Summary of Contents for Airofit Airocure

  • Page 1 Airocure User Manual...

  • Page 2: Table Of Contents

    Contents Purpose and Scope 2. Intended Use and Users 3. Safety Precautions 4. Operation 5. Maintenance 6. Getting started with Airocure 7. Warning Notification 8. Troubleshooting 9. Technical Specifications 10. Airocure Limited Warranty...

  • Page 3: Purpose And Scope

    The Airocure Breathing Trainer is used in conjunction with the Airocure software application operating on a smartphone - either Android or iOS. 2.1 Manufacturer’s Liability Airofit Medico A/S is only liable for equipment safety, reliability, and performance, provided that the Airocure is used in compliance with these instructions.

  • Page 4: Safety Precautions

    • Respiratory training can cause dizziness. We recommend that you remain seated after training and breathe normally for a minimum of 1-2 minutes before moving on to other activities. • Airocure is suitable for ages 12 and over. Users under the age of 15 should only use Airocure under the supervision of an adult.
  • Page 5 Airocure device is not dishwasher or autoclave safe. • Ensure that your Airocure device remains hygienic and in good working order. Always make sure that your device is dry before storing it. We advise you to store your Airocure device in a suitable, clean, and hygienic way.
  • Page 6 • If you have more than one Airocure device, do not swap the E-Units.

  • Page 7: Operation

    • Airocure User Manual 4.1 Airocure System Description The Airocure system consists of the Airocure Breathing Trainer and the Airocure mobile application. The Airocure Breathing Trainer provides resistance to your inspiratory and expiratory breathing, while the Airocure application provides guidance to...
  • Page 8 4.2 Getting to Know the Airocure Breathing Trainer...
  • Page 9 Power Button Press the Power Button to turn ON the Airocure Breathing Trainer. It will begin to blink green to indicate that the device is ON - at this point, it is ready to be paired with the mobile application.
  • Page 10 When fully charged, the light will show as solid green. 4.3 Using Airocure Correctly When using the Airocure Breathing Trainer you should be relaxed and sitting upright. Hold the device with your hand on the E-Unit. Make sure the openings near the resistance wheels are not obstructed.

  • Page 11: Maintenance

    5. Maintenance Always make sure that your device is dry before storing it. We advise you to store your Airocure Breathing Trainer in a suitable, clean, and hygienic way. Fully charge your device if you are storing it for more than a week without use to avoid full battery depletion.

  • Page 12: Getting Started With Airocure

    Once a week, remove both the E-Unit and the mouthpiece from the Airocure Breathing Trainer to be able to clean it better. Use a drop of dish soap in water to wash your Trainer Unit and mouthpiece thoroughly. Once washed, hold the Trainer Unit under running water, allowing it to run through.
  • Page 13 As instructed in the Airocure app, you will initially perform a Breathing Performance Test to establish your breathing condition. The app notification will pop up when you should take the test.. The Breathing Performance Test records your • Maximum breath volume, the maximum amount of air you can exhale after filling your lungs completely •...
  • Page 14 a problem if you find something wrong with the app. The app also contains the Terms and Conditions (requires internet connection) and the Privacy Policy, which you agreed to when you created your account.

  • Page 15: Troubleshooting

    Normal range: 20 - 170 cmH Average: 75 ±25 cmH Expiratory strength: Normal range: 20 - 230 cmH Average: 95 ±35 cmH Airflow Resistance to airflow during respiration resistance 7. Troubleshooting Please contact us at support@airofit.com for troubleshooting guidance.

  • Page 17: Technical Specifications

    8. Technical Specifications 8.1 Airocure Breathing Trainer Description Notes Air resistance Inhalation air resistance A-F: 20-200 cmH O / (at 1 liter/sec) Exhalation air resistance 1-6: 20-200 cmH O / (at 1 liter/sec) NOTE Material Mouthpieces TPE (Medical) Housing Battery...
  • Page 18 Rechargeable 3.7V Li-ion, 35mAh Capacity 10 hours Charger 5V, min 100mA Charging time 8 hours Charger plug Magnetic connector Communication Bluetooth BLE version 4.1 Dimensions Size 70mm x 77mm x 33mm Weight Smartphone App...
  • Page 19 IOS version 11 or newer Android version 7 or newer...
  • Page 20 8.2 Environment Description Notes Operating conditions Temperature indoor 15°C to 35°C Temperature outdoor 0°C to 45°C Relative humidity 10% to 90% RH Pressure 960 hPa to 1,060 hPa IP classification IP65 Storage and transport conditions Temperature -25°C to 50°C Relative humidity 10% to 90% RH Pressure 700 hPa to 1,060 hPa...
  • Page 21 EN 60601-1-2:2015 8.3 Standards The Airocure training system is designed according to the Medical Device Directive - MDD 2007/47/EC. The Airocure system is manufactured with compliance to medical device Class I. The Airocure system complies with the EU Directive on personal data security - 2016/680/EU.
  • Page 22 Registration, Evaluation, 2006 Authorisation and Restriction of Chemical substances WEEE Directive 2012/19/EU 2012 8.4 Radio Equipment Compliance The Airocure system complies with Radio Equipment Directive (RED) - 2014/53/EU. The device complies with part 15 of the FCC Rules. FCC ID: 2ATQX-AF003...
  • Page 23 Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 24 L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicable aux appareils radio exempts de licence. IC: 25191-AF003 L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage 2.

  • Page 25: Airocure Limited Warranty

    9. Airocure Limited Warranty Airofit Medico A/S warrants this product to be free from defects in material or workmanship for a period of twenty-four (24) months from the date of purchase, provided that the product is used in a home environment and according to this manual.
  • Page 26 Copyright © 2021 by Airofit Medico A/S, Denmark All rights reserved. No part of this publication may be reproduced, distributed, or V1.1 transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of Airofit Medico A/S.
