lifesmart
®
is a registered trademark
of Supply Chain Sources, LLC., All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Purchase Date ____________Serial Number (
Questions, problems, missing parts? Contact technical support department at
657-341-0362, 9:00 a.m. - 5 p.m., PST, Monday - Friday or visit us online at
www.lifesmartcomfort.com
Please have your model and serial number ready
REV1-060717
INFRARED QUARTZ HEATER
& MULTIFUNCTION TOWER
located on back of unit
1
Customer number:
XXAC3004US, XXAC3012US
) __________________
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Life Smart XXAC3004US
Summary of Contents for Life Smart XXAC3004US
- Page 1 ® is a registered trademark of Supply Chain Sources, LLC., All Rights Reserved. Customer number: XXAC3004US, XXAC3012US ATTACH YOUR RECEIPT HERE Purchase Date ____________Serial Number ( ) __________________ located on back of unit Questions, problems, missing parts? Contact technical support department at 657-341-0362, 9:00 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Safety Information . -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Infrared Heater/Cooler/Humidfier Remote Control Control Panel (preassembled to Infrared Heater (A)) Easy Carry Handle (preassembled to Infrared Heater (A)) Filter Cover (preassembled to Infrared Heater (A)) Humidifier Chamber (preassembled to Infrared Heater (A)) -
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product . IMPORTANT SAFETY INSTRUCTIONS WARNING: POTENTIAL ELECTRICAL HAZARD IF NOT ADHERED TO . When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: •... - Page 5 SAFETY INFORMATION Tip-Over Safety Feature This heater is equipped with a tip-over safety feature . Once the heater is tipped over, an internal switch will automatically shut the heater off . Once the heater is restored to an upright position, the heater will reset .
-
Page 6: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Please review these frequently asked questions on the next few pages prior to using your heater . Q. My unit emits a strange odor when I first open the box and when I turn it on for the first time. Why is this happening? A . - Page 7 FREQUENTLY ASKED QUESTIONS Q. The temperature on my unit does not match the temperature display on my wall, or external thermostat. Why? A. This is completely normal . The temperature display on your unit may vary from the temperature display on another thermostat (like the one mounted to your wall or a purchased external thermostat) .
- Page 8 FREQUENTLY ASKED QUESTIONS Q. Can the unit be left outdoors? A . It is not recommended to leave your unit outside when it is not being used . (Think of it like a portable stereo - you can use it outdoors, but not recommended to leave outdoors .) Q.
-
Page 9: Preparation
PREPARATION Place the unit on a firm, level surface and plug into a grounded 120 V, 60 Hz power outlet . Only operate the unit in upright position . Insert two AAA batteries into the remote control before using (batteries not included) . *(Not all products will include a remote control .) Please note that infrared heaters do not heat like a traditional space heater . -
Page 10: Control Panel
CONTROL PANEL PART NAME DESCRIPTION Heat Button Engages the heating function Fan Button Cycles the Fan function between High/Medium/Low mode Mist Button Cycles the mist function between High/Low/Auto mode Temp-Up Button Increase the set temperature Temp-Down Button Decrease the set temperature Swing Button Activate/Deactivate oscillation function Power Switch Button... -
Page 11: Remote Control
REMOTE CONTROL PART NAME DESCRIPTION Temp Up Button Increases the set temperature value Heat Mode Button Engages the heating function Temp Down Button Decreases the set temperature value Power Button Powers the heater on or off Mist Button Cycles the mist function between High / Low / Auto Fan Button Cycles the Fan function between High / Medium / Low mode... -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS 1 . Turn the unit on or off by pressing the Power button on the control panel (C) or by pressing the Power button on the remote control (B) . Once the power is off, in heating mode, the heating elements will stop working first . - Page 13 OPERATING INSTRUCTIONS 5 . To activate the Mist function press the Mist mode button on the control panel (C) or the Fan mode button on the remote control (B) to tog- gle between the three mist settings high, low and auto which maintains a relative humidty level of approximately 40%-60% .
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE CLEANING THE AIR FILTER Clean the air filter (2) after three months or if it appears to be blocking airflow . With the unit unplugged, remove the two filter screws (1) as illustrated below . Clean all parts of the filter assembly and allow parts to completely dry . -
Page 15: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY The manufacturer warrants this heater against defects in materials and workmanship on functional parts, for a period of 1 year from the original date of purchase . Your sales receipt showing the date of purchase of the product is your proof of purchase . Keep it in a safe place for future reference . This warranty is subject to personal use only, commercial or rental applications will not be covered . -
Page 16: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our technical support department at 657-341-0362, 9:00 a.m. - 5 p.m., PST, Monday - Friday PART DESCRIPTION PART # Control panel COPA-MCAC FAN-MCAC Power board POBO-MCAC Tip-over switch TIPSW Limit switch LIMITSW Infrared tube QUAR-R750 Thermostat Wire SENSOR...
