Thetford Tecma Silence 2G-RV Quick Start Manual

Kit Contents: K1 - K5

K3
K2
K4
K1
K5
New Ref. Description
K1 K1 (1x) Vacuum Breaker
K2 K2 (1x) Flush Tube
K3 K3 (4x) Clamps
K4 K4 (1x) Inlet Tube
K5 K5 (1x) Tie
NI A Nozzle
NI B Toilet
NI Not Included

Tools Needed:

■ Towel(s)
■ Plastic trash bag
■ Pliers
■ Phillips Screwdriver
Thetford Corporation recommends that only a trained and
AVISO AVIS
! ! ! ! NOTICE ATTENTION ATENCIÓN CAUTION DANGER
qualifi ed technician service this product and plumbing
ATTENTION ATTENTION ATTENTION
and electrical work be performed by a licensed tradesper-
son. Local permit and code compliance is required.
Thetford Corporation accepts no responsibility or liability
for damage to equipment, injury, or death that may
result from the system's improper installation, service, or
operation.

PREPARE

• Read all instructions completely.
• Reduce holding tank odor: Rinse toilet with water, drain holding
tank, and add Thetford Holding Tank Deodorant.
• Wear protective gloves, glasses, long sleeves, and nose/face
mask to avoid contact with human waste.
• Wash entire toilet thoroughly.

REMOVE TOILET

1. Turn off RV water supply.
2. Flush toilet to drain.
3. Place towel(s) behind toilet under water connection to catch
water.
4. Disconnect RV water supply from water valve.
5. Remove toilet mounting screws.
P.O. Box 1285
Ann Arbor, MI 48106
www.norcold.com
Tecma® Silence 2G-RV / Silence Plus 2G-RV, High / Low
Vacuum Breaker
A
K3.3
K3.2
K2
Questions? 1-800-543-1219
K1
K3.1
K4
6. Disconnect B from sewer line (not shown) in fl oor.
7. Lift toilet from fl oor and place on trash bag.
8. Cover open sewer line (in fl oor) with rag or towel to reduce
holding tank odor

REMOVE PART

USE OLD PARTS
1. If K5 is present, cut and remove.
2. With pliers, slide clamp
3. Slide K3.2 on K2
4. If is damaged, remove and discard.
K2
5. Discard old parts

REPLACE PART

USE NEW PARTS
1. Slide onto
K3.2
2. Slide K3.3 over
3. Slide over
K2 A
4. Install K3.1 onto
5. Slide onto
K4 K1
6. Secure K1 by threading
Pull K5 to tighten.

REINSTALL TOILET

1. Clean bottom of toilet removing all old caulk; add a fresh
bead of caulk.
2. Place toilet on fl oor; align mounting holes to mounting brack-
ets.
3. Tighten toilet mounting screws until toilet is secure. Do not
overtighten.
4. Connect RV water supply line.
5. Turn on RV water supply.
6. Flush test toilet, checking for leaks at all connections.
Service Kit
Ensemble de réparation
Juego de servicio
B
K1
down ; disconnect from
K3.1 K4
, remove K1 .
K1 , K3 (3x).
. Position with loop on top.
K2 K3.2
K2
; secure with .
K3.3
A .
; secure with .
K3.1
K5 through B and
98303
K5
K3.2
.
K1
K3.2 as shown.
98304A (06.02.2018)
