Jackson Tool Threader Stands

Model 224W – Rolling Stand with tray

Model 235W – Rolling Stand with storage box

Model 224W

Assembly, Safety and Operating Manual

This manual is free of charge. All personnel who operate the Rolling Stand should have a copy

of this manual and read and understand its contents. To request a copy, call or write to the

address below. All information, specifications and product designs may change due to design

improvements or updates and are subject to change without notice. Jackson Tool does not

assume any liability for damages resulting from misuse or incorrect application of its products.

JACKSON TOOL • P. O. BOX 5701 • GREENVILLE, SC 29606

877-522-8995 or 864-721-4235 • FAX 864-721-4236 • www.jacksontoolinc.com

Read and understand this material before operating

or servicing the Threader Stand. Failure to

understand how to safely assemble and use this unit

may result in property damage, serious injury or death.

Model 235W

5/22

Table of Contents

Need help?

Do you have a question about the 224W and is the answer not in the manual?

Page 1 All information, specifications and product designs may change due to design improvements or updates and are subject to change without notice. Jackson Tool does not assume any liability for damages resulting from misuse or incorrect application of its products.
Page 2 TABLE OF CONTENTS Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Information .
Page 3 See page 5 for threader CAUTION mounting positions. MODEL DESCRIPTIONS Will fit RIGID ® Model No. Description Model # 224W Rolling Stand with tray 535 – 2001 and newer 1224 235W Rolling Stand with storage box 535 – 2001 and newer 1224 *RIGID is a registerered trademark of Emerson Electric, Inc.
Page 4 ASSEMBLY INSTRUCTIONS Figure 1 1. Attach front and rear cross members (18,20) to side frames (21,22) with 3/8" - 16 × 1" hex head cap screws and 3/8" - 16 hex nuts (6,24) as shown in Figure 1. Be sure crossmembers are assembled as shown in Figure1.
Page 5 THREADER MOUNTING POSITIONS 535-A/535 1224 (Front) Manual-2001 and newer 535-A/535 (Front) Manual-2001 and newer (Rear) 1224 (Rear) Figure 2 NOTE: Front of 535/1224 is oil reservoir end of unit.
Page 6 EXPLODED VIEW – THREADER STANDS...
Page 7 PARTS LIST ITEM # PART # DESCRIPTION QTY. 224-6 WHEEL — 16" 224-7 WASHER — FLAT 3/4" (SAE) 224-8 PIN — COTTER 3/16" X 1-1/4" 224-9 NUT — HEX (1/2"–13) 224-10 WASHER — LOCK 1/2" ZINC 224-11 3/8-16 X 1.0" HEX HEAD SCREW 224-14 SCREW —...
