Country Casual
Entertainment Credenza
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
H.
Plinth
1 pc.
I.
Base
1 pc.
R.
Back Support
1 pc.
Hardware List
Cam Lock Screw
28 pcs.(+1 extra)
Cam Lock
28 pcs.(+1 extra)
For assembly see instructions in carton 88 5538 102
Tools required for assembly : Phillips screwdriver
Casual Attire For Today's Home
Adjustable Pin
20 pcs.(+1 extra)
Wood Screw
for Plinth
2 pcs.(+1 extra)
J.
Back Panel
1 pc.
Wood Screw
for Back Panel
12 pcs.(+1 extra)
Machine Screw
Pull Handle
4 pcs.
4 pcs.
M.
Shelf
2 pcs.
