Iqinvision IQeye Sentinel Series IQeye855 Specifications

IQeye Sentinel
Megapixel Outdoor IP Camera
Features
>
Resolutions up to 5 MP, HD1080p (832)
> H.264 Main Profile + MJPEG Compression
> 30 fps @ 1.3 MP, 10 fps @ 5 MP
> 30 fps @ HD1080p (832)
> Day/Night Movable IR Filter on 85x and 832N
> Lightgrabber™ II Low-light Feature
>
Power Over Ethernet, 12-24VDC, 24VAC
> IP66 / NEMA 4 Outdoor Enclosure
> Outdoor Camera with Mounting
> ONVIF and PSIA Compliant (832)
> 3 Year Warranty
Available in 1080p H.264 Main profile and 1.3, 2, 3
and 5 MJPEG models, the Sentinel Series provides
the flexibility to monitor any outdoor area, including
parking lots, building exteriors, campus perimeters
and warehouses. The all-weather Sentinel Series
cameras were designed with the installer in mind.
The innovative features like Ethernet terminal punch-
down (eliminating the need to terminate with an
RJ45 connector) and brass camera hangers allow
the installer to work with both hands at once saving
time and money while eliminating frustration. The
wall, ceiling and parapet mounting options, rugged
aluminum construction and IP66 weather resilience
allow the camera to be installed virtually anywhere,
especially harsh environments. At less than 7W
power consumption, the Sentinel can be fully
operational using only Power-over-Ethernet.
