J003 996510031305
J004 996510029543
J004 996510012652
S002 994000004376
S003 994000002354
SPR01 996510029539
T001 ! 996510029535
T001 ! 996510030962
ACCESSORIES
RC01 996510029541
0005 996510029549
SPK1 996510029549
J009 ! 996510029404
J009 ! 996510031306
J009 ! 996510000909
J010 996510002103
J010 996510002089
Note: Only these parts mentioned in the list are
normal service parts.
PCBA-MAIN (-/98)
PCBA-POWER/ECO (-/98)
PCBA-DIS/MCU (-/98)
CD MECHANISM DA11B3VZ (BALL)
CD DOOR SPRING
BOTTOM CABINET (-/98)
BOTTOM CAB (-/05/12)
FRONT PANEL
BACK CABINET
IPOD SUPPORT
IPOD SUPPORT BKT
SPRING COVER
PANEL FIXER
FM PIG TAIL HOUSING
CD DOOR
LASER COVER (FOR SANYO CD)
CD GEAR BRACKET
CD GEAR BLK
DOCKING
PANEL BUTTONS
POWER BUTTONS
IR LENS(WHITE)
DISPLAY LENS
SCREW BUSHING (-/12)
TRIM RING
CONNECTOR SLEEVE
AC SOCKET R-201A(B00) BLACK (-/98)
16P FFC CABLE 1MM L=120MM 16P FFC CABLE 1MM L=120MM
10P FFC.1mm L=160mm (-/98)
10P FFC.1MM 120MM (-/05/12)
26P FFC 1mm L=170mm (-/98)
26P FFC 1mm L=110mm (-/05/12)
SWITCH SL14-22AH-5AN (-/98)
CD DOOR SWITCH DLS-02-W-1
DOCK SPRING
TRANSFORMER VDE EI57 127/240V (-/98)
TRANS. EI57 UP57-DCM105AT 230V (-/05/12)
REMORT CONTROL
SPK BOX (SINGLE L/R) (-/98)
SPK BOX (SINGLE L/R) (-/05/12)
AC CORD SET/10A 1.83M VDE APP (-/98)
AC CORD BS PLUG VDE APP 2M (-/05)
AC CORD VDE APP 2M (-/12)
CONN. CORD 3.5 ST/PLUGx2 500mm (-/98)
CONN. CORD 3.5 ST/PLUGx2 500mm (-/05/12)
