- Page 1 ZXFC Lightening Protection Devices Tester...
- Page 2 ZXFC MOV SPD TESTER MANUAL I Product Functions and Features............................2 II Technique Parameters..............................2 III Panel....................................3 IV. Operation Method................................ 4 V Precautions..................................6 VI After sale service................................6 VII Packing list..................................7 - 1 -...
- Page 3 ZXFC MOV SPD TESTER I Product Functions and Features 1. This instrument is applied to test the DC parameters of Oxide Zinc voltage dependent resistor ( varistor / MOV), ceramic 2/3-electrode surge arrester, gas discharge tube and other Surge Protective Devices. It also can be used as stable power source or constant current power supply.
- Page 4 ZXFC MOV SPD TESTER III Panel Front Rear 1. HV limit 2.Single/Continuous 3.MOV/SPD 4. HV indicating light 5.HV on/off 6.Display conversion 7. Test 8.Testing light 9.Voltage preset 10.Screen 11.Buzzer 12.power switch 13.Test terminal(red) 14.Test terminal(black) 15.Power socket - 3 -...
- Page 5 ZXFC MOV SPD TESTER IV. Operation Method 1. preparation 1) Turn "HV limit" knob clockwise to the end (maximum) and the "voltage preset" counterclockwise to the end (minimum). Insert the test lines into the panel "+" and "-" respectively. Connect the external power source to the back panel corresponding power socket.
- Page 6 ZXFC MOV SPD TESTER After clicking the "test" button, the test voltage starts at the rate of 100V/s and step up from the voltage preset value. After the green light is on: If the buzzer does not alarm, the display is the ignition voltage of measured discharge tube in the measurement range.
- Page 7 ZXFC MOV SPD TESTER Click "HV on/off" button to turn off the test voltage, turn off the power switch. When using external DC 12V DC power supply, the power cord should be removed. V Precautions 1. This machine has range (test scope) adjustment function.during the use, the test voltage should be as low as possible to reduce energy consumption, prolong the life of the instrument, the test time can be reduced with higher efficiency.
- Page 8 ZXFC MOV SPD TESTER VII Packing list 1. Main tester 1 pcs 2. Test lines 1 set 3. test clips 2 pcs 4. special power supply 1 pcs 5. Manual 1 copy 6. Inspection reports 1 copy 7. Warranty card 1 pcs 8.
