Ikan V8000T User Manual

Touchkit touch panel ms-dos version: 3.1.4
Hide thumbs Also See for V8000T:

Advertisement

Quick Links

Download this manual
TouchKit Touch Panel

User manual

for MS-DOS
Version: 3.1.4
0
TouchKit Touch Panel v3.1.4

Advertisement

loading
Need help?

Need help?

Do you have a question about the V8000T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ikan V8000T

Summary of Contents for Ikan V8000T

  • Page 1: User Manual

    TouchKit Touch Panel User manual for MS-DOS Version: 3.1.4 TouchKit Touch Panel v3.1.4...

  • Page 2: Table Of Contents

    CONTENT: CHAPTER 1. TOUCH PANEL CONTROLLER ... 2 ... 2 ONTROLLER PECIFICATIONS AND CHAPTER 2. INSTALLING AND USING TOUCHKIT... 5 CHAPTER 3. CONFIGURATION UTILITY AND RIGHT BUTTON EMULATOR ... 6 CHAPTER 4. UNINSTALLING TOUCHKIT... 10 TouchKit Touch Panel v3.1.4 ... 3 EATURES...

  • Page 3: Chapter 1. Touch Panel Controller

    Chapter 1. Touch Panel Controller This touch panel controller provides the optimistic performance of analog resistive touch panels for 4 wire, 5 wire and 8 wire models. It communicates with PC system directly through RS232, PS/2 or USB connector. user can see how superior the design is in sensitivity, accuracy and friendly operation.

  • Page 4: Specifications And Features

    1.2 Specifications and Features Specifications for Touchkit controller. Specifications Power requirements Operating temperature Storage Temperature Relative Humidity Protocol Resolution Report rate Response time Pin out definition Panel resistance Regulatory Approvals TouchKit Touch Panel v3.1.4 +5VDC ( Maximum 100mA, typical 70mA, 50mV peak to peak maximum ripple ) 0 to 50 ℃...
  • Page 5 OS support COM port support TouchKit Touch Panel v3.1.4 1. Fast full oriental 4 points position 2. Support monitor / display rotation 3. Support multiple monitor / display 4. Support QVGA and Half-VGA function Accuracy 25 points linearity compensation. Position and linearity verification 1.

  • Page 6: Chapter 2. Installing And Using Touchkit

    Chapter 2. Installing and using TouchKit TouchKit is software, which contains drivers of the touch panel controllers for RS232 and PS/2, and utilities for controller configuration: Configuration support Touchkit provides three program utilities for calibration and draw test. They are a.) tp4pcal.exe for 4 points calibration b.) tp25pcal.exe for 25 points calibration c.) tpdraw.exe for draw test...

  • Page 7: Chapter 3. Configuration Utility And Right Button Emulator

    Chapter 3. Configuration Utility and Right Button Emulator After installation TouchKit and rebooting system, the driver will probe all communication devices by default. Execute TPANEL -? for more options. TouchKit for DOS Version 1.00.02.0904 Test TKT1...no panel found Test TKT2...no panel found Test PS2...Loopback OK Read settings from PS2...OK Driver installed...
  • Page 8 TouchKit for DOS also supports three Sound Modes: NONE, UP and DOWN. Please go to C:\TouchKit\> tpanel.ini to change the sound mode. < tpanel.ini > Beep=None 1322 〔promptBegin〕 TouchKit for DOS Version 1.00.02.0904 〔promptEnd〕 After saving new tpanel.ini, user can force the driver to reload the new tpanel.ini by executing C:\TouchKit\>tpanel -r Other adjustment can be checked by C:\TouchKit\>...
  • Page 9 <TP4PCAL> Correct 4 point locations on screen with the panel. E.g. C:\>tp4pcal tkt2 Touch the blinking symbol on panel until beep or stop blinking. <TP25PCAL> Correct 25 point locations on screen with the panel. E.g. C:\>tp25pcal tkt2 Touch the blinking symbol on panel until beep or stop blinking. After the calibration, the new record will overwrite the old one.
  • Page 10 Right Button Emulator supports only video mode 3 and must start after the driver being installed; user may edit C:\>AUTOEXEC.BAT to toggle it on/off. If it is turned on a button will appear in the right-bottom corner of screen when mouse pointer is turned on.

  • Page 11: Chapter 4. Uninstalling Touchkit

    Chapter 4. Uninstalling TouchKit Follow these steps to uninstall TouchKit. For example: C:\>deltree touchkit Delete directory "touchkit" and all its subdirectories? [yn] y Deleting touchkit... C:\>edit autoexec.bat Then delete the following sentence: set path=%path%;C:\touchkit rem Add your own serial port configuration here, ex. SET TKT1=3E8 4 TPANEL.EXE rem Execute "TPANEL /?"...
