- Page 1 Deluxe Mobile Reversible Board ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 08/15/2022 1 of 6...
- Page 2 Parts List Hardware P1 - Leg A - M6 Screw P2 - Tray B - Drill Screw P3 - Cross Brace C - Flange P4 - Framed Board D - Knob E - Locking Casters F -Non-Locking Casters G - Caster Wrench UPDATED AS OF: 08/15/2022 2 of 6...
- Page 3 WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Previo a comenzar el proceso de Avant de commencer l’ assamblage check that all parts are present before ensamblaje favor revisar veuillez consulter instructions beginning assembly. Heavy or large instrucciones y asegurarse que cuenta con complètes et vérifier si vous avez toutes furniture may require multiple persons in...
- Page 4 Attach 2 Locking Casters (E) and 2 Non-Locking Attach Cross Brace (P-3) to Casters (F) to Legs (P-1) as shown. Screws (A). Attach 2 Locking Casters (E) and 2 Non-Locking Casters (F) to Legs (P-1) as shown. STEP 1 sters (E) and 2 Non-Locking Attach Cross Brace (P-3) to Legs (P-1) using 2 P-1) as shown.
- Page 5 Locking Casters (E) and 2 Non-Locking Attach Cross Brace (P-3) to Legs (P-1) using 2 Tighten Casters using Caster Wrench (G). F) to Legs (P-1) as shown. Screws (A). Attach 2 Flanges (C) to theF Remove 2 Screws from each side of Framed Board (P4). using 4 Screws removed in S Remove 2 Screws from each side of Framed Board (P4).
- Page 6 Spread the frame assembly at the top and insert the Framed Board(P-4) between STEP 5 Legs(P-1) and attach Flanges (C) to the legs using 2 Knobs (D). Assemble Tray (P-2) to Legs (P-1) using 6 Drill Screws (B). STEP 6 THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 08/15/2022 6 of 6...
