SERVICE
WASHING MACHINE (DRUM)
WW22K6800AW-A2.indb 1
WASHING MACHINE
DRUM TYPE
Basic Model
:
WW90J6413CW/UA
(WW6000J PROJECT)
Model Name
:
WW22K6800A*
Model Code
:
WW22K6800AW/A2
(WW6800K PROJECT)
Manual
1. Safety Instructions
2. Features and Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. PCB Diagram
6. Wiring Diagram
7. Reference
CONTENTS
2015/12/3 16:08:23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WW6000J Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WW6000J Series

Summary of Contents for Samsung WW6000J Series

  • Page 1 WASHING MACHINE DRUM TYPE Basic Model WW90J6413CW/UA (WW6000J PROJECT) Model Name WW22K6800A* Model Code WW22K6800AW/A2 (WW6800K PROJECT) SERVICE Manual WASHING MACHINE (DRUM) CONTENTS 1. Safety Instructions 2. Features and Specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. PCB Diagram 6. Wiring Diagram 7. Reference WW22K6800AW-A2.indb 1 2015/12/3 16:08:23...

  • Page 2: Table Of Contents

    CONTENTS 1. Safety instructions ..............1 1-1.

  • Page 3: Safety Instructions

    1. SAfETy INSTRUCTIONS 1-1. SAfETy INSTRUCTIONS fOR SERvICE ENgINEERS ► Make sure to observe the following instructions to operate the product correctly and safely and prevent possible accidents and hazards while servicing. ► Two types of safety symbols, Warning and Caution, are used in the safety instructions. Hazards or unsafe practices that may result in severe personal injury or death. WARNINg Hazards or unsafe practices that may result in minor personal injury or property damage. CAUTION WARNINg BEfORE SERvICINg...
  • Page 4 WARNINg WHILE SERvICINg • Check if the power plug and outlet are damaged, flattened, cut or otherwise degraded. √ If faulty, replace it immediately. Failing to do so may result in electric shock or fire. • Completely remove any dust or foreign material from the housing, wiring and connection parts. √ This will prevent a risk of fire due to tracking and shorts in advance. • When connecting wires, make sure to connect them using the relevant connectors and check that they are completely connected. √ If tape is used instead of the connectors, it may cause fire due to tracking. • Make sure to discharge the PBA power terminals before starting the service. √ Failing to do so may result in a high voltage electric shock. • When replacing the heater, make sure to fasten the nut after ensuring that it is inserted into the bracket-heater. √ If not inserted into the bracket-heater, it touches the drum and causes noise and electric leakage. WARNINg AfTER SERvICINg • Check the wiring. √ Ensure that no wire touches a rotating part or a sharpened part of the electrical harness. • Check for any water leakage. √ Perform a test run for the washing machine using the standard course and check whether there is any water leakage through the floor section or the pipes. • Do not allow consumers to repair or service any part of the washing machine themselves. √ This may result in personal injury and shorten the product lifetime.
  • Page 5 CAUTION BEfORE SERvICINg • Do not sprinkle water onto the washing machine directly when cleaning it. √ This may result in electric shock or fire, and may shorten the product lifetime. • Do not place any containers with water on the washing machine. √ If the water is spilled, it may result in electric shock or fire. This will also shorten the product lifetime. • Do not install the washing machine in a location exposed to snow or rain. √ This may result in electric shock or fire, and shorten the product lifetime. • Do not press a control button using a sharp tool or object. √ This may result in electric shock or damage to the product. CAUTION WHILE SERvICINg • When wiring a harness, make sure to seal it completely so no liquid can enter. √ Make sure that they do not break when force is exerted. • Check if there is any residue that shows that liquid entered the electric parts or harnesses. √ If any liquid has entered into a part, replace it or completely remove any remaining moisture from it. • If you need to place the washing machine on its back for servicing purposes, place a support(s) on the floor and lay it down carefully so its side is on the floor. √ Do not lay it down on its front. This may result in the inside tub damaging parts. Safety Instructions _ 3 WW22K6800AW-A2.indb 3 2015/12/3 16:08:27...
  • Page 6 CAUTION AfTER SERvICINg • Check the assembled status of the parts. √ They must be the same as before servicing. • Check the insulation resistance. √ Disconnect the power cord from the power outlet and measure the insulation resistance between the power plug and the grounding wire of the washing machine. The value must be greater than 10MΩ when measured with a 500V DC Megger. • Check whether the washing machine is level in relationship with the floor. Check whether it is installed firmly on the floor. √ Vibrations can shorten the lifetime of the product. 4 _ Safety Instructions WW22K6800AW-A2.indb 4 2015/12/3 16:08:27...

  • Page 7: Features And Specifications

    2. fEATURES AND SPECIfICATIONS 2-1. fEATURES ■ COMMON fEATURES features Description Big Door • This is the maximum capacity to be implemented at the standard 55 cm depth. - The benefits for customers have been greatly increased due to the efficient use of limited space. - Usability has been improved due to the easier loading and removing of the laundry. • The size of the loading entry has increased: 300 mm → 308 mm (Wide) - A lot more washing can be conveniently added and removed. 308 mm Diamond Drum • The washing performance has increased but potential damage to the washing has been minimized. (The size of the holes on the diamond drum has been reduced for minimizing damage to the washing.) - The embossed wall of the drum serves as a washboard, dramatically increasing the washing performance compared with existing drum washing machines, which use the power of the difference in elevation only. - The size of holes has been reduced drastically, maintaining the optimal wash performance (Washing Cost 1.0) while saving on water and electricity required for washing. - The structure of the holes on the diamond drum has been changed minimizing potential damage to the washing since it is difficult for strands to enter the holes.
  • Page 8 ■ OPTIONAL fEATURES ► The features below depend on the model. features Description Super Speed • Super speed reduces the washing time using SpeedSpray™ that removes detergent residue thoroughly with powerful water sprays during rinsing. *Super speed available on Normal, Heavy Duty and Deep Steam cycle. Steam • Deeply clean with Steam With Deep Steam cycle using the steam function, you can always keep your clothes hygienic and pristine. 6 _ Features and Specifications WW22K6800AW-A2.indb 6 2015/12/3 16:08:28...
  • Page 9 Wool • Fabric Care - Minimize shrinking - Gently and carefully cleans - delicate fabrics that are usually washed by hand. Normal vs Wool mark Normal vs Wool mark volt Control • The solution for more Durable and Reliable Washing Machine - Although you may not see the direct problems of power surges that run through your electronic devices, a real danger in sudden surges of voltage does exist and this definitely affects your washing machine. This is especially true for machines that require a lot of energy. Samsung’s Volt Control guarantees that your washing machine works safely even with voltage deviations of ±25%. • What does the “Volt Control” mean? - This is technology that allows to safe a washing machine from high shock and even lower voltage. There is an additional protective measure in a washing machine for your precious clothes. It constantly controls washing cycle in a fluctuated situation and re-start automatically when the standard voltage flows back again. 400v 350v 300v 250v 220v...

  • Page 10: Specifications

    2-2. SPECIfICATIONS Model WW22K6800A* Wash Type FRONT LOADING TYPE Dimension W600mm x D600mm x H850mm Water Pressure 50 kPa ~ 800 kPa Water volume 63 L Weight 73 kg Wash & Spin Capacity 2.2 CU.FT Power Consumption 900 W Spin Revolution 1400 8 _ Features and Specifications WW22K6800AW-A2.indb 8 2015/12/3 16:08:29...

  • Page 11: Comparing Specifications With Existing Models

    2-3. COMPARINg SPECIfICATIONS WITH ExISTINg MODELS (★) : Functions may be different depending on the model. Project WW6800K WW6000J Model Name WW22K6800A* WW90J641*** Image Capacity 2.2 CU.FT 9.0 kg Water Volume 63 L 63 L 1400 1400 Motor Control Sys Fuzzy logic Fuzzy logic Weight Detection 3 Stages 3 Stages Main Heater Capacity 900 W 2000 W Spec Water Supply Cold & Hot Cold Only...

  • Page 12: Options Specifications

    2-4. OPTIONS SPECIfICATIONS Item Code Remarks FASTENER-BOLT DC60-00104A Default ASSY HOSE For specific DC97-16921A ★ WATER models only DC68-03643A MANUAL-BOOK Default DC68-03645A CAP-FIXER DC67-00307A Default CAP-FIXER DC67-00208B Default HOSE-HANGER DC62-10278A Default GUIDE LIQUID DC61-03510A Default ASSY DRAWER DC97-19243A Default BLEACH Note • (★) is supplied for specific models only among those without water supply hoses. • You can purchase additional water supply and drain hoses from a service center. • For built-in models, the spanner, water supply and drain hoses are not supplied. Both the water supply and drain hoses are supplied during the installation.

  • Page 13: Disassembly And Reassembly

    3. DISASSEMBLy AND REASSEMBLy 3-1. TOOLS fOR DISASSEMBLy AND REASSEMBLy Tool Type Remarks Heater(1),Tub(12), Fixer 10mm screw(5), Motor(2), Balance(9) Shock Absorber (2 holes Box driver 13mm each in left/right), Damper(2), Damper(friction 2) 19mm Pulley(1) 10mm Double- ended 13mm Replaced by box driver spanner 19mm A Tool for protecting empty turning of bolt or abrasion from Vice pliers using box driver For disassembly of Spin drum Others Common tools for servicing (screwdriver, nipper, long nose pliers) Removal and Reassembly _ 13 WW22K6800AW-A2.indb 13 2015/12/3 16:08:31...

  • Page 14: Standard Disassembly Drawings

    3-2. STANDARD DISASSEMBLy DRAWINgS ► This is a standard disassembly diagram and may differ from the actual product. Use this material as a reference when disassembling and reassembling the product. Part Description Figure ASSY 1. Remove the two screws COVER holding the Top Cover at the back of the unit. 2. Remove the top-cover by lifting it up after pulling it back about 15mm. 3. Then, the Water (Pressure) Sensor pressure Sensor, Noise Filter and Water Valve can be replaced. Noise filter Water valve 14 _ Removal and Reassembly WW22K6800AW-A2.indb 14 2015/12/3 16:08:31...
  • Page 15 Part Description Figure ASSY 1. Remove the 2 screws hoding PANEL the front operating panel. CONTROL 2. Remove the two screws at the top of the ASSY-PANEL CONTROL. 3. Hold the ASSY-PANEL CONTROL while pulling it upwards and release the hook to remove it. 4. Disconnect the terminals connected to the PCB by hand. 5. Hold the ASSY-PANEL CONTROL while pulling it upwards and release the hook to remove it. Removal and Reassembly _ 15 WW22K6800AW-A2.indb 15 2015/12/3 16:08:32...
  • Page 16 Part name Description Figure SUB-PCB 1.There are six clasps to fix pcb, such as the right picture shows. ④ ④ ③ ① ② ② 2.Press the clasp ①,release the clasp ①,and then press clasp ②,release the clasp clasp ③ ②,after that press release the clasp from ③ upwards . 3.Finally, take the PCB out from claps ④. 4.Repair or replacement. 16 _ Removal and Reassembly WW22K6800AW-A2.indb 16 2015/12/3 16:08:35...
  • Page 17 Part Description Figuer WATER 1. Remove the top-cover. SUPPLY VALVE 2. Separate the water supply valve wire. 3. Remove the 2 screws holding the water supply valve. DAMPER 1. Remove the 2 screws shown in the figure. Removal and Reassembly _ 17 WW22K6800AW-A2.indb 17 2015/12/3 16:08:37...
  • Page 18 Part Description Figure SENSOR 1. Connect the Water-Hose PRESSURE to the main body of the Pressure-Switch. 2. Fix the Hose-Clamper. 3. Place the Pressure-Switch into the Bracket Hole holding the main body of the Pressure-Switch. 4. To separate the Pressure- Switch, pull the Pressure- Switch forwards while pushing the marked part with your finger. 18 _ Removal and Reassembly WW22K6800AW-A2.indb 18 2015/12/3 16:08:41...
  • Page 19 NO. Part name Description Figure NOISE 1. Seperate top cover. FILTER 2. Seperate filter net wire. 3. Remove the nut. 4. Replace filter net. DOOR HINGE 1. Open the door,removing the two screws holding the door hinge and sep- erate the door 2. Remove the 3 screws holding the Holder Glass, separate the Holder Glass and replace the hinge. Removal and Reassembly _ 19 WW22K6800AW-A2.indb 19 2015/12/3 16:08:41...
  • Page 20 NO. Part name Description Figure DOOR-LOCK 1.Open the Door. 2.Remove the Wire Dia- phragm and remove it from The Front Frame. For easier disassem- bly, remove the spring from the lower part of the Diaphragm with a (-) screwdriver. Since the Diaphragm can be damaged when removing it, remove it slowly in one direction. 3.Remove the ASSY- CLAMP DIAPHRAGM as photograph. 4.Remove the two crews. Remove the screw hold- ing the Door-Lock S/W. Remove the Door-Lock S/W. Remove the con- nection wire. Remove the connec- tor after releasing it by pressing the catch. 20 _ Removal and Reassembly WW22K6800AW-A2.indb 20 2015/12/3 16:08:44...
  • Page 21 Part Description Figure FRAME 1. Remove the two screws FRONT holding the FRAME-FRONT. 2. Remove the three screws holding the bottom of the FRAME-FRONT. 3. Disconnect the terminal for the DOOR-LOCK switch. 4. The DOOR-DIAPHRAGM, HEATER, PUMP, SHOCK- DAMPER and DOOR LOCK switch. Removal and Reassembly _ 21 WW22K6800AW-A2.indb 21 2015/12/3 16:08:46...
  • Page 22 Part Description Figure COVER- 1. Remove the 4 screws holding BACK the Back-Cover at the back of the washing machine. BELT 1. Separate the belt and then assembly it. 2. Check if the belt position is at the center of the Pulley. Assembling the belt Place the belt around the Pulley ( ) and then over the Motor- Pulley ( ). MOTOR 1. Separate the Wire Housing from the motor. 2. Remove the two bolts holding the motor at the back of the washing machine. The 2 screws designated ‘A’ which are inside must be also removed. 3. Separate the motor. When installing the Belt around the Motor Pulley, the bottom of the belt must be located on the second floor of the Motor Pulley. 22 _ Removal and Reassembly WW22K6800AW-A2.indb 22 2015/12/3 16:08:47...
  • Page 23 No. Part name Description Figure BUBBLE 1.Press the upper part PUMP AND of the Filter Cover and DRAIN PUMP push it downwards to release the catch.Then seperate frame front 2.Remove the remaining water through the drain- age hose. Place a bowl under the drainage hose, or the remaining water may fl ow out. 3.Separate the Drain Filter by turning it counter- clockwise Since the remaining wa- ter may flow out, place a bowl underneath it when separating the filter. 4.Remove the 2 screws holding the Drain Pump. Removal and Reassembly _ 23 WW22K6800AW-A2.indb 23 2015/12/3 16:08:47...
  • Page 24 No. Part name Description Figure BUBBLE 6.Seperate the frame PUMP AND front, and then seperate DRAIN PUMP weight balance (Front). 7.Release all band ring to removal hose except for hose dain. Push the pump inwards slightly and remove it 8.Release the clamper hose which con- nected pump and hose drain,then seperate it. 9.seperate cover pump. 24 _ Removal and Reassembly WW22K6800AW-A2.indb 24 2015/12/3 16:08:48...
  • Page 25 No. Part name Description Figure BUBBLE 10.Disconnect the terminal PUMP AND of wires. DRAIN PUMP 11.Remove 3 screws as photograph, then sep- erate pump drain and replace it. ※Check Points for Troubleshooting 1.Separate the Drain Filter and check if any alien substances are inside the pump (e.g. coins, buttons .., etc.) → Remove these if found. 2.Check if the wire driving the pump is has come loose → Take the relevant countermeasure if necessary. 3.When water leaks, check the assembly status of the Clamp Hose, and Cap Drain → Take the relevant countermeasure if necessary. Turn the filter counterclockwise to remove the remaining water. Removal and Reassembly _ 25 WW22K6800AW-A2.indb 25 2015/12/3 16:08:48...
  • Page 26 Part name Description Figure WEIGHT- 1.Remove the three screws. BALANCE 2.Separate the WEIGHT- BALANCE(U). 3.Remove the three screws. 4.Separate the WEIGHT- BALANCE(F). For disassembly, please make sure assembled the BRACKET-NUT into the TUB first. Make sure the hole and hole respond to each other correctly. There is no ringt and left direction for WEIGHT- BALANCE(F). 26 _ Removal and Reassembly WW22K6800AW-A2.indb 26 2015/12/3 16:08:50...
  • Page 27 Part name Description Figure BUBBLE 1.First,seperate HOSE AIR frame front,weight JOINT balance(right) and case pump, Then release clampers, seperate hose air joint from tub and pump. HOSE-FILTER 1.Disassembling and Reassembling the Hose- Joint Clamper Disassembling and HOSE-FILTER TUB Reassembling the Hose- Joint Clamper Caution Take care when disassembling or reassembling the product, as the direction the screws turn used for this product differs from the standard direction for screws. 1. To disassemble it, turn the screw clockwise. 2. To reassemble it, turn the screw counterclockwise. Removal and Reassembly _ 27 WW22K6800AW-A2.indb 27 2015/12/3 16:08:50...
  • Page 28 Part Description Figure HEATER 1. Separate the Back Cover. 2. Separate the Connection Housing (3). 3. Remove the nut holding the heater and separate the Heater. 4. Remove the Heater from the Tub. Caution Make sure to insert the Heater into the correct position of the bracket inside the Tub when reassembling it. Otherwise, there is a danger of a fire. Make sure to push it inwards until the packing part comes into the Tub completely when reassembling it so that the packing part is completely stuck to the Tub. Fasten the holding nut with a force of 5Kgf/ cm2. If the nut is not fastened properly, there is a danger of water leaking. 28 _ Removal and Reassembly WW22K6800AW-A2.indb 28 2015/12/3 16:08:52...
  • Page 29 Part name Description Figure SPRING- 1. Insert the vertical hook of HINGER SPRINGHANGER into the GUIDE-SPRING on the ASSY-FRAME. 2.Drag the SPRING-HANGER to insert the elliptical hook into the hole that’s at the side of the ASSY-TUB as the left picture show. 3.Make sure the SPRING- HANGER’s two hooks are assembled right. Removal and Reassembly _ 29 WW22K6800AW-A2.indb 29 2015/12/3 16:08:53...
  • Page 30 Part Description Figure ASSY-TUB 1. Remove the 14 screws holding the tub . 2. Separate the ASSY-BOLT on the BACK-TUB. 3. Separate the PULLEY. 4. Separate the ASSY DRUM. PACKING- 1. Assemble packing-tub’s one side of “凹” to TUB-BACK use two hands. 30 _ Removal and Reassembly WW22K6800AW-A2.indb 30 2015/12/3 16:08:54...
  • Page 31 Part Description Figure OIL-SEAL 1. Assemble the OIL-SEAL in the TUB-BACK. 2. Press the OIL-SEAL gently and turn it back and forth. ASSY- 1. Remove the WASHER-WAVE DRUM from the SHAFT. 2. Remove the three screws holding the ASSY FLANGE SHAFT. Removal and Reassembly _ 31 WW22K6800AW-A2.indb 31 2015/12/3 16:08:55...
  • Page 32 Part Description Figure ASSY- 1. Remove the one screw DRUM holding the DRUM-LIFTER. 2. Release the HOOK. 3. Assemble the HOOK, DRUM- BACK, Holding it with screw. 32 _ Removal and Reassembly WW22K6800AW-A2.indb 32 2015/12/3 16:08:56...

  • Page 33: Troubleshooting

    4. TROUBLESHOOTINg 4-1. CHECK MODES ► This is a washer integrated check mode. for detailed information, refer to the general repair scripts. Check Check Type Causes Remarks Mode - The part of the hose where the water level sensor is located is damaged (punctured). - The hose is clogged with foreign material. - The hose is folded. Water Level - Too much lubricant has been applied to the insertion part of the air hose. Sensor - Hose engagement check. (disengaged) - Part fault. (Faulty internal soldering)
  • Page 34 Check Check Type Causes Remarks Mode - Check the consumer’s power conditions. : Make sure to check the operating voltage. Connect a tester to the internal power terminals during the Boil or Dry operations and observe the washing machine’s operation carefully. Power Check 9E1,9E2 : Check the voltages. (A check occurs when under or over voltage is supplied.) : Check whether a plug receptacle is used. When the connecting wire is 1m, a momentary low voltage may drop up to 10 V - Main PBA fault (sometimes) - The signals between the sub and main PBAs are not sensed because of commuication check. - Check the connector connections between the sub and main PBAs carefully. → Check for incorrect or loose connections, etc. - Remove the sub PBA C/Panel and check for any faulty soldering. - The diagnosis of the I/O Board communication check. - The signals between The DR Module and main PBAs are not sensed because of commuication check. - Check The connector connections between The DR Module and main PBAs carefully.
  • Page 35 Check Check Type Causes Remarks Mode - A switch contact check because of a deformation of the door When the door is not hook. opened after the door open operation. - When the door is pulled by force. When the door is not - This occurs in the Boil wash because the door is pushed due locked after the door to a pressure difference from internal temperature changes. close operation. - The door lock switch terminal is connected incorrectly. Door Check - The door lock switch terminal is broken. - This occurs intermittently because of an electric wire leakage - Main PCB fault. - This occurs if the Power switch is turned on/off continually and too much heat is generated (This check is difficult to be reproduced.) - The washing heater is short-circuited or has a wire disconnected. - The washing heater in the tub has a check. (Contact check, temperature sensor fault) If the heater has no check, this occurs - If the water level sensor operates without water because water...
  • Page 36 Check Check Type Causes Remarks Mode - The washing heater sensor in the tub has a check. (Contact check or temperature sensor fault) - The connector is connected incorrectly or is disconnected. Heater sensor fault - If the water level sensor operates without water because the : W hen the connector water is frozen or for any other reason and the temperature is connected sensor engaged at the bottom to prevent overheating for the incorrectly or has a washing heater detects a temperature of 100 to 150 ˚C, the wire disconnected or Temperature washing machine turns the input power off. contact check Sensor Check - The drying heater sensor in the tub has a check. (Contact check or temperature sensor fault) - IPM temperature is abnormally high. - As laundry causes this check, check the laundry. Unbalance - Find the reason for the unbalance and solve it as directed in Check the user manual. - This occurs when too much foaming is detected. It is also displayed while foaming is removed. When the removal is finished, the normal cycle proceeds.
  • Page 37 4-2. CORRECTIvE ACTIONS fOR EACH CHECK CODE Troubleshooting _ 37 WW22K6800AW-A2.indb 37 2015/12/3 16:08:56...
  • Page 38 38 _ Troubleshooting WW22K6800AW-A2.indb 38 2015/12/3 16:08:57...
  • Page 39 Troubleshooting _ 39 WW22K6800AW-A2.indb 39 2015/12/3 16:08:57...
  • Page 40 40 _ Troubleshooting WW22K6800AW-A2.indb 40 2015/12/3 16:08:57...
  • Page 41 Troubleshooting _ 41 WW22K6800AW-A2.indb 41 2015/12/3 16:08:57...

  • Page 42: Pcb Diagram

    5-1. MAIN PCB (DIM) Location Part No. function Description RY101 Main Relay/ Power Supply Terminal Receive 220 ACV to operate the PBA RY401 Heater Realy For driving the heater power CNP101 Power Supply Terminal Receive 220 ACV to operate the PBA CNS901 Motor Power Supply Terminal For Driving the Motor CNS801 Water Level and Thermal Sensor Connection Terminal Detect the water supply / Communicate with the Sub PBA CNP401 Valve and pump driver Driver water valve and pump motor 42 _ PCB Diagram WW22K6800AW-A2.indb 42 2015/12/3 16:09:00...

  • Page 43: Circuit Diagrams Of Main Parts For Main Pcb (Dim)

    5-2. CIRCUIT DIAgRAMS Of MAIN PARTS fOR MAIN PCB (DIM) ► CNS901 ► RY101 ► CNP101 1. MOTOR U 1. POWER N (AC1) 1. POWER L1 (AC1) 2. MOTOR V 2. AC_COMMON 2. AC_COMMON 3. MOTOR W ► RY401 1. WASH HEATER 2. AC_COMMON ► CNS801 ► CNP401 1. TXD TO SUB 5. GND 1. NC 6. NC...

  • Page 44: Sub Pcb

    5-3. SUB PCB Location Part No. function Description BZ601 Buzzer Circuit Generates sound when the menu key and encoder-key are operated or when the menu is closed. CN803 Main and Sub PCB Connection Port Main and sub PBA communication. CN201 Program Writing Attach the connector for writing the program when an upgrade or change of the program is required. DSP701 Display Displays the remaining time for the selected cycle,Displays the menu and progress status. CN503 Touch connector connect to touch sensor CN502 MEMS connector connect to MEMS 44 _ PCB Diagram WW22K6800AW-A2.indb 44 2015/12/3 16:09:01...

  • Page 45: Detailed Descriptions Of Contact Terminals For Sub Pcb

    5-4. DETAILED DESCRIPTIONS Of CONTACT TERMINALS fOR SUB PCB ► CN201 ► DSP701 Programm writing Display ► CN502 MEMS connector ► BZ601 ► CN803 ► CN503 Buzzer Circuit Main and sub PCB communication Touch connector PCB Diagram _ 45 WW22K6800AW-A2.indb 45 2015/12/3 16:09:02...

  • Page 46: Wiring Diagram

    6. WIRINg DIAgRAM 6-1. WIRINg DIAgRAM (DIM) ■ REfERENCE INfORMATION BLACK BLUE GREEN GRAY NATURAL ORANGE PINK SKYBLU SKYBLUE VIOLET WHITE YELLOW 46 _ Wiring Diagram WW22K6800AW-A2.indb 46 2015/12/3 16:09:02...

  • Page 47: Reference

    7. REfERENCE 7-1. WW6800K PROJECT NAME MODEL NAME IN THE MARKET BOM MODEL CODE ► Drum Machine Classification ► Color Code 3:Frame ► Capacity ► RPM Notation ► Buyer Code ► Color Code 1:Display Color according to type: W: WHITE 90: 9Kg 50: 5Kg 0: 1000rpm WW: Washer Front Loading 0: BLACK S: SILVER 80: 8Kg 40: 4Kg 2: 1200rpm WD: Washer & Dryer 3: SILVER 70: 7Kg...
  • Page 48 This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2015 Samsung Electronics Co.,Ltd. All Any unauthorized use of Manual can be punished under applicable rights reserved. International and/or domestic law. May. 21th 2015 WW22K6800AW-A2.indb 48 2015/12/3 16:09:02...
