Sony SS-CN700ED Service Manual page 27

SS-CN700ED/CR700ED/SR700ED
EXPLODED VIEW AND PARTS LIST
NOTE:
• Items marked "*" are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• Hardware (# mark) list and accessories and pack-
ing materials are given in the last of this parts list.
CENTER SPEAKER
SS-CN700ED
#2
SP1
#2
#2
1
Ref. No. Part No. Description
1 X-4955-920-1 FRAME (CENTER) ASSY, GRILL
2 4-250-035-01 SIDE PANEL
3 4-250-034-01 SPEAKER CABINET (CENTER)
4 4-250-030-01 TERMINAL BASE (CENTER)
5 4-250-054-01 BASE (CENTER)
6 4-250-055-01 CUSHION (BASE)
7 4-250-050-01 FOOT (CENTER)
8 4-912-253-01 CATCHER
2
2
not supplied
#2
8
#1
SP3
#1
#2
#2
SP2
Remark
not supplied
3
#4
#4
#2
#2
8
6
7
7
Ref. No. Part No.
SP1 1-825-556-11 SPEAKER (8cm)
SP2 1-825-556-11 SPEAKER (8cm)
SP3 1-825-558-11 SPEAKER (2.5cm)
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-660-19 SCREW +BVTP 4X10 TYPE2 N-S
#4 7-685-659-79 SCREW +BVTP 4X8 TYPE2 N-S
not supplied
#4
#4
#2
6
5
Description
4
2
Remark
