Sony SS-CN700ED Service Manual page 24

Ref. No. Part No. Description
< TRANSISTOR >
Q201 8-729-036-89 TRANSISTOR KTC3198GR-A
Q202 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q701 8-729-029-86 TRANSISTOR DTC124ESA
Q703 8-729-178-42 TRANSISTOR 2SC2784-F
Q704 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q705 8-729-029-86 TRANSISTOR DTC124ESA
Q901 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
< RESISTOR >
R201 1-249-429-11 CARBON
R202 1-249-429-11 CARBON
R216 1-249-393-11 CARBON
R217 1-249-393-11 CARBON
R701 1-215-869-11 METAL OXIDE
R702 1-247-887-00 CARBON
R703 1-249-441-11 CARBON
R704 1-249-433-11 CARBON
R705 1-249-441-11 CARBON
R706 1-249-441-11 CARBON
R707 1-249-427-11 CARBON
R708 1-249-427-11 CARBON
R709 1-249-433-11 CARBON
0 R902 1-219-237-11 SOLID
0 R904
1-215-901-00 METAL OXIDE
0 R904 1-218-642-11 METAL OXIDE
0 R905
1-247-895-91 CARBON
0 R906 1-247-807-31 CARBON
R907 1-249-429-11 CARBON
R908 1-249-393-11 CARBON
R909 1-249-421-11 CARBON
R910 1-244-317-71 METAL
R910 1-240-858-71 METAL
R911 1-219-984-51 METAL
R911 1-244-398-71 METAL
R912 1-249-415-11 CARBON
R913 1-249-426-11 CARBON
R914 1-249-419-11 CARBON
R915 1-249-417-11 CARBON
R916 1-249-420-11 CARBON
0 R917
1-249-381-11 CARBON
0 R918
1-249-381-11 CARBON
0 R920 1-247-807-31 CARBON
< RELAY >
RY701 1-515-920-11 RELAY (24V)
0 RY801 1-755-458-11 RELAY
< TRANSFORMER >
0 T901
1-437-232-11 TRANSFORMER, POWER (US,CND)
0 T901
1-437-233-11 TRANSFORMER, POWER (AEP,UK)
0 T902 1-437-793-11 TRANSFORMER, POWER (US,CND)
0 T902
1-437-794-11 TRANSFORMER, POWER (AEP,UK)
< THERMISTOR >
0 THP901 1-803-916-11 THERMISTOR, NTC
******************************************************
Remark Ref. No.
******************************************************
10K 5% 1/4W
10K 5% 1/4W
10 5% 1/4W F
10 5% 1/4W F
1K 5% 1W
220K 5% 1/4W
100K 5% 1/4W *
*
22K 5% 1/4W
100K 5% 1/4W
100K 5% 1/4W
6.8K 5% 1/4W F
6.8K 5% 1/4W F ******************************************************
22K 5% 1/4W
3.3M 20% 1/2W
(AEP,UK)
33K 5% 2W
(US,CND)
100K 5% 1W
(AEP,UK)
470K 5% 1/4W
100 5% 1/4W
10K 5% 1/4W
10 5% 1/4W F
2.2K 5% 1/4W F
0.18 5% 2W
(US,CND) *****************************************************
0.27 5% 2W
(AEP,UK)
0.1 5% 2W
(US,CND)
0.3 5% 2W
(AEP,UK)
680 5% 1/4W F
5.6K 5% 1/4W
1.5K 5% 1/4W F
1K 5% 1/4W F
1.8K 5% 1/4W F
1 5% 1/4W F
1 5% 1/4W F
100 5% 1/4W
POWER SELECT
Part No. Description
1-689-583-11 SELECT BOARD
***********
4-248-894-01 KNOB (SELECT)
< SWITCH >
S101 1-762-115-11 SWITCH, PUSH (1 KEY) (INPUT SELECTOR)
S102 1-762-115-11 SWITCH, PUSH (1 KEY) (POWER SAVE)
S103 1-762-115-11 SWITCH, PUSH (1 KEY) (PHASE)
S104 1-762-115-11 SWITCH, PUSH (1 KEY) (BOOST)
1-689-584-11 VOL CONTROL BOARD
****************
4-248-893-01 KNOB (VOLUME)
< CONNECTOR >
CN910 1-506-999-11 PIN, CONNECTOR (PC BOARD) 3P
CN912 1-566-693-11 PIN, CONNECTOR (3.96mm PITCH)2P
< VARIABLE RESISTOR >
VR101 1-225-826-11 RES, VAR, CARBON 20K (SW LEVEL)
MISCELLANEOUS
*************
57 1-696-169-22 CORD, POWER (AEP,UK)
57 1-783-531-72 CORD, POWER (US,CND)
SP101 1-825-556-11 SPEAKER (8cm)
SP102 1-825-556-11 SPEAKER (8cm)
SP103 1-825-557-11 SPEAKER (11cm)
SP104 1-825-558-11 SPEAKER (2.5cm)
SP901 1-825-556-11 SPEAKER (8cm)
SP902 1-825-556-11 SPEAKER (8cm)
SP903 1-825-557-11 SPEAKER (11cm)
SP904 1-825-558-11 SPEAKER (2.5cm)
ACCESSORIES
***********
1-770-019-51 ADAPTOR, CONVERSION PLUG (UK)
1-827-595-11 CORD (WITH CONNECTION) (4P) (5m)
1-827-596-11 CORD (WITH CONNECTION) (PIN-PLUG) (5m)
4-249-491-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
4-249-491-21 MANUAL, INSTRUCTION (SPANISH, GERMAN)
4-249-491-31 MANUAL, INSTRUCTION (DUTCH, ITALIAN)
4-249-491-41 MANUAL, INSTRUCTION (SWEDISH, POLISH)
4-249-491-61 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
SA-VF700ED
VOL CONTROL
Remark
(For SUBWOOFER)
(AEP,UK)
(AEP)
(AEP)
(AEP)
(US,CND)
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
23
