AMERITECH SecurityLink AM100 Installation Instructions Manual

Hide thumbs Also See for SecurityLink AM100:
Table of Contents

Advertisement

Quick Links

AM100
SECURITY SYSTEM
INSTALLATION
INSTRUCTIONS
N7526-3V1 Rev B 4/99
Ref: 20AMTE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SecurityLink AM100 and is the answer not in the manual?

Questions and answers

Related Manuals for AMERITECH SecurityLink AM100

Summary of Contents for AMERITECH SecurityLink AM100

  • Page 1 AM100 SECURITY SYSTEM INSTALLATION INSTRUCTIONS N7526-3V1 Rev B 4/99 Ref: 20AMTE...
  • Page 2 RECOMMENDATIONS FOR PROPER PROTECTION The Following Recommendations For The Location Of Fire And Burglary Detection Devices Help Provide Proper Coverage For The Protected Premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS GENERAL DESCRIPTION ....................7 Section 1. INSTALLING THE CONTROL.................... . 10 Section 2. Mounting the Cabinet ......................10 Installing the Lock (if used) ....................10 Mounting the Control's Circuit Board Alone in the Cabinet..........11 Mounting Control and RF Receiver Circuit Boards Together in the Cabinet....
  • Page 4 Section 8. 4285 & 4286VIP PHONE MODULES .................32 Installing the Phone Module....................32 General Information ......................32 Mounting The Phone Module ..................32 Phone Module Wiring..................... . 33 Caller ID Units ....................... .33 Checking the Operation of the 4285 or 4286 Phone Module..........35 Section 9.
  • Page 5 Remote Programming Information..................79 Remote Programming Advisory Notes ................79 Section 23. SYSTEM COMMUNICATION .................... . 80 Report Code Formats ......................80 Table of Contact ID Codes....................82 Section 24. SYSTEM OPERATION ......................83 Security Codes ........................83 Keypad Functions......................
  • Page 6 CONVENTIONS USED IN THIS MANUAL MAIN SECTION TITLES ARE SHOWN IN REVERSE TYPE Before you begin using this manual, it is important that you understand the meaning of the following symbols (icons). These notes include specific information which must be followed if you are installing this system for a UL Listed application.

  • Page 7: General Description

    Section 1. GENERAL DESCRIPTION The AM100 is a security system control that supports up to 38 zones, using basic hard-wired, wired expansion, and/or wireless zones, plus 3 keypad activated zones. Basic Hardwired Zones Provides 8 basic hardwired zones having the following characteristics: •...
  • Page 8 Security Codes • One installer code for entire system (user 1) • One Master code for entire system (user 2) • 12 secondary user codes (users 3–14) • One baby-sitter code (user 15) • One duress code (user 16) Baby-sitter Code: A special code that can only be used to disarm the system if that particular code (or the installer code) was used to arm it.
  • Page 9 Optional Long Range Radio • Allows all messages that have been programmed to go to the primary telephone number to be reported additionally to a 7720PLUS or 7820 radio. Check availability of these models. Built-in Telephone Line Monitoring Option • The telephone line voltage can be monitored to supervise the phone line connection.

  • Page 10: Installing The Control

    Section 2. INSTALLING THE CONTROL This section provides instructions for mounting the control cabinet and installing the cabinet lock (if used). Also included in this section are instructions for the following: • Installing the main PC board • Mounting the 5881 (5882 in Canada) RF Receiver board in the cabinet (if used) •...

  • Page 11: Mounting The Control's Circuit Board Alone In The Cabinet

    Mounting The Control's Circuit Board Alone in The Cabinet (Fig. 2) 1. Hang two short Black mounting clips (provided) on the raised cabinet tabs (see Detail B in Fig. 2). 2. Insert the top of the circuit board into the slots at the top of the cabinet. Make sure that the board rests on the correct row (see Detail A ).

  • Page 12: Standard Phone Line Connections

    Standard Phone Line Connections The wiring connections shown here are not applicable if the 4285/4286 Phone Module is used. Refer to the 4285/4286 Phone Module section for information regarding phone line connections, which are different than those shown here. Incoming phone line and handset wiring is connected to the main terminal block (via a RJ31X jack) as follows (also see Figure 4): Term.

  • Page 13: Installing The Back-Up Battery

    b. Wire the other three terminals (Sync, Data, Com) on the 4300 transformer. Wires from these terminals must be connected to a 9-pin connector on the control board (using a 4142TR cable supplied with the 4300 transformer), as shown in Figure 5. These particular wires can be 24 gauge or larger, and can be run along with the AC and ground wires to the control panel.

  • Page 14: Installing Remote Keypads

    Section 3. INSTALLING REMOTE KEYPADS This section lists the wired keypads that may be used and provides instructions for wiring and mounting the keypads. A preliminary check-out procedure is also provided to ensure that the connected keypads are functioning properly in the system. Keypads That May Be Used •...

  • Page 15: Mounting The Keypads

    BLACK GREEN KEYPAD YELLOW CONTROL TERMINALS Figure 6. Keypad Connections To The Control Board Mounting the Keypads 1. Make sure addressable type keypads (AM6128 and AM6139) are set to non-addressable mode (address 31), which is the factory default setting. Refer to the instructions provided with the keypad for address setting procedure.

  • Page 16: Preliminary Check-Out Procedure

    SUPPLEMENTARY CONTROL POWER SUPPLY TERMINAL STRIP – AUX AUX. DATA DATA – IMPORTANT: MAKE THESE CONNECTIONS DIRECTLY TO SCREW TERMINALS AS SHOWN. Figure 7. Using A Supplementary Power Supply For Keypads Preliminary Check-out Procedure If you want to check that the system is working before connecting field wiring from zones and devices, do the following: 1.

  • Page 17: Basic Hard-Wired Zones 1-8

    Section 4. BASIC HARD-WIRED ZONES 1–8 This section provides general information for the hard-wired zones in the system, plus specific instructions for installing 2-wire smoke detectors, 4-wire smoke/combustion detectors, and 2-wire latching type glass break detectors. Installing the Hard-Wired Zones Common Characteristics for Zones 1–8 •...

  • Page 18: Turning Off Fire Alarm Sounding

    You can turn off Fire alarm sounding by pressing the OFF key on any keypad or Turning Off Fire Alarm other arming/disarming device. To clear the "memory of alarm" and to reset the Sounding detector’s alarm, enter the security code plus OFF again. COMPATIBLE 2-WIRE SMOKE DETECTORS System Sensor System Sensor...

  • Page 19: Wiring 2-Wire Latching Type Glass Break Detectors On Zone 8

    COMPATIBLE 4-WIRE SMOKE/COMBUSTION DETECTORS 1412 System Sensor, 4-wire ionization products of combustion detector 2412 System Sensor, 4-wire photoelectric smoke detector 2412TH System Sensor, 4-wire photoelectric smoke detector w/135º F (57º C) heat detector A77–716B System Sensor, EOL relay module (supervisory module for wired 4-wire fire zone).

  • Page 20: Check-Out Procedure For Hard-Wired Zones

    Programming Hard-Wired Zones Each zone must be programmed into the system using the 56 Zone Programming mode, which assigns characteristics that define the way the system responds to faults on that zone. Refer to the Zone Response Type section and the Zone Programming section for specific instructions on programming hard-wired zones.

  • Page 21: Wired Zone Expansion (4219, 4229)

    Section 5. WIRED ZONE EXPANSION This section provides information regarding the use of expansion modules for expanding the number of wired zones in the system, the modules that can be used and their wiring connections. Installing Zone Expansion Units You can add an additional 8 wired EOLR zones to the basic control's 8 zones, for a total of 16 wired zones, by using a No.

  • Page 22: Check-Out Procedure For Wired Expansion Zones

    Programming Wired Expansion Zones Each zone must be programmed into the system using the 56 Zone Programming mode, which assigns characteristics that define the way the system responds to faults on that zone. Refer to the Zone Response Type section and the Zone Programming section for specific instructions on programming wired expansion zones.

  • Page 23: Wireless Zone Expansion (5800 System)

    Section 6. WIRELESS EXPANSION (5800 SYSTEM) This section provides instructions for installing 5800 series wireless receivers and transmitters. General Information In addition to its basic wired zones, the control supports up to 30 wireless zones using an appropriate 5881 (5882 in Canada) type RF receiver. The actual number of zones supported depends on whether you are using a wired zone expander module.

  • Page 24: Installation And Setup Of The 5881/5882 Receiver

    Installation and Setup of the 5881/5882 Receiver 1. Set the receiver's DIP switch for device address “0”, as described in its instructions (all switches to the right. . . “off”). 2. Mount the receiver. The RF receiver can detect signals from transmitters within a nominal range of 200 feet.

  • Page 25: Installing The 5800Tm Module

    Installing the 5800TM Module Installation of this module is necessary only if you are using one or more 5827BD Wireless Bi-directional keypads or 5804BD transmitters. Mounting the 5800TM Module The 5800TM must be located next to the RF receiver (between one and two feet from the receiver’s antennas).

  • Page 26: Transmitter Input Types

    Transmitter Input Types All of the transmitters described have one or more unique factory assigned input (loop) ID codes. Each of the inputs requires its own programming zone (e.g., a 5804's four inputs require four programming zones). See APPENDIX A toward the end of this manual. Transmitters can be enrolled as one of the following types: Type Description...

  • Page 27: 5800 Series Transmitters Table

    5800 Series Transmitters Table Also refer to APPENDIX A near end of this manual for transmitter input loops/button locations. Model Description Input Type And Special Notes 5801 Wireless Panic • Unit has 4 pushbuttons, each with a unique Input (loop) code. Transmitter •...
  • Page 28 Installing 5800 Series Transmitters To be sure reception of the transmitter's signal at the proposed mounting location is adequate, perform a Go/No Go test. Go/No Go Test Mode The Go/No Go tests will verify adequate RF signal strength from the proposed transmitter location, and allow you to reorient or relocate transmitters if necessary, before mounting the transmitters permanently.

  • Page 29: Relay Outputs & Powerline Carrier Devices

    Section 7. RELAY OUTPUTS & POWERLINE CARRIER DEVICES Relay/Powerline Carrier Device Basics Relays and Powerline Carrier devices (ex. X-10 brand devices) are programmable switches that can be used to perform many different functions. They can be used to turn lights on and off, control sounders, or for status indications.

  • Page 30: Powerline Carrier Devices

    4229 RELAY DIP SWITCH RELAY CONNECTOR FOR SETTING ADDRESS AND ZONE “A” RESPONSE EITHER OR BOTH CAN BE USED TERMINALS ON RELAY CONTROL PANEL NO C NC 4-PIN CONSOLE PLUG GRN DATA OUT (TERM 6) TAMPER JUMPER POSITION TO CONTROL 4229 IN CABINET (–) GROUND (TERM 4)

  • Page 31: Wiring Connections

    Wiring Connections 1. Splice one end of a 3-conductor cable to the wire ends of the 4142TR cable supplied with the 4300 transformer. 2. Connect the 4142TR cable plug to the 9-pin connector on the control (see SUMMARY OF CONNECTIONS diagram for location of the 9-pin connector).

  • Page 32: 4285 & 4286Vip Phone Modules

    Section 8. 4285 & 4286VIP PHONE MODULES This section provides instructions for mounting and wiring the 4285 or 4286 Phone Modules. Installing the Phone Module General Information The 4285 or 4286VIP Phone Modules are add-on accessories for the AM100 that permits access to the security system via a Touch-tone phone (either on premises or by a call-in when away).

  • Page 33: Phone Module Wiring

    Phone Module Wiring The 4285 or 4286 phone module is wired between the control panel and the premises handset(s). It listens for touch tones on the phone line and reports them to the control panel. During on-premises phone access, it powers the premises phones;...

  • Page 34: Figure 16. 4285/4286 Phone Module Wiring Connections

    4285/4286 WIRING NOTES: 1. Wire either Phone Module exactly as shown, using a direct-connect cord and RJ31X jack. 2. If Touch-tones are not heard when pressing keys following phone access to the security system via an on-premises phone, try reversing the pair of wires connected to terminals 3 & 4 on either phone module and the pair of wires connected to terminals 21 &...

  • Page 35: Checking The Operation Of The 4285 Or 4286 Phone Module

    Programming the 4285/4286 Phone Module The system must be programmed for use with the 4285 or 4286 Phone Module, including assigning a phone code and selecting words from the alpha vocabulary. Refer to the Programming sections for specific programming details. Checking the Operation of the 4285/4286 Phone Module To Check Phone Module Operation From an On-Premises Phone: 1.

  • Page 36: External Sounders

    Section 9. EXTERNAL SOUNDERS This section provides a list of compatible sounders and connection information for an external sounder. Compatible Sounders Ademco AB-12M 10” Motor bell & box. UL Grade A. 100 mA Motorized Bell & Box current draw. Ademco 1011BE12M Motor bell &...

  • Page 37: Sounder Connections

    Sounder Connections The AM100 provides a 12VDC output which can power external alarm sounders (bells or sirens, see compatible sounders listed previously). This output will activate a sounder when an alarm occurs. Make connections to alarm output terminals 3 (+) and 4 (–). See Figure 17. Non-UL Installations The total current drawn from this output cannot exceed 2 amps.

  • Page 38: Long Range Radio

    Section 10. LONG RANGE RADIO General Information Check availability of Models 7720 PLUS or 7820 long range radios. If output to long range radio is selected, all messages that are programmed to go to the primary telephone line receiver will also be sent to the 7720 PLUS or 7820 long range radio.

  • Page 39: Remote Keyswitch

    Section 11. REMOTE KEYSWITCH This section provides instructions for the connection of an optional remote 4146 keyswitch for remote arming and disarming of the system, and the programming necessary when a keyswitch is used. Also included is a description of how the keyswitch operates in the system.

  • Page 40: Figure 19A. Keyswitch Wiring (4300 Interface Transformer Not Used)

    9 PIN 1 2 3 4 5 6 7 8 9 CONNECTOR ON CONTROL BOARD 4142TR CABLE THESE WIRES NOT (ARMED) CONNECTED IF 4300 INTERFACE TRANSFORMER IS YELLOW NOT BEING USED (READY) (+ AUX POWER) TO 9 PIN GREEN CONNECTOR WHITE YELLOW (NOT USED) 820Ω...

  • Page 41: Programming For The Remote Keyswitch

    Programming For The Remote Keyswitch 1. With one 2-line Alpha keypad (AM6139), enter the programming mode by entering: Installer code + 8 + 0 + 0 keys. If RF zones, wired expansion, or a keyswitch will be used, data fields 22 RF SYSTEM, 25 WIRED ZONE EXPANSION and...

  • Page 42: Keyswitch Operation

    If keyswitch is enabled (in programming 07 Response Time 30 ) , the response is preset to mode, field 350ms. Therefore no entry is required. Press [ ] to continue. Typical summary display A summary display will appear, showing the Zn ZT RC In RT data for zone 07 that was just programmed.

  • Page 43: Audio Alarm Verification (Aav) Unit

    Section 12. AUDIO ALARM VERIFICATION (AAV) UNIT General Information An Audio Alarm Verification (AAV) module, such as the Eagle 1241, is an add-on accessory that permits voice dialog between an operator at a central station and a person at the alarm installation, for the purpose of alarm verification.

  • Page 44: Figure 20. Connection Of Aav Unit When Not Using A 4285 Phone Module

    INCOMING TELCO LINE DIRECT CONNECT CORD RJ31X RING JACK PREMISES ANSWERING MACHINE AND PLUG PHONES ANSWERING TERMINALS MACHINE ON CONTROL EARTH GROUND REFER TO AAV MODULE INSTRUCTIONS FOR CONNECTIONS TO AUDIO SPEAKERS AND MICROPHONE INPUT TRIGGER EAGLE SECURITY RING (TO TERM. 22 ) MODEL 1241 TIP (TO TERM.

  • Page 45: Final Power Up

    Section 13. FINAL POWER UP This section provides information about final power-up procedures and battery size calculations. Earth Ground Connections The designated earth ground terminal (25) must be terminated in a good earth ground for the lightning transient protective devices in this product to be effective.

  • Page 46: Making The Battery Connections

    Making the Battery Connections 1. Use the battery standby formula (above) to select the appropriate battery for the installation. Do not connect the battery until all devices have been wired to the control. 2. Attach the Red and Black wires on the battery connector cable as follows: a) Red to the positive (+) battery tab on the control board.

  • Page 47: Mechanics Of Programming

    Section 14. MECHANICS OF PROGRAMMING This section provides information on how to use the system's programming modes. It will enable you to understand how to enter and exit programming mode, and how to program the data fields and how to use the user-friendly interactive modes ( 56, 83).

  • Page 48: Reviewing A Data Field/Erasing An Entry In A Data Field

    3. If the number of digits that you need to enter in a data field is less than the maximum digits available (for example, the phone number field), enter the desired data, then press [ ] and the next data field number to be programmed.

  • Page 49: Zone Response Type Definitions

    Section 15. ZONE RESPONSE TYPE DEFINITIONS General Information You must assign a zone type to each zone, which defines the way in which the system responds to faults in that zone. Zone types are defined below. Type 00 Program a zone with this zone type if the zone is not used. Zone Not Used Type 01 This zone type provides exit and entry delays whenever the zone is faulted if...
  • Page 50 Type 06 This zone type sends a report to the Central Station but provides no keypad display or sounding. This zone type is usually assigned to a zone containing 24-hour Silent Alarm an Emergency button. Type 07 This zone type sends a report to the Central Station, and provides an alarm sound at the keypad, and an audible external alarm.

  • Page 51: Data Field Descriptions

    Section 16. DATA FIELD DESCRIPTIONS Descriptions of System Data Fields THE BLANK PROGRAMMING FORM SHOULD BE USED TO RECORD THE DATA FOR THIS INSTALLATION Defaults (where applicable) Are Indicated In Text The following pages list all data fields used in this control (in numerical order). If you have performed the programming instructions that were included with the installation of each of the various peripheral devices covered in previous sections, this table will simply serve as a reference for all data fields in the system.
  • Page 52 POWERLINE CARRIER DEVICE (X-10) HOUSE ID Powerline Carrier devices require a House ID. This field identifies this House ID to the control. If Powerline Carrier devices are used, they are selected in field House ID is entered in following manner: 0 = A, 1 = B, 2 =C, 3 = D, 4 = E, 5 = F, 6 = G, 7 = H, 8 = I, 9 = J, # + 10 = K, # + 11 = L, # + 12 = M, # + 13 = N, # + 14 = O, # + 15 = P.
  • Page 53 ALARM BELL TIMEOUT 0 = No timeout 1 = 4 min 2 = 8 min 3 = 12 min 4 = 16 min This field determines whether the external sounder will shut off after time allotted, or continue until manually turned off. UL installations: must be set for a minimum of 4 min (option 1) NOTE: If the fire sounder of 32 is programmed for no timeout with...
  • Page 54 DIALER PABX ACCESS CODE (See Box at Left) PROGRAMMING( 40 – Enter up to 6 digits if PABX is needed to access an outside line. If 44 and fewer than 6 digits are needed to be entered, exit by pressing [ ] and 47 –...
  • Page 55 SPLIT/DUAL REPORTING Use options 0 - 5 when reporting to standard telephone receivers TO PRIMARY TO SECONDAR Y All reports none, unless primary fails, then all Alarms, Restore, Cancel Others All except Open/Close, Test Open/Close, Test Alarms, Restore, Cancel All except Open/Close, Test All reports Use options 6 - 9 when reporting to a pager is desired TO PRIMARY...
  • Page 56 15-SECOND DIALER DELAY (BURGLARY) 0 = no dialer delay 1 = provide 15-second delay of burglary alarm report (except zone type 24) to the central station, which allows time for the subscriber to avoid a false alarm transmission. This delay does not apply to zone type 24 alarms, which are always sent as soon as they occur.
  • Page 57 SYSTEM STATUS EXIT ERROR REPORT CODE (See box on previous page) REPORT CODES If the system is armed and an Entry/Exit or Interior zone is still open ( 59 – 68) after the exit delay time has expired, an alarm will sound at the keypad and external sounder (keypad also displays “Exit Alarm”).
  • Page 58 (See box on page 56). CANCEL REPORT CODE 1 | 0 This is sent upon disarming of the system after an alarm condition was reported. RESTORE ALARM RESTORE REPORT CODE, 1st DIGIT REPORT CODES This is sent when the zone that caused an alarm is restored to its ( 70 –...
  • Page 59 EVENT LOGGING 0 = No event logging 1 = log Alarm/Alarm Restore 2 = log Trouble/Trouble Restore 4 = log Bypass/Bypass Restore 8 = log Open/Close x = log combination of events (add value of entries) Example: To select “Alarm/Alarm Restore”, and “Open/Close”, enter 9 (1 + 8); the selection of “3”...
  • Page 60 DOWNLOAD DOWNLOAD PHONE NUMBER INFORMATION ( 94, Enter up to 20 digits as follows: 0–9, # +11 for “ ”, # + 12 for “#”, # + 13 for a pause. Do not fill unused spaces. End field by entering .

  • Page 61: Zone Programming ( 56 Menu Mode)

    Section 17. ZONE PROGRAMMING 56 Menu Mode) While in program mode, press 56 to enter Zone Programming Menu Mode. Refer to the zone assignment table for 56 on the separate programming form . This is an interactive menu mode that is used to program zone numbers, zone types, alarm and report codes, and to identify the type of loop input device.
  • Page 62 Zone Number (Zn): Enter the zone number that you wish to program Enter Zn Num. (or 00 to exit zone programming). Press [ ] to continue. (00 = Quit) ↑ Zone 20 entered A summary display appears, showing the status of that zone's Zn ZT P RC In: L programming.
  • Page 63 Loop number (LP#): Enter the loop number (1-4) for the zone of the 10 INPUT DEV: LP# transmitter being enrolled. The default is loop "1." To accept this, RF TRANS. RF: 1 press [ ]. If a different loop number is being used on this transmit- ter, enter the desired loop number and press [ ] to continue (see the transmitter's Installation Instructions for specific loop designations).
  • Page 64 The summary screen for the zone will appear. Note that an "s" ZN ZT P RC IN: L indicates that a serial number has, in fact, been enrolled. The cursor 10 03 1 3C RF: 1 s will be flashing above the loop number. Press [ ] to accept the zone information.

  • Page 65: Output Devices ( 80 Menu Mode)

    Section 18. OUTPUT DEVICES ( 80 Menu Mode) Programming Options Defined The following will help you understand the programming of Output Devices when using 80 and 81 modes. The options used to start and stop these devices are described below, followed by the actual screen prompts and available entries.
  • Page 66 If a "SYSTEM OPERATION" is chosen (e.g., End of Exit Time), that operation will cause the device to activate as selected in "ACTION.” The different choices for "ZONE TYPE" and "SYSTEM OPERATION" are listed in “Programming Output Relays & Powerline Carrier Devices” later in this section, and in the Programming Form.
  • Page 67 Programming Output Relaysand Powerline Carrier Devices While in program mode, press 80 to enter Output Device Menu Mode. This mode is used to program all output devices used in the system (4229 or 4204 Relay modules, or Powerline Carrier devices). Refer to the output device table for 80 on the separate programming form when programming output devices.
  • Page 68 Enter 0 for any. 02 Start: Press the [ ] key to continue. If a zone list will be used to STOP, or restore, the device action, enter the 02 Stop: Zn List zone list number 1, 2, or 3 (to be programmed in 81 mode).

  • Page 69: Zone Lists ( 81 Menu Mode)

    Section 19. ZONE LISTS ( 81 Menu Mode) While in program mode, press 81 to enter Zone List Menu Mode. This mode is used to program zone lists for output devices (programmed in menu mode) and/or for defining a common zone. Refer to the Programming Form worksheet for 81 Mode.

  • Page 70: Alpha Descriptor Programming ( 82 Menu Mode)

    Section 20. ALPHA DESCRIPTOR PROGRAMMING This section provides instructions for programming alpha zone descriptors. This is recommended for systems using Alpha keypads, and necessary if a 4285 or 4286 Phone Module is used. If using a 4285/4286 Phone Module, select from those words in the Alpha Vocabulary list shown in boldface type.
  • Page 71 Summary Mode Display Default Descriptor If a descriptor was not entered previously for zone 1, the default ZN 0 1 Z O N E 0 1 descriptor for zone 1 will be displayed. Note that this a “summary mode”, and that no entries can be made. Entries can be made only when the display contains a flashing cursor, which signifies the “entry mode."...
  • Page 72 9. Press “6” to accept the selected ZN 0 1 B A C K word. D O O R NOTE: If these are the only words are using for the descriptor, press “8 ” instead of “6 ” to save them Flashing Cursor if “6”...

  • Page 73: Adding Custom Words

    Adding Custom Words (will not be annunciated by 4285/4286 Phone Module) You can add up to 10 installer-defined words to the built-in vocabulary. Each of the 10 "words" can actually consist of a "word string" of one or more words, but no more than ten characters can be used for each word or word string.

  • Page 74: Alpha Vocabulary List (For Entering Zone Descriptors)

    ALPHA VOCABULARY LIST (For Entering Zone Descriptors ) NOTE: Use only this list when programming AM100 zone descriptors. (Word Space) • 064 DUCT LOCK SHOCK • 227 LOOP • 170 SHOP • 228 • 001 SHORT • 229 • 065 EAST •...

  • Page 75: Using Sequential Mode ( 83 Menu Mode)

    Section 21. USING 83 SEQUENTIAL MODE 83 Sequential mode when a wireless transmitter is to be physically added, removed, or simply changed (as when replacing a unit that has a non-removable battery). By using this mode, you can add, delete, or change the serial number of a transmitter in a zone, but retain all other existing data that has been programmed for that zone.
  • Page 76 5. This prompt is displayed when the system has found the next zone 10 INPUT S/N: L which needs to be enrolled. The system will respond to the first serial Axxx xxxx number transmitted after the [ ] key on the keypad is pressed. A serial number may be enrolled by one of two methods: a) Enter the 7 digit serial number printed on the transmitter b) Activate the transmitter by faulting or restoring the input you...
  • Page 77 When the system sees activity on the appropriate input, it will beep 10 CONFIRMED three times and display the confirmation message. Press [ ] or the A022-4064 3 upper left-hand button of the program tool when you are ready to enroll the next transmitter.

  • Page 78: Remote Programming And Control (Downloading)

    Section 22. REMOTE PROGRAMMING AND CONTROL (DOWNLOADING) General Information The AM100 can be remotely programmed from an IBM compatible Personal Computer (PC), a HAYES modem, and Ademco's V-LINK® Software (as specified below). Downloading may only be performed if a technician is at the site. Programming the control from a remote location is protected against compromise by someone attempting to defeat the system, using multi-levels of security protection:...

  • Page 79: Remote Programming Information

    Remote Programming Information The downloading system can perform many functions when in communication with the control unit. Besides uploading and downloading, the status of the system can be observed and various commands can be initiated, as follows: • Arm the System in the Away Mode; Disarm the System. •...

  • Page 80: System Communication

    Section 23. SYSTEM COMMUNICATION This section provides an explanation of formats this system accommodates for reporting alarms and other system conditions to the central station. The process of a successful transmission consists of both the method of communication between the control panel and the central station receiver and the actual way the information is sent and displayed at the central station.
  • Page 81 The following describes each format in greater detail. 3+1 and 4+1 Standard Formats Comprise a 3- (or 4-) digit subscriber number and a single digit report code (e.g. Alarm, Trouble, Restore, Open, Close, etc). 3+1 and 4+1 Expanded Formats Comprise a 3- (or 4-) digit subscriber number, and a two-digit report code.

  • Page 82: Table Of Contact Id Codes

    Ademco Contact ID Reporting takes the following format: CCCC Q EEE ZZZ where: CCCC = Customer (subscriber) ID Q = Event qualifier, where: E = new event , and R = restore EEE = Event code (3 hexadecimal digits) Note: For a complete list of event codes, refer to the central office receiver manual.

  • Page 83: System Operation

    Section 24. SYSTEM OPERATION Security Codes Installer Code The installer programs the 4-digit Installer Code initially as part of the programming procedure. The factory default Installer code is " 4-1-1-2 ", but may be changed in field 20. The Installer code is the only code that can enter programming mode and also, in normal operation mode, is used to enter the Master code which allows access to the normal functions of the system.

  • Page 84: Keypad Functions

    Arming Maximum ..Enter code + [4] = A R M E D M A X I M U M (Ameritech does NOT advertise this capability.) Arming Instant ....Enter code + INSTANT [7] = HOME INSTANT Disarming ......Enter code + OFF [1] = **SYSTEM READY** Bypassing Zones .....
  • Page 85 SUMMARY OF ARMING MODES Features for Each Arming Mode Arming Exit Entry Perimeter Interior Delay Delay Armed Armed Mode AWAY HOME INSTANT MAXIMUM *This feature is not advertised in order to prevent false alarms by the user while at home with ALL protected zones (interior and exterior) armed. Panic Keys There are three panic key pairs that can be used to manually initiate alarms and send a report to the central station.

  • Page 86: Trouble Conditions

    (See Troubleshooting Guide on page 89 also) Trouble Conditions General Information The word "CHECK" on the Keypad's display, accompanied by a rapid "beeping" at the Keypad, indicates that there is a trouble condition in the system. The audible warning sound can be silenced by pressing any key. Instruct users to call for service immediately upon seeing any of the following messages.

  • Page 87: Testing The System

    Section 25. TESTING THE SYSTEM Test Procedure After installation is completed, the Security System should be carefully tested, as follows. 1. With the System in the disarmed state, check that all zones are intact. If a NOT READY message is displayed, press the [ ] key to display the faulted zone(s).

  • Page 88: To The Installer

    • When one button of a transmitter (RF, UR, or BR) is activated, all zones assigned to other buttons on that transmitter are cleared. This also applies to 5816 and 5817 transmitters which have multiple loops (zones). • Any transmitter that is not “enrolled” will not turn off its zone number.

  • Page 89: Troubleshooting Guide

    Section 26. TROUBLESHOOTING GUIDE S Y S T E M ( i n c l u d i n g W i r e l e s s ) SYMPTOM POSSIBLE CAUSE REMEDY Transmitter signal not 1a. Transmitter or 5881/5882 not properly Check or change transmitter's battery.
  • Page 90 TROUBLESHOOTING GUIDE (cont’d) C O N T R O L SYMPTOM POSSIBLE CAUSE REMEDY "AC POWER" light off. 1a. Interrupted AC power supply. 1a. Check transformer connection and Powerline circuit breaker. Digital communicator 2a. AM100 in TEST mode. 2a. Remove from TEST mode. message not being received.

  • Page 91: Contacting Technical Support In The Event Of Problems

    • Note the proper model number of this product, and the version level (if known) along with any documentation that came with the product. • Note your AMERITECH customer number and/or company name. Having this information handy will make it easier for us to serve you quickly and effectively.

  • Page 92: Regulatory Agency Statements

    REGULATORY AGENCY STATEMENTS UL NOTICE: This is a "Grade A" residential system. FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.

  • Page 93: Specifications & Accessories

    Section 27. SPECIFICATIONS & ACCESSORIES Specifications AM100 1. Physical: 12-1/2" W x 14-1/2" H x 3" D (318mm x 368mm x 76mm) SECURITY 2. Electrical: CONTROL VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, Ademco No. 1321 (in U.S.A.) RECHARGEABLE BACK-UP BATTERY: 12VDC, 4AH (Gel type). Charging Voltage: 13.8VDC.
  • Page 94 1. Physical: 6-1/4" W x 4-3/4" H x 1" D (159mm x 121mm x 26mm) AM6139 REMOTE KEYPAD 2. Electrical: Voltage Input: 12VDC; Current Drain: 100mA 3. Interface Wiring: Same as AM6128. 5881/5882 SERIES 1. Physical: 7-3/8" (188mm) W x 4-3/8" (112mm) H x 1-7/16" (37mm) D RF RECEIVERS Note: 10-7/8"...

  • Page 95: Accessories (Compatible Devices)

    Accessories (Compatible Devices) No. 1321 16.5VAC, 25VA Plug-In Transformer No. 4300 Powerline Carrier device Interface AC Transformer Sounders Ademco AB-12M 10” Motor bell & box. UL Grade A. 100 mA current Motorized Bell & Box draw. Ademco 1011BE12M 10” Motor bell & box. UL Listed. 100 mA current Motorized Bell &...

  • Page 96: Appendix A. 5800 Rf System Wireless Transmitters, Input Loop Identification Diagrams

    APPENDIX A. 5800 RF System Wireless Transmitters Transmitter Input Loop Identification 5800 Series Transmitter Input Loop Identification • All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the input loops requires its own programming zone (e.g., a 5804's four inputs require four programming zones).

  • Page 97: Index

    1-minute delay ............ 45 5890 ..............27 1011BE12M ............36 6127 7 1321 ............9, 12, 45 AM6128............ 14, 15, 94 1321 AC transformer ..........8 6137 7 1321 transformer ..........30 6137 1400 ..............95 6138 1412 ............... 19, 95 AM6139..........
  • Page 98 Battery Life ............26 EXIT ERROR REPORT CODE ......57 Battery Size ............45 Expanded or 4+2 Format ........56 battery standby formula ........46 Factory Defaults ..........48 bells ............... 7 fast busy signal ........... 34 button transmitters ..........25 FCC ..............
  • Page 99 NUMBER OF REPORTS ........59 Secondary User Codes ........83 Off-Premises Phone ..........35 Security Codes ............ 83 On-Premises Phone ..........35 Sequential mode ........... 60, 75 OPEN REPORT CODE ........57 numbers .............. 48 Optima 24 Plus FAX96 Modem ......78 serial number ..........
  • Page 100 X-10 type..............9 X-10 ..............68 Zone Descriptors ........... 9 Zone Descriptors..........74 Zone Expansion ..........21 Zone List ............. 48 Zone Not Used ............ 49 Zone Programming ..........48 zone type ............. 62 Zone Type Default ..........62 Zone types ............. 49, 67 –100–...
  • Page 101 – NOTES – –101–...

  • Page 102: Limitations Of This Alarm System

    WARNING THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example: •...

  • Page 103: Summary Of Connections

    ADEMCO No. 4219 SET UNIT’S DIP BATTERY FUSE GEL LEAD ACID TYPE. WIRED EXPANSION MODULE SWITCH FOR AUX PWR FOR REPLACEMENT, BATTERY NORMALLY NEED NOT BE (8 ADD'L EOLR WIRED ZONES) DEVICE OUTPUT USE SAME VALUE 9-PIN CONNECTOR – REPLACED FOR AT LEAST 3 YRS. -OR- ADDRESS TERMS...

  • Page 104: Limited Warranty

    ADEMCO LIMITED WARRANTY Alarm Device Manufacturing Company, a Division of Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants its products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for 24 months from the date stamp control on the product or, for products not having an Ademco date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.
