Global Truss ST-180 User Manual

Light stand
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

ST-180 PRODUCT DESCRIPTION

Thank you for choosing an ST-180 light stand from Global
Truss America. This stand has been designed to have a low
loading height, obtained by a multi-mast configuration. The
telescopic masts are made of treated steel and have been sized
in order to obtain maximum rigidity. Special attention has been
placed on security. The spring loaded safety pins guarantee
extra security when operating the stand and as a third safety
device, each mast can also be secured with a tension knob.
The ST-180 is equipped and shipped with
A: Heavy duty casters for vertical and horizontal transport
B: Heavy duty steel body and base
C: Nylon guided adjustable leg brace turnbuckles
D: Galvanized steel leveling screw jack feet
E: Heavy duty steel outriggers
F: Large tension knobs
G: Manual cable winch with built in safety brake
H: Spring loaded safety pins
F
G
D
C
Global Truss ST-180 User Guide
H
B
A
A
E
Page
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-180 and is the answer not in the manual?

Questions and answers

Related Manuals for Global Truss ST-180

Summary of Contents for Global Truss ST-180

  • Page 1 Global Truss ST-180 User Guide ST-180 PRODUCT DESCRIPTION Thank you for choosing an ST-180 light stand from Global Truss America. This stand has been designed to have a low loading height, obtained by a multi-mast configuration. The telescopic masts are made of treated steel and have been sized in order to obtain maximum rigidity.
  • Page 2 Global Truss ST-180 User Guide ST-180 Technical Specification SETTING UP THE STAND ALL SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE 1) Place the stand in the vertical position on its wheels. 2) Ensure that the ground is firm enough to prevent the stand from...
  • Page 3 IMPORTANT 1) All equipment that is being raised by the cranks stands should be secured with Global Truss TUV rated clamps and safety cables prior to raising the mast to the desired working height. 2) One operator per stand is required when using the stands in pairs to lift trussing.
  • Page 4 Global Truss ST-180 User Guide ATTACHING TRUSS Attach the STSB-006 truss adapters (Sold separately) to the round tube mast. Tighten the tension knob on the adapter to prevent the adapter from spinning. Attach the truss to the truss adapters and secure the truss using...
  • Page 5 2) During the 12 month warranty period, Global Truss or one of our 4) All electrical devices hung on truss or T bars supported by the...
