Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
US office: Fontana
UK office: Ipswich
Contact Us !
Do NOT return this item.
AU office: Truganina
US:cs.us@costway.com
UK:cs.uk@costway.com
AU:cs.au@costway.com
HU10196-Q/HU10196-F
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
USER'S MANUAL
Full(Queen) Bed
Advertisement
Table of Contents
Related Manuals for Costway HU10196-Q
Summary of Contents for Costway HU10196-Q
- Page 1 Replacements for missing or damaged parts will be shipped ASAP ! US office: Fontana UK office: Ipswich AU office: Truganina USER’S MANUAL Contact Us ! Full(Queen) Bed HU10196-Q/HU10196-F Do NOT return this item. US:cs.us@costway.com UK:cs.uk@costway.com AU:cs.au@costway.com THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 PARTS LIST Footboard Headboard Before You Start Headboard Leg(L&R) Bed Roll-Out Slats Bed Slats Support Side Rail Left Read each step carefully before starting. It is very important to ensure each step followed in correct order, otherwise assembly difficulties may occur. Center Slats Side Rail Right Most of board parts are labeled or stamped on the raw...
- Page 3 STEP 1.1 Attach Head Board Leg (C) to Head Board (A) as shown using JCBC BOLT (1) with Flat Washer (3) and securing with ALLEN KEY (4). STEP 1.2 Fix the other holes with Screws (6) as shown. LEFT RIGHT BACK VIEW STEP 1 .1 : STEP 1 .2 :...
- Page 4 STEP 3 Care and Maintenance Fix the Bed Slat Supports (E) to the bed slats (D) and Center Slats (H), then tighten with JCBC Bolts (2) as shown. Install the bed slat (D) to Side Rail (F) & (G), and tighten with Screws (6) as shown. (NOTE: THE Use a soft, clean cloth that will not scratch the surface when dusting.
