Samsung UN40H4203AH Service Manual page 64

Level Loc. Part Code
.2 M-F BN39-01929M
.2 P001A BN44-00754A
.2 WIFI BN59-01174A
.2 CB07 BN61-10765A
.2 FL06 BN96-31086R
.2 SP01A BN96-32738A
.2 FB01A BN96-32965B
1 M0017 BN91-13320B
.2 M0014 BN94-07823N
..3 AH020 BN62-00659A
..3 T0527 BN68-00513A
..3 BN97-07144A
...4 BN46-00109H
...4 BN46-00110N
..3 BN97-08898A
...4 0202-001899
...4 0403-001783
...4 0404-001404
...4 0406-001200
...4 0406-001628
...4 0406-001635
...4 0501-000445
...4 0505-002560
...4 0505-002598
...4 0505-002893
...4 0505-003397
...4 1001-001545
...4 1103-001487
...4 1105-002527
...4 1105-002529
...4 1201-003690
...4 1203-004363
...4 1203-006017
...4 1203-006130
...4 1203-007238
...4 1203-007242
...4 1203-007984
...4 1203-008104
...4 1203-008105
...4 1203-008118
Copyright© 1995-2013 SAMSUNG. All rights reserved.
Description & Specification
LEAD CONNECTOR-FUNCTION;40H4203,Lead Con
DC VSS-LED TV PD BD;L40G0B_ESM,L40G0B_ES
NETWORK-WIFI MODULE;WIDT-30Q,Internal Wi
BRACKET-PCB;H4203,SECC,T0.5
ASSY CABLE P-FFC;UE40H4200,FFC,NH,250mm,
ASSY SPEAKER P;6ohm,10W,holderless_PDP-r
ASSY BOARD P-JOG SWITCH & IR;UH4200,FUNC
ASSY CHASSIS;H4203
ASSY PCB MAIN;H4203,40"
HEAT SINK;UN55H6203AFXZA,A6063,BLACK
LABEL-E,PASS;ALL MODEL,YUPO(110G),BLACK,
ASSY DRM-KEY;HDCP(BN46-00110N),MAC(BN46-
KEY CODE-CERTIFI;MAC,TV/AV,General
KEY CODE-CERTIFI;MIRACAST,TV,X12 /X13
ASSY SMD;H4203,BN41-02253*
SOLDER-CREAM;M705-GRN360-K2-VT,25-36um,S
DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70
DIODE-TVS;AOZ8804ADI,6/-/-V,150W,SLP2510
DIODE-TVS;SMF5.0A,6.4V, 6.7V, 7V,200W,SM
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
FET-SILICON;AO6415,P,-20V,-3.3A,0.15ohm,
FET-SILICON;AP2317GN,P,-20V,-4.2A,0.052o
FET-SILICON;AO4801AS,P,-30V,-5A,2W,SOIC-
FET-SILICON;2N7002K,N,60V,380mA,1.19ohm,
IC-ANALOG MULTIPLEX;TS3USB221ERSER,R-PQF
IC-EEPROM;AT24C256C-SSHL-T,256Kbit,32Kx8
IC-DDR3 SDRAM;K4B2G1646Q-BCK0,DDR3,2Gbit
IC-DDR3 SDRAM;K4B4G1646D-BCK0,DDR3 1600,
IC-AUDIO AMP;TAS5747PHPR,QFP,48P,DUAL,PL
IC-VOL. DETECTOR;SOT-23,3Z30,2.9x1.6mm,P
IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9
IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8
IC-PWM CONTROLLER;TPS54427,DDA,8P,4.8x3.
IC-POSI.ADJUST REG.;G2992BP11U,SOP-8,8P,
IC-DC/DC CONVERTER;AOZ3015PI,SO-8,8P,6.2
IC-POSI.FIXED REG.;S-13A1D18-E8001,HSOP,
IC-POSI.FIXED REG.;S-13A1D33-E8001,HSOP,
IC-DC/DC CONVERTER;AOZ3013PI,SO-8,8P,4.9
Exploded Views and Parts List
Qty. SA/SNA
1 SA
1 SA
1 SA
1 SNA
1 SA
1 SA
1 SA
1 SNA
1 SA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
0 SNA
2 SNA
2 SA
2 SA
1 SA
5 SA
2 SC
1 SA
1 SA
1 SA
5 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SNA
1 SA
1 SA
2 SNA
1 SNA
3 SNA
5
