Hotpoint VWSR4150DWW Dimensions And Installation Information

3.2 cu. ft. super capacity washer

Hide thumbs Also See for VWSR4150DWW:

25-1/2

Side View

Specification Created 6/03

Rear View

Circuit Requirements: An individual, properly-grounded branch circuit,

with a three-prong grounding-type receptacle, protected by a 15 or

20 amp circuit breaker or a time-delay fuse, is required.

Electrical Rating: 115V, 60Hz, 10 Amps

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

Washer Note: Washer wall outlet must be located within 36" of

service cord entry. Wall outlet must not be located behind dryer.

Listed by

Underwriters

Laboratories

Table of Contents

Do you have a question about the VWSR4150DWW and is the answer not in the manual?

Page 1: Rear View
® VWSR4150DWW – Hotpoint 3.2 Cu. Ft. Super Capacity Washer Washer Dimensions (in inches) 25-1/2 Side View Specification Created 6/03 Circuit Requirements: An individual, properly-grounded branch circuit, with a three-prong grounding-type receptacle, protected by a 15 or 20 amp circuit breaker or a time-delay fuse, is required.
Page 2 ® VWSR4150DWW – Hotpoint 3.2 Cu. Ft. Super Capacity Washer Specification Created 6/03 Features and Benefits • Rotary electromechanical controls – Allow fast, easy cycle selection. • Four wash/spin speed combinations – Speeds vary according to fabric type for better clothes care.
