GR-86 GPS Receiver Module

Main Features

SiRF GSC3f chipset with embedded ARM7TDMI CPU available for
customized applications in firmware.
20-channel GPS Receiver for fast acquisition and reacquisition
Very compact size, only 24 * 24 * 3 mm.
200,000 effective correlators for fast Time To First Fix (TTFF), even at
poor satellite signal.
Built-in WAAS/EGNOS Demodulator.
Low
power
Push-To-Fix mode.
Support NMEA-0183 v2.2 data protocol and SiRF binary code.
Real time navigation for location based services.
For Car Navigation、Marine Navigation、Fleet Management 、AVL and
Location-Based Services、Auto Pilot、Personal Navigation or touring
devices, tracking devices/systems and Mapping devices application.

Specifications

Acquisition at low signal levels:
Cold / warm / hot start: 42/38/1 sec(average)
Position Accuracy:
Autonomous: <10 meters at 2D RMS.
SBAS: <7 meters at 2DRMS, WAAS corrected.
DGPS: 1-5 meters at DGPS corrected.
Receiver:
Tracking : L1/CA code
Channel : 20
Max. Update rate: 1 HZ
Time mark: output 1 pulse/sec, aligned with GPS time ±0.1 usec
Max. altitude/velocity : <60,000 ft / < 1,000 knots.
consumption
with
Advanced
Trickle-Power
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR-86 and is the answer not in the manual?

Questions and answers

Related Manuals for Holux GR-86

Summary of Contents for Holux GR-86

  • Page 1: Main Features

    GR-86 GPS Receiver Module Main Features SiRF GSC3f chipset with embedded ARM7TDMI CPU available for customized applications in firmware. 20-channel GPS Receiver for fast acquisition and reacquisition Very compact size, only 24 * 24 * 3 mm. 200,000 effective correlators for fast Time To First Fix (TTFF), even at poor satellite signal.
  • Page 2 Protocol Support : NMEA-0183, SiRF Binary, AI3/F Datum: WGS-84(default), selectable for other Datum. Processing Core 200,000+ effective correlators for fast TTFF and high sensitivity acquisition. Processor Type: ARM7/TDMI Processor Speeds 49 MHZ Integrated Flash 4 Mb Minimum acquire signal levels: -159 dBm (based on SiRF GSC3f spec) Interface : CMOS 3V Dimension: 24 x 24 x 3 mm...
  • Page 3 Module snapshot and pin out definition Picture Outline drawing (0,21) (0,19) (0,17) (0,15) (0,13) 24.0 mm. (0,11) (0,9) (0,7) (0,5) (0,3) (0,0) (8.5,24) (5,24) 3.5 mm. (16,0) 24.0 mm. 0.2 mm. (24,21) (24,19) (24,17) (24,15) (24,13) (24,11) (24,9) (24,7) (24,5) (24,3) 5.0 mm.
  • Page 4 Recommanded PCB...

  • Page 5: Ordering Information

    Reserve for feature 1 µsec pulse per second when tracking TIMEMARK PWR Ground Ordering Information Model No. GR-86-A GR-86-B Function description Chipset RF interface output voltage (V) GSC3f RF antenna power 2.8 VDC from GR-86 GSC3f RF antenna power supply from VCC_IN...
