will open a directory box, allowing you to name your settings file. This file will always be saved in the Wavetronix
folder created when you installed Click Supervisor, under Wavetronix > ClickHome > Drivers > 421 > User. You
can also select Save to Device to save your settings to your Click 421.
Note. If you do not save your settings to your Click 421, they will be lost the next time you power the device down.
The Tools menu contains five options for working with your device. Reset > System power cycles your device,
■
while Reset > Factory Default restores your device to the settings with which it was shipped. Restore will restore
the driver to the settings currently saved on the Click 421, erasing any unsaved changes. Upgrade can be used
to manually upgrade to the most current firmware for your device. Hex View changes the view of certain settings
in the driver to hexadecimal.
Clicking the Quit menu exits the driver and returns you to the Click Supervisor main page.
■
Expert
The Expert driver allows you to see all possible settings and fields, both those available in the SmartSensor
driver and those available only through this driver. The driver is divided into three tabs, System, Bluetooth, and
Diagnostics.
The System tab is divided into three subtabs: General, Comm, and Autobaud.
The General subtab contains information about the device (see the figure and table below).
Setting Description
Module Shows the name of the Click device.
Driver Names the driver you are currently working with.
Description
Shows a description of the device being configured. This is only for your information and does not
affect the operation of the device.
Location
Displays the location of the device being configured. This is only for your information and does not
affect the operation of the device.
Serial Number Displays the serial number of your device.
Firmware Version
Shows the version of firmware your device currently has installed. If Click Supervisor detects a
discrepancy between this version and the most current version it currently has access to, you will be
prompted to upgrade when you connect to the device.
Subnet ID
Shows the subnet ID number. This option is currently not available.
