Bose® MB210
Compact Subwoofer
Installation Guide*
Installationsvejledning*
Installationsanleitung*
Guía de instalación*
Guide d'installation*
Guida all'installazione*
Installatiehandleiding*
Installationsanvisning*
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bose Professional MB210
Summary of Contents for Bose Professional MB210
- Page 1 Bose® MB210 Compact Subwoofer Installation Guide* Installationsvejledning* Installationsanleitung* Guía de instalación* Guide d’installation* Guida all’installazione* Installatiehandleiding* Installationsanvisning* * For use by professional installers only. * Kun til brug for erfarne installatører. * Montage ausschließlich durch ausgebildetes Installationspersonal. * Para uso exclusivo de instaladores capacitados.
-
Page 2: Important Safety Instructions
Important Safety Instructions pro.Bose.com Please read and keep all safety and use instructions. This product is intended for installation by professional installers only! This document is intended to provide professional installers with basic installation and safety guidelines for this product in typical fixed-installation systems. Please read this document and all safety warnings before attempting installation. -
Page 3: Product Features
Bose Professional F1 portable, powered subwoofer, in a compact, Baltic-birch plywood enclosure optimized for fixed-installation applications. Featuring outstanding performance to size ratio, the MB210 is designed to complement Bose Professional FreeSpace®, Panaray®, and RMU loudspeaker models with additional bass impact. -
Page 4: Installation
AND 4-PIN EURO BLOCK CONNECTOR Front View Right View Rear View BRACKET REMOVED DIMENSIONS APPLY TO BOTH SIDES Connector Panel The MB210 subwoofer includes the following connections (all wired in parallel): q Euroblock connector (4-pin) w NL4 connectors Installation Guide - 9... - Page 5 Installation pro.Bose.com Mounting Loudspeaker with U-Bracket Before You Begin - Recommended Tools • 10 mm sockets and socket wrenches - for M8 bolts on U-bracket • T3 square drive (included) - for removing plastic inserts. CAUTION: • The loudspeaker weighs 21.8 kg (48 lbs) with U-bracket attached. Use caution when lifting to avoid injury and/or damage to the speaker.
-
Page 6: Using The Ground Feet
Using the Ground Feet The MB210 subwoofer can be placed on the ground in either the horizontal or vertical orientation, using the ground feet. To attach the ground feet: Remove the backing from the adhesive side of the first ground foot. -
Page 7: Technical Information
The Bose® PowerMatch configurable power amplifiers offer optimal amplification, amplifier limiting, digital signal processing (DSP), and DSP presets for use with the MB210 Compact Subwoofer. Please refer to the specifications listed on the pro.Bose.com website for amplifiers and compare with the table above to determine which model is best for your particular system design. - Page 8 Technical Information pro.Bose.com Recommended Mid-High Loudspeakers The MB210 loudspeaker pairs excellently with Bose FreeSpace, RoomMatch Utility and Panaray lines of loudspeakers, and can also be used with any other passive Loudspeakers. Installation Guide - 13...
-
Page 9: Additional Information
Additional Information pro.Bose.com MB210 Loudspeakers Technical Specifications Single Module Performance Frequency Response (- 3 dB) 45 - 180 Hz Frequency Range (-10 dB) 37 - 270 Hz Recommended High-Pass Protection Filter 45 Hz with 24dB / octave filter Nominal Coverage Pattern... -
Page 10: Contact Information
Additional Information pro.Bose.com Contact Information Visit us on the web at pro.Bose.com. Americas Hong Kong (USA, Canada, Mexico, Central America, South America) Bose Limited Bose Corporation Suites 2101-2105, Tower One, Times Square Framingham, MA 01701 USA 1 Matheson Street, Causeway Bay, Hong Kong Corporate Center: 508-879-7330 852 2123 9000 Americas Professional Systems,... - Page 11 ©2017 Bose Corporation, All rights reserved. Framingham, MA 01701-9168 USA www.pro.Bose.com All trademarks are the property of their respective owners AM792735 Rev. 00 June 2017...
