PRODUCT USAGE

OPTIONAL ATTACHMENTS

KitchenAid offers a wide range of optional attachments such as Food Grinders or Pasta
Makers. They may be attached to the Stand Mixer attachment power shaft, as shown
here.
1
Turn the speed control to "0" (OFF).
Unplug the Stand Mixer.
3
Insert attachment into attachment hub,
making certain that attachment power
shaft fits into the square attachment hub
socket.
5
To remove: Turn speed control to "0"
(OFF) and then unplug the Stand Mixer.
NOTE: See the Use and Care Guide of each specific attachment for recommended
speed settings and operating times.
10
W11395148A.indb 10
2
Flip up hinged attachment hub cover to
open.
4
Tighten attachment knob by turning it
clockwise until the attachment is secured
to the Stand Mixer.
6
Loosen attachment knob by turning it
counterclockwise. Rotate attachment
slightly back and forth while pulling it out.
