- Page 1 DEZURIK CYLINDER OPERATOR T-SERIES ACTUATOR D10135 Instruction August 2012 DeZURIK, Inc. Sartell, Minnesota USA | Phone: 320-259-2000 | www.dezurik.com | info@dezurik.com...
- Page 2 Safety label(s) on the product indicate hazards that can cause injury or death. If a safety label becomes difficult to see or read, or if a label has been removed, please contact DeZURIK for replacement label(s). Personnel involved in the installation or maintenance of valves should be constantly alert to potential emission of pipeline material and take appropriate safety precautions.
-
Page 3: Table Of Contents
DeZURIK Cylinder Operated T-Series Actuator Table of Contents Description - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... -
Page 4: Description
DeZURIK Cylinder Operated T-Series Actuator Description The Cylinder Operated T-Series Actuator is an economical actuator capable of providing a long-lasting, dependable means of valve operation. Scotch yoke-series actuators are available in three sizes: Size 3, Size 5 and Size 7. The actuator has been sized to achieve optimum performance from your valve. -
Page 5: Open Position Stop Adjustment
DeZURIK Cylinder Operated T-Series Actuator Closed Position Stop Adjustment (Continued) 2. Pressurize the cylinder so the valve is in the closed position. 3. Loosen the lock nut on the set screw in the cylinder cap. 4. Turn the set screw in or out until the desired closed position is attained. -
Page 6: Removing Actuator
DeZURIK Cylinder Operated T-Series Actuator Removing Actuator 1. Discontinue pipeline flow. 2. If the actuator is powered, disconnect and lock out the pneumatic, hydraulic or electrical power to prevent accidental operation of the actuator. Accidental operation of power actuator can cause personal injury or equipment damage. -
Page 7: Disassembling Actuator
DeZURIK Cylinder Operated T-Series Actuator Disassembling Actuator 1. Discontinue pipeline flow. 2. If the actuator is powered, disconnect and Iock out the pneumatic, hydraulic or electrical power to prevent accidental operation of the actuator. Accidental operation of power actuator can cause personal injury or equipment damage. -
Page 8: Changing Mounting Positions
DeZURIK Cylinder Operated T-Series Actuator Reassembling Actuator (Continued) 13. Perform the Open and Closed Position Stop Adjustments as described in the appropriate Section of this Instruction. 14. Fasten the gasket and cap to the housing. 15. Apply a layer of lubricant approximately 1/2" thick to the appropriate surfaces described in the LUBRICATION Section of this Instruction. - Page 9 If you use metric fasteners with ASME Class 150/300 bolt holes and flange bolt patterns, you do so at your sole risk and any liability associated with such use shall not be the responsibility of DeZURIK, Inc. In addition to the foregoing, DeZURIK’s Manufacturer’s Conditions apply.
