Powelectrics IN4MA Metron-p Technical Manual And Specifications

Pulse counting GSM/GPRS Telemetry Solution
Technical Manual and Specification
Proprietary Notice:
The information in this document is subject to change without notice. Company or product names
mentioned in this document may be trademarks or registered trademarks of their respective
companies.
All rights reserved. Neither the whole nor any part of the information contained in this publication
may be reproduced in any material form except with the written permission of Powelectrics Ltd.
This publication is intended only to assist the reader in the use of the product. Powelectrics Ltd.
shall not be liable for any loss or damage arising from the use of any information in this publication,
or any error or omission in such information, or any incorrect use of the product.
© 2007 Powelectrics Ltd.
Technical Manual and Specification..........................................................................1
WARNINGS .........................................................................................................................................4
OVERVIEW..........................................................................................................................................7
NAVIGATION BASICS ........................................................................................................................7
GETTING STARTED ........................................................................................................................... 8
CONNECTIONS................................................................................................................................. 10
CONFIGURATION ............................................................................................................................. 13
Programming Specification............................................................................................................. 14
Important points to note .................................................................................................................. 14
The text message format ................................................................................................................. 14
Command Number 1 – Programming the phone book ................................................................. 15
Command Number 2 – Configuration of the system settings ...................................................... 15
Command Number 4 – Changing the password............................................................................ 16
Command Number 5 – Clearing the configuration........................................................................ 17
Command Number 6 – Requesting Configuration and Status ..................................................... 17
Important points to note .................................................................................................................. 18
Reset Confirmation text message format ...................................................................................... 19
© 2007 Powelectrics Ltd.
IN4MA Metron-p
Revision 0.99p-b
August 2008
Powelectrics Ltd
Sandy Hill Park
Sandy Way
Tamworth
Staffordshire
B77 4DU
United Kingdom
Tel: +44 (0)1827 310 666
Fax: +44 (0) 1827 310 999
www.powelectrics.co.uk
sales@powelectrics.co.uk
1
3
METRON FIRMWARE REVISION HISTORY
Version Date
0.99 13/07/2007 Metron P introduced to Metron range
This version of the Metron has a plug in board fitted into the D type connector on the front of
the main circuit board. This additional board incorporates the real time clock with a battery
backup. When the main battery is connected the real time clock draws it power from this, but
when power is removed the small on board battery takes over and this has a life of 4 years.
© 2007 Powelectrics Ltd.
WARNINGS
Safety
Read carefully these instructions and notes before powering IN4MA Metron. For each
situation please follow the specific instructions.
The Metron is a low power radio transmitter and receiver. When it is powered, it will send and
receive radio frequency (RF) signals.
Operating the Metron close to other electrical equipment such as television, phone, radios
and personal computer, may cause interference.
DO NOT CONNECT ANYTHING TO THE 9 PIN D TYPE
CONNECTOR ON THE FRONT OF THE BOARD
WITHOUT PRIOR APPROVAL FROM POWELECTRICS
LIMITED.
Interference
The Metron, like all wireless devices, is subject to interferences that may reduce its
performance.
Road Safety
Do not use the Metron while driving. In case of use on cars, it is necessary to check that
electronic equipment is shielded against RF signal. Do not place the Metron over the air bag
or in the air bag deployment area.
Hospital Safety
Do not use the Metron near health equipment, especially pacemaker and hearing aids, to
avoid potential interferences. The Metron is a not mobile phone; do not use it in direct contact
with the human body. Switch it off in hospitals, and in any other type of medical centre.
Hospitals or health care facilities may be using equipment that could be sensitive to external
RF energy.
Explosive Materials
Do not use the Metron in refueling points, near fuel or chemicals. Do not use the Metron
where blasting is in progress. Observe restrictions, and follow any regulation or instruction.
Do not use the Metron in direct contact with the human body; do not touch the antenna if not
necessary when the Metron is powered. Use approved accessories and batteries only. Do not
connect incompatible products.
© 2007 Powelectrics Ltd.
Comments
2
4
