Parts List
A
CPU Water Block
BPTA-CPUMS-V2-SKA
A-1
B
Fittings
.................2 pcs
BPTA-DOTFH1622
B-1
....................2 pcs
BPTA-15ATFH16
B-2
C
Accessory
................................2 pcs
Hard tube
C-1
....................1 pc
Fitting + soft tube
C-2
CPU set
C-3
Thumb screw
SPRING
Thumb nut
1mm Spacer
M3x32mm Screw
SC6-32M3
Nylon cup washer
A
..........1 pc
A-1
B
B-1
C
Hard Tube
C-1
※ The allowable variance in tube length is ± 2mm
Fitting + soft tube
C-2
TITAN X_2.0
BPTA-O11D-AK_AMD_A2.0-BK
B-2
252
interpretations. These are subject to change without notice. Product
— 1 —
Installation Guide
Bitspower reserves the right to change the product design and
colors and accessories are based on the actual product.
English
V3
Φ:16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bitspower TITAN X 2.0
Summary of Contents for Bitspower TITAN X 2.0
- Page 1 ※ The allowable variance in tube length is ± 2mm Fitting + soft tube Bitspower reserves the right to change the product design and interpretations. These are subject to change without notice. Product colors and accessories are based on the actual product.
- Page 2 AMD SOCKET 939 / 754 / 940 AMD SOCKET AM4 AMD SOCKET AM3 / AM3+ AMD SOCKET AM2 / AM2+ AMD SOCKET FM1 / FM2+ Bitspower Fan and DRGB RF Remote Controller Hub (Not included) are now available at microcenter.com DRGB PIN on Motherboard ...
- Page 3 II. AMD Chipset Installation Step 1 CPU_FAN AIO_PUMP Step 2 Loosen the screws. Adjust the slider according to the CPU block position. Adjust the hard pipe to the same level as the CPU Block inlet. When installing the hard pipe from the CPU After the hard pipe is installed, please keep the block to the water distribution reservoir, total length between 227-240mm to ensure...
- Page 4 Repeat until all the air has exited the loop. Notice : Do not turn on the pump if the reservoir is empty. Bitspower recommends that consumers add the Bitspower coolant or 90% full purified water for their water-cooling liquid.
