- Page 1 NOEL-ARTYA7-EX Quick Start Guide 2020 User's Manual The most important thing we build is trust NOEL-ARTYA7-EX Quick Start Guide NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
-
Page 2: Table Of Contents
5.6.5. Console driver ....................5.6.6. Memory layout ....................5.6.7. Work area ...................... 5.6.8. Symmetric Multiprocessing ................5.7. Device tree ....................... 5.7.1. Background ....................5.7.2. GRMON ......................5.8. Compiler options ....................... 5.9. Building the kernel ....................NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... - Page 3 8.1.4. coremark ....................8.1.5. Creating a custom application ................8.2. Driver manager examples .................... 8.2.1. Introduction ....................8.2.2. Requirements ....................8.2.3. Build ......................8.2.4. Targets ......................8.2.5. Comments ...................... 8.2.6. Limitations ..................... 9. Support ..........................NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
-
Page 4: Introduction
1. Introduction 1.1. Overview This document is a quick start guide for the NOEL-ARTYA7-EX design. The guide is mainly how-to oriented and does not go into many technical details. For more in-depth information we refer to respective products User's Manual. See the reference list below. -
Page 5: Overview
Linux 64-bit host operating systems. Chapter 5 describes how to use RTEMS with NOEL-ARTYA7-EX. The recommended method to load software onto NOEL-ARTYA7-EX is by connecting to a debug interface of the board through the GRMON hardware debugger (Chapter 4). -
Page 6: Bare C Cross-Compiler
Included in the software development environment is a NOEL-ARTYA7-EX BSP for Buildroot which provides the necessary driver support. See Chapter 7 for instructions on how to create a Linux image for NOEL-ARTYA7-EX with Buildroot. 2.4.4. VxWorks 7 Please contact support@gaisler.com for information about NOEL-V BSPs for VxWorks 7. -
Page 7: Board Configuration
• Ethernet PHY SGMII interface with RJ-45 connector. See (Chapter 4). 3.5. Memories The NOEL-ARTYA7-EX has 256 MiB of SDRAM available on the on-chip bus. 3.6. Programming the bitstream A Xilinx Vivado script to program the FPGA is provided with the bitfile distribution. The bitstream folder contains several bistreams which represent different configurations of the processor (EX1,EX2, ecc.). -
Page 8: Grmon Hardware Debugger
The first step is to set up a debug link in order to connect to the board. The following section outlines which debug interfaces are available and how to use them on the NOEL-ARTYA7-EX design. After that, a basic first inspection of the board is exemplified. -
Page 9: Debug-Link Alternatives
The previous sections have described which debug-links are available and how to start using them with GRMON. The subsections below assume that GRMON, the host computer and the NOEL-ARTYA7-EX board have been set up so that GRMON can connect to the board. -
Page 10: Get System Information
JTAG chain (1): xc7a200t Device ID: 0x291 GRLIB build version: 4258 Detected frequency: 40.0 MHz Component Vendor NOEL-V RISC-V Processor Cobham Gaisler NOEL-V RISC-V Processor Cobham Gaisler AHB-to-AHB Bridge Cobham Gaisler AHB Debug UART Cobham Gaisler JTAG Debug Link Cobham Gaisler... -
Page 11: Debugging With Gdb
Loading section .sdata2, size 0x30 lma 0x400253d8 Loading section .eh_frame, size 0x4 lma 0x40025408 Loading section .init_array, size 0x8 lma 0x40025410 Loading section .fini_array, size 0x8 lma 0x40025418 Loading section .rtemsroset, size 0x68 lma 0x40025420 NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... - Page 12 RTEMS tools: 9.3.0 20200312 (RTEMS 5, RSB 5 (3bd11fd4898b), Newlib 7947581) executing thread ID: 0x08a010001 executing thread name: UI1 Program received signal SIGTRAP, Trace/breakpoint trap. _CPU_Fatal_halt (source=source@entry=5, error=error@entry=0) at /home/user/riscv/leon-rtems/build/../c/src/lib/libbsp/riscv/riscv/ ../../../../../../bsps/riscv/riscv/start/bsp_fatal_halt.c:43 asm ("ebreak"); (gdb) NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
-
Page 13: Rtems Real Time Operating System
RTEMS toolchain for NOEL-V. This section gives the reader a brief introduction on how to use RTEMS together with the NOEL-ARTYA7-EX design. It will be demonstrated how to install the toolchain and build an existing sample RTEMS project and run it on the board using GRMON. - Page 14 RESULT SYMBOL 593660 00007688 a0, 280(a0) [0000000000023128] _Thread_Entry_adaptor_numeric+0x4 593660 0000768c jalr zero, t1 [000000000000768E] _Thread_Entry_adaptor_numeric+0x8 593695 00000118 ebreak BREAKPOINT Init+0x0 593728 00000118 addi sp, sp, -16 [0000000000029D70] Init+0x0 593729 0000011a s0, 0(sp) [0000000000029D70] Init+0x2 NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
-
Page 15: Risc-V And Noel-V Integration With Rtems
The NOEL-V RTEMS BSP variants are similar to the RTEMS mainline BSP variants for RISC-V (rv64imac, etc) available in the kernel source tree directory bsps/riscv/riscv/config. The full list of BSP variants provided with the tool chain is: • noel32i • noel32im • noel32imafd • noel32imafd_smp NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... -
Page 16: Console Driver
Then use the command run as normal to start an RTEMS application, or any other application expecting a device tree: Example 5.2. load and run a RAM image which expects a device tree grmon3> dtb noel-xilinx-artya7.dtb grmon3> load myprogram.elf grmon3> run NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... -
Page 17: Compiler Options
5.9.1. RTEMS test suite Giving the kernel configure option --enable-tests will build the RTEMS kernel test suite, consisting of over 600 tests, together with the kernel. Most tests run correctly on NOEL-V. Cobham Gaisler is currently analyzing NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler... -
Page 18: Building The Tool Chain
Example 5.4. export THE_PREFIX=/opt/my-rtems-noel export THE_RSB_REPO="git://git.rtems.org/rtems-source-builder.git" export THE_RSB_COMMIT=5.1 export THE_RSB_PATCHES=/opt/rtems-noel-1.0.4/0001-noel-multilibs-for-gcc-9.3.0.patch git clone $THE_RSB_REPO rsb pushd rsb git checkout -b noel $THE_RSB_COMMIT git apply $THE_RSB_PATCHES --check git am $THE_RSB_PATCHES popd pushd rsb/rtems ../source-builder/sb-set-builder --prefix=$THE_PREFIX 5/rtems-riscv popd NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... -
Page 19: Bare-Metal Cross-Compiler
C and C++ single-threaded applications. This section gives the reader a brief introduction on how to use NCC together with the NOEL-ARTYA7-EX design. It will be demonstrated how to build an an example program and run it on the NOEL-ARTYA7-EX using GRMON. -
Page 20: Running And Debugging With Grmon
6.6. Running and debugging with GRMON Once your application is compiled, connect to your NOEL-ARTYA7-EX with GRMON. The following log shows how to load and run an application. Note that the console output is redirected to GRMON by the use of the -u command line switch, so that the application standard output is forwarded to the GRMON console. -
Page 21: Linux
Buildroot and how to load and execute a Linux image on hardware using GRMON. Cobham Gaisler provides a BSP for NOEL-ARTYA7-EX which is included in the Buildroot version downloadable from https://www.gaisler.com/NOEL-ARTYA7. The Buildroot BSP contains additional driver support for Linux. - Page 22 40200000 .payload 12.7MB / 12.7MB [===============>] 100% Total size: 12.80MB (97.78Mbit/s) Entry point 0x40000000 Image noelv-buildroot/output/images/fw_payload.elf loaded Load the DTB using the dtb command: grmon3> dtb noel-xilinx-artya7.dtb DTB will be loaded to the stack NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
- Page 23 0.005332] Calibrating delay loop (skipped), value calculated using timer frequency.. 100.00 BogoMIPS (lpj=200000) 0.008901] pid_max: default: 32768 minimum: 301 0.012378] Mount-cache hash table entries: 2048 (order: 2, 16384 bytes, linear) 0.015177] Mountpoint-cache hash table entries: 2048 (order: 2, 16384 bytes, linear) NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
- Page 24 12.229148] random: crng init done Starting syslogd: OK Starting klogd: OK Running sysctl: OK Saving random seed: OK Starting network: OK Welcome to Buildroot buildroot login: You can now log into the system using root as username. NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2...
-
Page 25: Rtems Example Applications
8.1.4. coremark The CoreMark benchmark program from EEMBC. See the file coremark/README.NOEL-V for information on how to set the build parameters. Build for NOEL-V by entering the coremark directory and run the script named build.sh: NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... -
Page 26: Creating A Custom Application
The example binaries will be placed inside the bin directory. 8.2.4. Targets Examples will be built automatically for the following BSP variants: • Single processor BSP variants • noel32i • noel32im • noel32imafd • noel64im NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... -
Page 27: Comments
RTEMS shell. Type help at the prompt to see the available commands. config.c onfigures driver resources, initializes the Driver Manager and BSP Networking Stack. config_*.c is the subsystem configurations. 8.2.6. Limitations The RTEMS TCP/IP network stack provided is considered experimental for 64-bit NOEL-V. NOEL-ARTYA7-EX-QSG www.cobhamaes.com/gaisler December 2020, Version 1.2... -
Page 28: Support
9. Support For support contact the Cobham Gaisler support team at support@gaisler.com. When contacting support, please identify yourself in full, including company affiliation and site name and address. Please identify exactly what product that is used, specifying if it is an IP core (with full name of the library distribution archive file), component, software version, compiler version, operating system version, debug tool version, simulator tool version, board version, etc. - Page 29 Cobham convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual rights of Cobham or of third parties. All information is provided as is. There is no warranty that it is correct or suitable for any purpose, neither implicit nor explicit.
