Summary of Contents for Plymovent MDB-Compact PRO Series
- Page 1 Central filter system with integrated fan MDB-COMPAC T Installation and user manual www.plymovent.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PREFACE ........................... 5 INTRODUCTION ......................5 PRODUCT DESCRIPTION ..................... 7 SAFETY INSTRUCTIONS ....................7 INSTALLATION ......................9 USE ......................... 12 MAINTENANCE ......................13 TROUBLESHOOTING ....................14 SPARE PARTS ......................14 ELECTRICAL DIAGRAM ....................14 DISPOSAL ........................ 15 CE DECLARATION ........................ -
Page 3: Preface
PREFACE INTRODUCTION Using this manual Identification of the product This manual is intended to be used as a work of reference for professional, well trained and authorised users to be able to The identification plate contains, among other safely install, use, maintain and repair the product mentioned things, the following data: on the cover of this document. - Page 4 Options and accessories Filter efficiency CART-D/C/E/PTFE - M according to DIN EN 60335-29 The following products can be obtained as an option and/or - MERV 11 according to ASHRAE 52.2 accessory: CART-MB MERV 16 according to ASHRAE 52.2 Certification Type Description MDB-Compact with W3 compliant (according to EN-ISO...
-
Page 5: Product Description
Ambient and process conditions Operation The polluted air from the external device is Process temperature: extracted through the air inlet module on the left - min. 5°C (41°F) side of the unit. The air then passes the filter - nom. 20°C (68°F) cartridges inside the housing. - Page 6 Users - The use of this product is exclusively reserved to authorised, WARNING! trained and qualified users. Temporary personnel and Fire hazard! Do not use the product for: personnel in training can only use the product under - polishing applications in combination with supervision and responsibility of skilled engineers.
-
Page 7: Installation
- Use sufficient climbing gear and safety guards when working on a higher level than 2 metres (6½ ft.) (local restrictions may apply). - Clean the area afterwards. MDB-Compact (fully assembled) ATTENTION MDB-Compact (semi-assembled) Service, maintenance and repairs must be performed in accordance with directive TRGS 560 - Cover plate (incl. - Page 8 ATTENTION To make the unit level, make sure that you support the angular points as well as the seam between the filter housing (A) and the fan housing (B). A: Inlet left B: Inlet top Fig. 4.2 Position of air inlet module Fig.
- Page 9 4.5.3 Air inlet module The open sides of the unit are provided with specially constructed seals to make the unit airtight. You must use SealApplicator (seal assembly lubricant) before you connect • Install the air inlet module in the same way as the cover plate (refer to paragraph 4.5.2).
-
Page 10: Use
• Do the same procedure for the remaining filter cartridge(s). • Disconnect the compressed air supply. • Put the precoat material in a bucket. • Start the fan. It must run at full speed. Electric connection • Gradually add the precoat material into the inlet of the unit (or into the inspection hatch, if any). -
Page 11: Maintenance
MAINTENANCE WARNING - Prevent excessive draughts. Periodic maintenance - Do not open the dust drawer while the fan is running. The product has been designed to function without problems for a long time with a minimum of To empty the dust drawer, do the following. maintenance. -
Page 12: Troubleshooting
• Seal the sack securely. Precoat (PRECO-N) / CART-D, CART-C and CART-E only (option) • Put a new filter cartridge on the cartridge holder (A) and attach it with the disassembled parts. • Refer to paragraph 4.9 for the precoat procedure. •... -
Page 13: Disposal
CE DECLARATION CE declaration of conformity for machinery We, Plymovent Manufacturing B.V., Koraalstraat 9, 1812 RK Alkmaar, the Netherlands, herewith declare, on our own responsibility, that the products:... - Page 14 ANNEX Fig. I Dimensions MDB-2/Compact MDB-4/Compact MDB-6/Compact Front view inch inch inch A 1348 53⅛ 1801 70⅞ 2004 78⅞ B 1502 59⅛ 1955 2158 C 1186 46¾ 1190 46⅞ 1641 64⅝ Top view inch inch inch D 1197 47⅛ 1206 47½...
- Page 15 ANNEX Fig. II Performance chart (60 Hz) 3500 3000 2500 MDB-6/COMPACT 2000 1500 MDB-4/COMPACT 1000 MDB-2/COMPACT 1000 2000 3000 4000 5000 6000 7000 8000 Airflow m³/h 1000 1500 2000 2500 3000 3500 4000 4500 Airflow cfm Net extraction capacity at the filter inlet (new/clean filter cartridges) 0000104046/010822/A MDB-Compact PRO...
- Page 16 ANNEX Fig. III Lifting instructions 90° max. 45° 0000104046/010822/A MDB-Compact PRO...
- Page 17 ANNEX Fig. IV Hole pattern | bottom view (M10x25) MDB-2/Compact MDB-4/Compact MDB-6/Compact inch inch inch 1198 47⅛ 1205 47½ 1205 47½ 35¾ 35¾ 35¾ 1199 47¼ 1649 64⅞ 1849 72¾ 1516 59⅝ 1965 77⅜ 2182 85⅞ 3⅛ 3⅛ 3⅛ Ø 11 Ø...
- Page 18 ANNEX Fig. VI Exploded view MDB-Compact 0000103150 0000100297 0000100353 0000100354 0000100356 0000102315 0000104642 0000110003 0000110004 0000100351 (6x) 0000102598 0000102666 0000103138 0000301426 0000103126 0000103127 0806010120 0000103148 0000103135 0000103136 0000103137 0000100539 0000100542 0000100547 0000100344 0000101349 0000100345 0000103133 0000100346 0000103134 0000102530 0000102532 0000103162 0000103139 0000103142 0324000300...
- Page 19 ANNEX Fig. VII Spare parts MDB-Compact Article no. Description General 0000100297 CART-PTFE/10 / Filter cartridge 0000100351 TEV-AV/79 / Vibration dampers (6 pcs) 0000100353 CART-C / Filter cartridge 0000100354 CART-E / Filter cartridge 0000100356 CART-D Premium Plus / Filter cartridge 0000101373 PRECO-N (1 kg) / Precoat material 0000102315 CART-MB / Filter cartridge...
- Page 20 0000104046/010822/A MDB-Compact PRO www.plymovent.com...
