- Page 1 Model #2342VA-31-201-925-UM 2342VA-31-242-925-UM ASSEMBLY INSTRUCTIONS 31 IN. W X 22 IN. D VANITY Questions, problems, missing parts? Before returning to the store, contact Greentouch Home Customer Service 9 a.m. - 5 p.m., EST, Monday - Friday 1-855-571-1044 customerservice@greentouchhome.com...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Pre-Installation . -
Page 3: Warranty
Warranty LIMITED LIFETIME WARRANTY The manufacturer warrants this item against defects in materials and workmanship for a period of one (1) year from the date of original retail purchase. This warranty applies only to the original purchaser. This warranty does not apply to any damage on the product by accident, misuse, or modified, improper installation or by affixing accessories not produced by the manufacturer. -
Page 4: Pre-Installation
Pre-Installation PLANNING INSTALLATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 45 minutes (24 hours for silicone caulk to dry). TOOLS REQUIRED (NOT INCLUDED) Phillips Utility Knife... -
Page 5: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity CARTON Vanity Box 2 of 3 Box 1 of 3 Backsplash Sink Box 3 of 3 Back Stretcher Bar Box 2 of 3 Shelf customerservice@greentouchhome.com Please contact 1-855-571-1044 for further assistance. -
Page 6: Installation
Installation Installing the side panel □ Place the folded vanity in the upright position. Unfold the left side panel of the vanity (A), and repeat to unfold for the right side panel. Installing the bottom panel □ Flip down the bottom panel to let it rest on wood support blocks located on the side panels. - Page 7 Installation (continued) Installing the back stretcher bar □ Locate one of the back stretcher bar (E) and gently slide the lock pins into the lower slot holes on the side panels. Installing the back stretcher bar □ Locate the other back stretcher bar (E) and gently slide the lock pins into the upper slot holes on the side panels. □...
- Page 8 Installation (continued) Installing vanity cabinet NOTE: Clean area where the vanity (A) will be permanently located prior to beginning installation, ensuring the vanity (A) will not interfere with any water supply and drain lines once mounted. □ With two people, carefully place the vanity (A) against the wall in its final location. Place a level on the unit in both directions, across the front and on both sides to properly adjust the levelers on the unit.
- Page 9 Installation (continued) Unpacking the top Mounting the sink □ Take out the top (B) and backsplash (C) according to the □ Apply silicone caulk (not included) to the top edge of the steps indicated by the drawings, and place them face down sink (D).
- Page 10 Installation (continued) Installing the sink Attaching the sink brackets □ Screw bolts (FF) into the threaded holes of the stone top □ Lower the sink brackets (GG) over the bolts (FF) and allow (B). to rest on the sink lip. □...
- Page 11 Installation (continued) Installing the top □ Apply silicone caulk to the top edge of the wood cabinet. □ With the help of another adult, gently lower the stone top with the assembled sink onto the cabinet. NOTE: Make sure the stone top is flush with the back side of the wood cabinet and the stone overhang is equal on both sides over the wood cabinet left and right side walls.
- Page 12 Installation (continued) Installing the shelf □ Insert shelf pins (BB) at desired height, ensuring they are level. Place shelf (F) on top of shelf pins (BB). Aligning the doors (optional) If you need to adjust the doors, do so in the following manner. □...
-
Page 13: Care And Maintenance
Care and Maintenance □ Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. □ You can clean the vanity with a gentle, non-abrasive household cleaner. □ Make sure to dry the wood immediately with a soft cloth or towel. □... -
Page 14: Service Parts
Service Parts For 2342VA-31-201 If you are missing parts or if you require replacement parts, please contact our customer service team at 1-855-571-1044, 9:00 am - 5:00 pm, EST, Monday - Friday. Identify the required part(s) and have the part number(s) ready. Part Description Part Number... - Page 15 Service Parts For 2342VA-31-242 If you are missing parts or if you require replacement parts, please contact our customer service team at 1-855-571-1044, 9:00 am - 5:00 pm, EST, Monday - Friday. Identify the required part(s) and have the part number(s) ready. Part Description Part Number...
