CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when it is not in use.
Dust regularly with small brush or vacuum. Spills should be taken
care of immediately before they harden or stain with a slightly
dampened sponge.
NOTICE
Please make sure that you have all parts indicated before you
begin assembly of this item.
Part List and Hardware List
PIECE
DESCRIPTION
A
Seat
B
Right side
C
Left side
D
Back
Joint bar
E
F1
Allen screw
F2
Allen bolt
F3
Allen Key
F4
Wrench
QUANTITY
1x
1x
1x
1x
2x
8x
M6x70
4x
M6x35
1x
1x
MODEL
#
PAT
6753
Product Dimension: 45.28"W x 24.8"D x 34.61"H
Weight capacity : 600 lbs
Warning : Do not stand on the bench
Warning : Do not torque bolts / screws
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Safavieh Outdoor Ruben PAT6753
Summary of Contents for Safavieh Outdoor Ruben PAT6753
- Page 1 CARE AND MAINTENANCE Store outdoor furniture indoors or cover well when it is not in use. Dust regularly with small brush or vacuum. Spills should be taken care of immediately before they harden or stain with a slightly dampened sponge. NOTICE MODEL 6753...
- Page 2 PREPARATION Before beginning the assembly of the product, make sure all parts are present. Compare the parts with the package contents list and hardware contents list. If any parts are missing or damaged, do not attempt to assemble the product. Tool required for assembly (included): Allen Key and Wrench.
- Page 3 Step 3: attach the back (D) to the side as shown on the picture use the Step 4: When turning the back side (D),as shown on the picture, Allen bolt (F2) . Tighten by the Allen Key (F3) and wrench (F4) as shown make sure to lock the back (D) on the left side (C).
