ASSEMBLY

CAREFULLY READ AND PERFORM ALL ASSEMBLY INSTUCTIONS ON THE FOLLOWING PAGES.
Tools Required:
• Adjustable wrench (not provided)
• #2 Phillips Screwdriver (not provided)
• The following hardware is provided:
Item No.
A
B
C
D M4 x 10mm Shoulder Bolt
E
F
G
H
I
J
Item Name
M5 x 12mm Bolt
M5 x 60mm Bolt
M4 x 8mm Bolt
Hinge Rod
Cotter Pin
M5 Nut
M10 Lock Nut
M10 Flat Washer
M5 Spring Washer
Diagram Qty
44 pcs
8 pcs
3 pcs
2 pcs
2 pcs
2 pcs
8 pcs
2 pcs
2 pcs
4 pcs
9
