Creusen BS 975 HD-B-2n Instructions For Use Manual

The Creusen belt grinder is a Dutch quality product which will give you many years of
useful service, particularly if you closely follow the tips and recommendations given in
these instructions.
Before starting work
Packing
The fully assembled machine is installed on a pallet and is securely packed.
Remove the packing.
Set - up
To ensure optimum use, set up the machine in a position in which it is easily accessible from
all sides. The machine can be placed on a flat floor (also without a foundation). You can fasten
the machine down using bolts with a maximum diameter of 10mm.
After setting up the machine, fit the protective eye shield (13).
Check also that the abrasive belt runs freely.
If you have model BS 975 A/HD-B-2n and BS 9150 A/HD-B-2n, also fit the hose in the front (80 cm) as
well as the rear (50 cm).
You check if a filtermat is placed in the collector tray (18).
The grinder is fitted with a belt for grinding aluminium and stainless steel.
Is the machine prepared with a brake, please follow
the below instructions.
The brake stops the machine within 3 seconds, if connected in star.
If the electrical connections is triangle the stopping time is longer.
Machines with 2- speed motor and integrated brake have the indication B-2n in the type indication,
also a different article number compared to the regular belt grinder.
In this manual following pictograms are used:
Denotes possible personal injury or damage
so the machine if the instructions in this manual
are ignored.
Denotes risk of electrical shock.
Instructions for use
Creusen belt grinder
with 2- speed motor and integrated brake
BS 975 HD-B-2n / BS 9150 HD-B-2n
BS 975A/HD-B-2n / BS 9150A/HD-B-2n
(A = with extraction unit)
