Summary of Contents for Nauticam NA-E2F
-
Page 1: Table Of Contents
NA - E2F For Z CAM E2-M4/S6/F6/F8 Cinema Camera PN 16505 User Manual Housing N120 Video Housing Introduction Package Contents Important Instructions Part Names and Functions Opening the Housing Closing the Housing Preparation for Use Recommended Accessory Care/Storage Warranty Specifications... -
Page 2: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA-E2F Padded Travel Case... -
Page 3: Important Instructions
O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specified by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product. -
Page 4: Part Names And Functions
PART NAMES AND FUNCTIONS Rear View Fn1 button Fn2 button IRIS + button IRIS - button Playback button M28 Accessory port M16 Accessory port REC button Focus + button Focus - button eND + button eND - button Moisture alarm window... - Page 5 PART NAMES AND FUNCTIONS Top + Front Views LCD Window Shutter / Up button Menu button Power button ISO/FN button 1/4”-20 size mounting threads 2x M16 Accessory ports EV / Down button Fn3 button OK button M16 Accessory port Zoom knob LOCK lever Port lock safety button Port locking lever Port index mark...
- Page 6 PART NAMES AND FUNCTIONS Back + Side Views 1/4” Threaded tripod holes Zinc Anodes Focus knob Housing unlock button Zoom knob...
-
Page 7: Opening The Housing
OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock latch anti-clockwise to open the housing flip open the back housing when lock latch is aligned to ‘open’ position... -
Page 8: Closing The Housing
CLOSING THE HOUSING * drawings as illustrations only before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking main O-ring insert the housing shaft into the shaft hole and then rotate the lock latch clockwise until you hear and feel it click into place... -
Page 9: Preparation For Use
PREPARATION FOR USE * drawings as illustrations only Installing the Camera unlock camera tray lever and remove the tray from the housing attach the camera tray by tightening the tray screw into the tripod socket of the camera turn zoom and focus knob lock levers to REL positions. - Page 10 PREPARATION FOR USE * drawings as illustrations only Installing the Camera lock camera tray Then, connect LANC control cable Place the zoom and focus knobs in place by turning the knob lock levers and make sure it is engaged with lens gears...
- Page 11 PREPARATION FOR USE * drawings as illustrations only Port Mounting depress port lock safety button and rotate anti-clockwise lubricant the port O-ring before mounting align index mark push port assembly straight in rotate locking lever clockwise to lock...
- Page 12 PREPARATION FOR USE * drawings as illustrations only Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
- Page 13 PREPARATION FOR USE * drawings as illustrations only Setting up moisture alarm CR2032 Battery Alarm ON/OFF remove battery press the battery down until it insulation film click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will flash in dampened cotton bud;...
- Page 14 PREPARATION FOR USE * drawings as illustrations only Changing lens/port after vacuum If using with vacuum valve : remove the cap from the vacuum valve and press the red button to release pressure before unlocking port lock If using without vacuum valve, please follow from step 2 unlock port lock After remove port assembly,...
-
Page 15: Recommended Accessory
RECOMMENDED ACCESSORY * drawings as illustrations only Connecting with external monitor (HDMI2.0 cable) Unscrew M28 accessory port cap Insert the HDMI 2.0 cable #25079 M28A2R210- M28A1R170 HDMI 2.0 Cable Gently push the cable into the M28 port opening of the housing, until it cannot go in any further. - Page 16 RECOMMENDED ACCESSORY * drawings as illustrations only Connecting with external monitor (HDMI2.0 cable) Install the camera with battery by sliding the attached saddle along the rail in the housing until it cannot go in any further Use the positioning guide on the rear housing to hold the cable in position.
- Page 17 RECOMMENDED ACCESSORY * drawings as illustrations only Vacuum valve system remove the plug of M16 accessory port from the housing remove the cap from the vacuum hand pump valve slightly lubricate the o-ring and vacuum valve tighten the vacuum valve to the accesory port housing with the tool provided on housing...
-
Page 18: Care/Storage
CARE/STORAGE Soak the housing system in fresh water Operate all controls and buttons at after salt water usage least 3 times while immersed in fresh water We recommand cleaning and inspecting Protect the housing with robust and the main O-ring each time after diving for shock-proof travel case during trans- any damage and every time the housing portation. -
Page 19: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals. -
Page 20: Specifications
25625 M16 Vacuum Valve II (Pushbutton Release) Monitor options 25221 M10 strobe mounting ball for housing 17922 Nauticam Atomos Ninja V Housing for Atomos Ninja V 5” (excl. HDMI 2.0 cable) 16232 0.25kg Trim Weights for 16227 (4pcs) 16233 0.5kg Trim Weights for 16227 (4pcs) HDMI connectivity accessories ( 1.4 ) - Page 21 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
