SRS10 (SRS11 / SRS13 / SRS14) Series
Thank you for purchasing a Shimaden Digital Controller. After making sure the product fits the desired description,
you should carefully read the instructions and get a good understanding of the contents before attempting to operate
the equipment.
Request
The instruction manual should be kept in a handy place where the end user can refer to it when necessary.
Preface
The instruction manual was written for those who perform wiring, installation and routine maintenance for the
SRS10 (SRS11/SRS13/SRS14) Series. The instruction manual contains a description of the operating method,
functions, wiring, mounting method and precautions when handling the SRS10 (SRS11/SRS13/SRS14) Series
(hereinafter referred to as the SRS10 Series unless a separate description is required). You should therefore keep it
in a handy place to refer to when operating and handling the equipment. Be sure to observe all precautions and
adhere to the procedures provided in the manual. The intsruction manual assumes that fixed value control is applied.
For information on programming function and communication (optional items), see the instruction manual for the
individual function.
Digital Controller
Instruction Manual
SRS10F-1BE
Sep. 2008
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Shimaden SRS10 Series
Summary of Contents for Shimaden SRS10 Series
-
Page 1: Request
SRS10 (SRS11/SRS13/SRS14) Series (hereinafter referred to as the SRS10 Series unless a separate description is required). You should therefore keep it in a handy place to refer to when operating and handling the equipment. Be sure to observe all precautions and adhere to the procedures provided in the manual. -
Page 2: Table Of Contents
Contents Request...............1 6. Screen explanation and setting items....16 Preface................1 7. Measuring range codes ........23 1. Safety rules.............3 8. Explanation of functions ........24 2. Introduction............3 8-1. Events ..............24 2-1. Preliminary check............3 (1) Alarm action ..............24 (2) Event standby action selection........24 (1) Model code check..............4 (3) Event selection alarm action diagrams ...... -
Page 3: Safety Rules
Additional instructions or notes. WARNING The SRS10 Series digital controllers are designed to control temperature, humidity and other physical amounts for general industrial equipment. You should either take appropriate safety measures or avoid using for control that could have a serious effect on human life. -
Page 4: Model Code Check
Note: In the event you want to inquire about a product defect, missing accessory or other matter, please contact your nearest Shimaden agent. 2-2. Notes on use Do not press front panel keys with a hard or pointed object. -
Page 5: Mounting
The controller is provided with tabs for mounting. Insert as is from the front surface of the panel. Controllers of the SRS10 Series are designed for mounting on the panel. Be sure to mount on the panel. If mounted in series, provide ventilation so ambient temperature does not exceed 50°C due to temparature rise caused by heat generation. -
Page 6: Wiring
Wire from the CT secondary side terminal to the CT input terminal of the SRS10 Series. There are 2 combinations of CT connection terminals for the SRS10 Series, which can detect current for 2 heater combinations. Heater (load) wire 3-5. Terminal layout Wire in accordance with the following terminal layout and terminal arrangement table. -
Page 7: Terminal Arrangement Table
3-6. Terminal arrangement table Terminal No. Name of terminal Description/code Note1: With thermocouple / voltage / current input, SRS11 SRS13/14 shorting across B and B terminal will cause Power supply 100-240V AC/24V AC:L,24V DC:+ an error. 100-240V AC/24V AC:N,24V DC: – Input R.T.D: A, thermocouple / voltage / Note2: The following optional function of the SRS10... -
Page 8: Names And Functions Of Parts On Front Panel
4. Names and functions of parts on front panel Measured value (PV) display Target set value (SV) display Action display Operating keys Name Function (1) Measured value display LED (red) Measured value (PV) * Displays current PV value on basic screen (screen 0-0). display * Displays type of parameter on each respective parameter display screen. -
Page 9: Parameter Diagram And Setting
5. Parameter diagram and setting 5-1 Parameter diagram The overview of the parameter diagram is as follows. The windows of the various screens are divided as follows. The number at the top left of the window is the screen No. Screen always displayed by key operation, etc. - Page 10 0-0 Basic screen 4 screen group 3 seconds 4-21 4-42 Heater 2 burnout alarm Communication master mode Initial screen setting finish slave address setting 4-22 4-43 Heater 2 loop alarm ...
-
Page 11: Display When Power Is Applied
5-2. Display when power is applied When power is applied, the initial screen when power is applied displays each screen for about 1 sec. and switches to the basic screen of screen group 0 as shown in the following figure. Series name (, , ) ... -
Page 12: Switching To Screen Group 2
(4) Switching to screen group 2 Pressing the key on the “1-0 initial screen” switches to the “2-0 initial screen” of screen group 2. Screen group 1 Screen group 2 0-0 Basic screen 2-0 Initial screen ... -
Page 13: Auto Return Function
5-4. Auto return function If no key operation is conducted for 3 minutes on the various screens (with the exception of the “0-2 output 1 monitoring screen”, “0-3 output 2 monitoring screen”, “0-4 step No. monitoring screen”, “0-5 remaining time of step monitoring screen”, “0-6 number of pattern execution monitoring screen”, “0-7 Execution PID No. -
Page 14: Auto Tuning (At)
(3) Auto tuning (AT) Function that automatically processes and sets parameter PID for PID control. Processing time varies according to control. 1) AT execution Pressing the key on the “0-15 AT action control screen” causes the display at the bottom to change to and the decimal point of the smallest digit to flash. -
Page 15: Standby (Stby) / Execution (Exe)
(4) Standby (STBY) / execution (EXE) The controller is equipped with a standby mode for temporarily halting controller execution. This operation mode is switched on the “0-1 standby action setting screen.” In the case of fixed value control (FIX mode), STBY (standby) / EXE (execution) is displayed. In the case of program control (PROG mode), RST (reset: stop) / RUN (program execution) is displayed. -
Page 16: Screen Explanation And Setting Items
6. Screen explanation and setting items 4-0 Initial screen basic screen 3 seconds Initial values: 0 or measuring range lower limit values 2-0 screen 3-0 screen 1-0 Initial screen Setting range: Within measuring range (within SV limiter) ... - Page 17 Start pattern No. monitoring screen PID setting screen group Display screen for program operation. With the SRS10 Series, you can have 3 types of PID constants. Initial value: 1 In the case of fixed value control (FIX), target set values SV1, SV2 and SV3 ...
- Page 18 Output 1 PID1 derivative time (D) setting screen 2-13 Output 2 dead band (DB) setting screen Initial value: 30 (seconds) Initial value: 0 (unit) Setting range: oFF, 1 – 3600 (seconds) Setting range: -1999 – 5000 (unit) There is basically no need to set if auto tuning (AT) is executed.
- Page 19 Event type code (used by 4-7 and 4-12) Event 2 action hysteresis setting screen Code Types of event Remarks Initial value: 20 (unit) No selection (non) Setting range: 1 – 999 (unit) Higher limit deviation EV1 initial values ...
- Page 20 Heater break/loop alarm settings 4-25 Analog output scaling higher limit value setting screen Can be used if event option and CT input option is eguipped. Initial value: 800.0 (For PV/SV, measureing range higher limit value; 4-17 Heater 1 break/loop alarm mode setting screen out1/out2 is 100.0) Setting range: When PV or SV is selected, within measuring ...
- Page 21 Setting range: non, EXE1(run1), EXE2(run2), mAn, At, ESV2, ProG, HLd, AdV, Ptn2, L_rS Add operation (Shimaden protocol) 2’s complement after add operation (Shimaden protocol) Set just like 4-28 DI1 mode. Exclusive OR (Shimaden protocol) LRC (MODBUS ASCII) If ESV2/Ptn2 is assigned to DI2, DI3 cannot be selected.
- Page 22 4-46 Control output 1 soft start time setting screen 4-54 PV bias value setting screen Initial value: 0 (unit) Initial value: oFF Setting range: -1999 – 2000 (unit) Setting range: oFF, 1 – 120 (seconds) Used for compensating input error of sensors, etc. Sets soft start time that gradually changes output.
-
Page 23: Measuring Range Codes
7. Measuring Range Codes Select measuring range from the following table. Changing the code initializes all data related to measuring range. Input type Code Measuring range (°C) Measuring range (°F) ~ 1800 °C ~ 3300 °F ~ 1700 °C ~ 3100 °F ... -
Page 24: Explanation Of Functions
8. Explanation of functions This section contains a description of operation not covered in “5.5 Screen group 0 setting.” 8-1. Events (1) Alarm action 1) Deviation alarm Sets alarm action points for deviation of measured values (PV) from target set values (SV). For example, to trigger an alarm when measured value (PV) of 30°C or more when target set value is 20°C, the higher limit deviation alarm is set to 10°C. -
Page 25: P (Proportional Action)
Heater loop alarm also outputs an alarm if the current value detected by CT when control output is OFF is higher than the setting. In the SRS10 series, 2 points of CT input is equipped if the CT input option is selected. -
Page 26: Proportional Cycling Time
Dead band: Shifts proportional band of control output2 for setting value. 8-5. External control input (DI) Input must be retained for at least 250 ms to receive external control input of the SRS10 Series. Assignment by DI input is conducted on the “4-28 – 4-31 DI mode setting screens.”... -
Page 27: External Selection (Esv2)
(5) SV external selection (ESV2) Setting values of SV1 – SV3 can be switched to SV being executed. DI is level action using 2 points. Assignment to DI1 or DI2 can be set. Assigning/setting SV external selection to DI1 automatically allocates it to DI2 as well, so DI2 cannot be selected. Assigning/setting SV external selection to DI2 automatically allocates it to DI3 as well, so DI3 cannot be selected. -
Page 28: Conditions That Cancel Soft Start
When the controller does not operate as intended and you suspect it may be broken, read the instruction manual and inspect once again. If there is something wrong with the controller or there is something you do not understand, contact your nearest Shimaden dealer. -
Page 29: Parameter Setting Record
10. Parameter setting record For the sake of convenience, you should record your settings and selections. Initial values for code 05 (K) are given here. Screen No. Parameter (item)/screen Initial value Setting/selection Record Basic screen (SV) () EXE () Standby action (FIX) ... - Page 30 Screen No. Parameter (item)/screen Initial value Setting/selection Record OUT2 PID P 2_P3 () 2-10 OUT2 hysteresis 2dF3 () 2-11 OUT2 PID I 2_i3 () 2-12 OUT2 PID D 2_d3 () 2-13 OUT2 dead band 2db3 () ...
-
Page 31: Specifications
11. Specifications ■ Display ● Control output 2 (option) Proportional band (P) : OFF, 0.1~999.9% (ON-OFF action by OFF) ● Digital display : Measured value (PV) / 7-segments red LED, 4 digits Integral time (I) : OFF, 1~6000 seconds (P or PD action by OFF) Target set value (SV) / 7-segments green LED, 4 digits Derivative time (D) : OFF, 1~3600 seconds (P or PI action by OFF) - Page 32 SRS14 : Approx. 160 g ● Communication code : ASCII, MODBUS RTU binary code only ● Communication : Shimaden standard protocol / MODBUS ASCII, RTU Protocol ● Other : Start character and BCC operating method can be selected. ● Communication...
