TM
FLASHFOLD
Bottom-Up Curtain
This Manual Covers Serial No. 42994 and Units Shipped to Date, Refer to 1390B for Units Prior to 3-13-2008.
PRINTED IN U.S.A.
Publication No. 1390E
email: printshop@RITEHITE.com
April 2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLASHFOLD 1390 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RITE-HITE FLASHFOLD 1390

Summary of Contents for RITE-HITE FLASHFOLD 1390

  • Page 1 FLASHFOLD Bottom-Up Curtain This Manual Covers Serial No. 42994 and Units Shipped to Date, Refer to 1390B for Units Prior to 3-13-2008. PRINTED IN U.S.A. Publication No. 1390E email: printshop@RITEHITE.com April 2014...

  • Page 2: Table Of Contents

    Program (P.M.P.) which can be fitted to your specific operation. be constructed and printed so that exposure to weather condi- Call your local representative or RITE-HITE MACHINE GUARDING at 1-563-587-4401 or toll free at 1-800-553-5560. If tions or wet and damp locations...

  • Page 3: Installation Instructions

    FLASHFOLD ™ MODEL 1390 INSTALLATION INSTRUCTIONS Quantity Description Crate Containing the following WA R N I N G ! ! ! Header Container Covers Curtain Container When working with electrical or electronic controls, make sure Curtain Container Floor that the power source has been locked out and tagged according Header Guides to OSHA regulations and approved local electrical codes.

  • Page 4: Frame Installation

    FLASHFOLD ™ MODEL 1390 FRAME INSTALLATION Pre-Installed Brackets may be Turned 1/4” [6] Hex 90° for Mounting to Wall Bolts with T-Nuts or Weld Unit Floor Mount Bracket for Both Slide Header Guide Over T-Nuts Single Outside Floor Sides of Header Guides Mount Bracket Header Guides Flush with Bottom of Curtain...
  • Page 5 FLASHFOLD ™ MODEL 1390 HEADER INSTALLATION OPTIONAL INTERRUPT SWITCH PLACEMENT Belting Header Non-Drive Idle Pulley NOTE: The interrupt switch is a cam style switch. It is at the top of the non-drive curtain guide. Place the curtain in the up position. Adjust position of switch in curtain guide until switch is aligned with the curtain, Figure 5.4.
  • Page 6 FLASHFOLD ™ MODEL 1390 DRIVE INSTALLATION Install motor assembly onto the drive bracket using (4) Route the drive belting from the header attachment point M8-1.25 x 25mm bolts, lock washers and a 13mm socket, up to the idler pulley onto the backside of the idler pulley, Figure 5.5.
  • Page 7 FLASHFOLD ™ MODEL 1390 CURTAIN/GUIDE INSTALLATION Wrap Curtain Around the Header and use the Hook and Loop Fastener to Assemble Place the bottom of the curtain into the bottom of the curtain container and tek screw the ABS strip, and the steel strip at the bottom braces on the frame of the curtain container.
  • Page 8 FLASHFOLD ™ MODEL 1390 COVER INSTALLATION Reversing Edge Cable Reversing Edge Housing Place reversing edge on top of curtain bar and fasten evenly spaced every 12” -18” [305 - 457] Route reversing edge cable/chain in the groove on the header guides and fasten with bolt on motor Reversing Edge plate.
  • Page 9 FLASHFOLD ™ MODEL 1390 LIMIT SWITCH INSTALLATION Center Adjustment Screw #1 Close Limit Open Limit #2 Open Limit Contact Blocks Switch Screw Switch Cam Switch Screw Close Limit Contact Block Switch Cam Wiring Layout The limit switch is pre-mounted to the top of the motor POWER UP/START UP mount bracket with the small sprocket attached.

  • Page 10: Limit Switch Adjustments

    Observe the closing action to make sure that the curtain operates smoothly, and fully closes without excessive curtain ripple near the bottom. RITE-HITE MACHINE GUARDING PLANNED MAINTENANCE Model 1390 FLASHFOLD™ CUSTOMER:...
  • Page 11 FLASHFOLD ™ MODEL 1390 NOTES PAGE This page intentional left blank. PUB. NO. 1390E APRIL 2014...
  • Page 12 FLASHFOLD ™ MODEL 1390 FIELD WIRING DIAGRAM PUB. NO. 1390E APRIL 2014...
  • Page 13 FLASHFOLD ™ MODEL 1390 ELECTRICAL WIRING DIAGRAM PUB. NO. 1390E APRIL 2014...
  • Page 14 FLASHFOLD ™ MODEL 1390 CONTROL BOX LAYOUT 17,20 16,18,21 11,13 8,9,10 6,23 7,22 5210E031 Rev. C 10/04/2011 Control Box Layout 15,16 30,31 15,16 6,24 ITEM DESCRIPTION PART NUMBER Control Box Assembly 1746..Circuit Breaker, Overload, 1.6-5A 16660008 Contactor, Interlock, MCS 17000010 Contactor 24VAC, 16amp, 50/60Hz, 1NO 17000020...
  • Page 15 FLASHFOLD ™ MODEL 1390 SERVICE PARTS 45,46 1,2,3 9,10 48,49 24,42 18-20 PUB. NO. 1390E APRIL 2014...

  • Page 16: Service Parts/List

    FLASHFOLD ™ MODEL 1390 SERVICE PARTS LIST ITEM QTY DESCRIPTION PART # ITEM QTY DESCRIPTION PART # Container, Curtain Ass’y 1721..Shroud Drive Pulley Guard 69200090 (Includes Covers, Floor & HDW) Retaining Ring 67020016 Container, Curtain Weldment 1722..1.427’ Chain Drive #35 16600019 Container, Curtain Covers 1873..

  • Page 17: Architectural Drawing

    FLASHFOLD ™ MODEL 1390 ARCHITECTURAL DRAWING PUB. NO. 1390E APRIL 2014...
  • Page 18 FLASHFOLD ™ MODEL 1390 NOTES PAGE This page intentional left blank. PUB. NO. 1390E APRIL 2014...
  • Page 19 FLASHFOLD ™ MODEL 1390 NOTES PAGE This page intentional left blank. PUB. NO. 1390E APRIL 2014...

  • Page 20: Warranty

    RITE-HITE or its agent, a reasonable opportunity to inspect any Product claimed to be defective and shall, at RITE-HITE’s option, either (x) grant RITE-HITE or its agent access to Owner’s premises for the purpose of repairing or replacing the Product or (y) return of the Product to the RITE-HITE, f.o.b.
