Utopia Symmetry Installation Manual

Installation Guide
Symmetry Fitted Washbasin Unit
Important Information
•
Read the instructions carefully.
•
Check the product for any signs of damage and remove any protective film.
•
It is recommended that a technically competent installer undertakes installation.
•
It is the installer's responsibility to carry out a thorough assessment of the wall type and the
weight of the cabinet and use appropriate fixings.
•
Care should be taken when drilling walls to avoid any hidden wires or pipes.
•
If the fascias are to be cut, use a saw with a fine-toothed blade ensuring that the room is well
ventilated. Any cut edges should be sealed with PVA glue or silicone sealant to prevent the
ingression of moisture.
Installation
Remove the shelf and turn the unit upside down. Push the legs
firmly into the leg sockets.
Stand the unit back on its legs against the wall. If fitting a run of
units, fix them together through the gable panels. Try to hide the
fixings where possible behind shelves or hinge plates.
Adjust the legs on the units until they are level. Secure the units
to the wall by drilling through the back rail and using suitable fixings
for the wall type.
Door hinge adjustment
•
To square the door against the cabinet, adjust screws A.
•
To adjust the door closer to or further away from the cabinet,
adjust screws B.
•
To adjust the door vertically, slacken screws C. Re-tighten
once the door is adjusted as required.
•
To remove the door hinges from the cabinet, press button D.
•
To remove the door hinges from the door, remove screws E.
Care & Maintenance
Furniture should be regularly dusted with a soft cotton or micro-fibre cloth. For more thorough
cleaning, occasionally wipe your furniture with a soft cloth dampened with a mild detergent
solution. Surfaces should be thoroughly dried with a lint free cloth to prevent watermarks. Under
no circumstances should solvent cleaning agents, bleach or abrasive cleaning agents or cloths be
used. Spills should be removed immediately using a clean cloth. All bathroom furniture will
deteriorate through prolonged periods of exposure to high levels of condensation so bathrooms
must be adequately ventilated using suitable extraction. Failure to ensure adequate ventilation
may invalidate your guarantee.
