- Page 1 Original operating manual Measuring method for the lateral distribution EasyCheck SmartLearning www.amazone.de...
- Page 3 TABLE OF CONTENTS TABLE OF CONTENTS 1 Product description 2 Checking the lateral distribution 3 Cleaning the mats MG6126-EN-II | F.1 | 30.05.2022...
- Page 5 1 | Product description Product description CMS-T-00000641-B.1 EasyCheck is part of the mySpreader app. With EasyCheck, the lateral distribution of the fertiliser is measured and setting recommendations are given to improve the lateral distribution. The fertiliser is collected on 16 rubber mats. The rubber mats are photographed with a smartphone or tablet, and the pictures are evaluated.
- Page 6 EasyCheck app. While spreading, the fertiliser is collected on 16 mats. In the EasyCheck app, there is a symbol for each of the 16 mats. Using the mat symbols, a picture can be taken and evaluated for each corresponding mat.
- Page 7 NOTE The first row of mats must be placed in a tramline. The mat spacing specified in the EasyCheck app is based on the centre of the mats. In the direction of travel, the mats must be spaced at least 1 m apart.
- Page 8 If the fertiliser spreader spreads beyond the next tramline, drive in tramline 3 and spread. To take a picture of a mat, tap on a mat symbol in the EasyCheck app. NOTE The following table shows a correct example and a negative example for the picture.
- Page 9 2 | Checking the lateral distribution Correct Shadow Soiled Too close Too far Crooked 10. Take a correct picture of the mat corresponding to the mat symbol. The results of the evaluation is shown. NOTE Each white spot on the figure represents a grain of fertiliser.
- Page 10 2 | Checking the lateral distribution 12. Take a valid picture of each mat using the corresponding mat symbol. 13. Select "CONTINUE". CMS-I-00000538 MG6126-EN-II | F.1 | 30.05.2022...
- Page 11 2 | Checking the lateral distribution 14. Adjust the fertiliser spreader using the values under "Optimised settings". NOTE Recommendations The values under "Optimised settings" can be changed as needed. The values will be documented. 15. Select "FINISHED". 16. Confirm spreader settings. The results of the check will be stored in the history of the mySpreader app.
- Page 12 3 | Cleaning the mats Cleaning the mats CMS-T-00004870-A.1 Clean the mats thoroughly with normal household cleaning agents. MG6126-EN-II | F.1 | 30.05.2022...
- Page 14 AMAZONEN-WERKE H. DREYER SE & Co. KG Postfach 51 49202 Hasbergen-Gaste Germany +49 (0) 5405 501-0 amazone@amazone.de www.amazone.de MG6126-EN-II | F.1 | 30.05.2022...
